JBL STUDIO L8400P Owner's Manual

SPECIFICATIONS

Model L8400P
Description 12" (300mm), 600-Watt, high-performance compact powered subwoofer
Amplifier
Power (RMS) 600 Watts
Peak Dynamic 1200 Watts
Power †
Frequency
Response (–3dB) 22Hz – Low-pass crossover frequency
Low-Pass
Crossover
Frequencies 50Hz – 150Hz, Continuously adjustable
Low-Frequency
Transducer 12" (300mm) PolyPlas ™ cone with rubber surround and cast-aluminum chassis;
HeatScape motor structure; Symmetrical Field Geometry
™
fiberglass voice coil; magnetic shorting ring
Baffle Low diffraction, IsoPower
Enclosure Sealed
Inputs Gold-plated 5-way binding-post speaker-level; left and right line-level,
switchable to LFE
Outputs Gold-plated 5-way binding-post speaker-level; 150Hz high-pass when using
speaker-level connection
Dimensions
(H x W x D) 16-1/2" (15-1/2" without feet) x 15-1/2" x 15-1/2"
(419mm [394mm without feet] x 394mm x 394mm)
Weight 58 lb (26.4kg)
†
The Peak Dynamic Power is measured by recording
the highest peak-to-center voltage produced by the
power amplifier with its limiters disabled, across
the output of a resistive load equal to minimum
impedance of the transducer, using a 50Hz sine wave
burst, 3 cycles on, 17 cycles off.
PRO SOUND COMES HOME
JBL Consumer Products, 250 Crossways Park Drive, Woodbury, NY 11797 USA
8500 Balboa Boulevard, Northridge, CA 91329 USA
2, route de Tours, 72500 Chateau du Loir, France
www.jbl.com
© 2005 Harman International Industries, Incorporated. All rights reserved.
JBL and Harman International are trademarks of Harman International
Industries, Incorporated, registered in the United States and/or other countries.
Part No. 354038-001
(SFG ); oversized
™ ™
™
™
Dolby and Pro Logic are registered trademarks of Dolby Laboratories.
DTS is a registered trademark of DTS, Inc.
All features and specifications are subject to change without notice.
STUDIO ™ L SERIES
L8400P
OWNER'S GUIDE
®
