CADENZA PRE AMPLIFIER
OWNER'S MANUAL
-------------------------------------------------------------------------------
© Viola Audio Laboratories 2005
The information contained in the manual is subject to change without notice. The
most current version of this manual will be posted on our web site at
www.Violalabs.com.
P/N: 91-cadenza manual
Revision: 01
Page 1 of 16
Viola Cadenza Manual Rev 1
7th September 2005

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Cadenza and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Viola Systems Cadenza

Summary of Contents for Viola Systems Cadenza

  • Page 1 The information contained in the manual is subject to change without notice. The most current version of this manual will be posted on our web site at www.Violalabs.com. P/N: 91-cadenza manual Revision: 01 Page 1 of 16 Viola Cadenza Manual Rev 1 7th September 2005...

  • Page 2: Table Of Contents

    • Cadenza Front Panel Description • Cadenza Rear Panel Description • Cadenza Power Supply Rear Panel • Connecting the Cadenza to your System Connecting the Inputs Connecting the Outputs • Connecting the Power Supply • AC Power Cable Connection •...

  • Page 3: Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS Please read all of the following instructions carefully before operating your Cadenza. This product contains no user serviceable parts. Never attempt to repair the unit yourself. Refer all servicing to a VIOLA approved technician. This product must be connected to the mains supply with a three- conductor AC mains power cord that includes a ground connection.

  • Page 4: Introduction

    INTRODUCTION Thank you for choosing the VIOLA Cadenza Preamplifier. Great care has gone into the design and manufacture of the Cadenza and if properly used, it will give a lifetime of musical enjoyment. We strongly recommend that you read these instructions before you attempt to use the unit, so that you can be sure it is set up to give optimum performance.

  • Page 5: Location

    If the setting on your unit is not correct, contact your VIOLA dealer. Only a VIOLA approved technician should change the voltage setting. Do not attempt to do this yourself. Should you set the unit to the wrong voltage, you risk personal injury and you may also cause serious damage to the unit which will void the warranty.

  • Page 6: Surround Sound Processor Loop

    Figure 1. SSP Loop Switch To gain access to the SSP loop switch you will need to remove the Cadenza’s top cover. This is secured with 20 socket head screws. You will require a 1/16 inch hex driver.

  • Page 7: Cadenza Front Panel Description

    INPUT LEFT dB GAIN RIGHT dB GAIN IOLA 10 11 12 10 11 12 CADENZA PREAMPLIFIER Figure 2. Cadenza front panel Input Selector Switch. The Cadenza has 7 inputs. These are described in the table below: Input Description Connector Reserved for future use...

  • Page 8: Cadenza Rear Panel Description

    DC POWER Figure 3. Cadenza rear panel The Cadenza’s input and output connectors are arranged in 2 rows on the rear panel. The lower row is for the right channel and the upper row is for the left channel. DC Power Input Connector.

  • Page 9: Cadenza Power Supply Rear Panel

    • NEVER short-circuit the Cadenza power supply outputs. • NEVER use any power supply other than the dedicated Cadenza power supply • NEVER use the Cadenza power supply to power anything other than the Cadenza. • ALWAYS switch the Cadenza off before connecting or any changing cables.

  • Page 10: Connecting The Inputs

    Note, these need be no more than finger tight. AC POWER CABLE CONNECTION If the wall outlet you plan to use for the Cadenza has an on/off switch, check that it is switched off. Insert the supplied AC mains cord into the receptacle on the rear of the Cadenza power supply and ensure that it is pushed securely home.

  • Page 11: Switching On For The First Time

    Allow the system to stabilize for 2 minutes, and then put a CD into the player and press play. If the wall outlet you are using for the Cadenza is switchable, switch it on now. Press the power switch on the Cadenza power supply rear panel so that the section with the number 1 is pushed down.

  • Page 12: Care And Cleaning

    250V FUSES DISCONNECT POWER BEFORE REPLACING FUSES Figure 5. Cadenza power supply mains inlet receptacle. • Check the fuse with a continuity tester and replace any blown fuses with one of the rating and type shown below. Using a fuse...

  • Page 13: Troubleshooting

    • Check the entire signal wiring in the system. • Check that all the units feeding the Cadenza are switched on and that the signal source is playing music. • Check that the input selector and any other relevant switches are set appropriately.

  • Page 14: Warranty

    WARRANTY VIOLA Audio Labs products are warranted to be free from defects if used under normal conditions for a period of 5 years from the date of shipment from the factory.

  • Page 15: Contacting Viola

    VIOLA will not pay freight costs if units are returned without a RA number, or if no fault is found. Customers are responsible for all freight charges for units returned for non-warranty repairs.

  • Page 16: Specifications

    44.7cm W x 9.1cm H x 40.6cm D Power Supply: 8.8” W x 3.6” H x 16” D 22.3cm W x 9.1cm H x 40.6cm D Specifications are subject to change without notice. Page 16 of 16 Viola Cadenza Manual Rev 1 7 th September 2005...
