PRO-SW100P 100-Watt Powered Subwoofer
Your RCA PRO-SW100P 100-Watt
Powered Subwoofer is designed to give
you the best possible low frequency sound
quality for the ultimate home theater
experience. You will be astonished by the
realism it adds to movie sound effects and
the power it lends to all kinds of music.
The subwoofer combines the power of a
built-in 100-watt RMS amplifier with a
responsive, 10-inch coated paper cone
woofer — all housed in a ported
bass-reflex enclosure to produce tight,
floor-rumbling, powerful bass (down to 42
Hz) that you can feel as well as hear! The
LED power indicator lets you see at a
glance when the subwoofer is operating.
Your subwoofer has an adjustable high cut
filter and high and low level inputs,
making it easy to incorporate into existing
systems, or you can use it as an integral
part of a subwoofer/satellite combination.
It also has these features:
Auto On/Off — automatically switches
the PRO-SW100P’s amplifier to standby if
the subwoofer does not receive a signal for
about 11 minutes.
Standby Indicator — lights when the
subwoofer is connected to power but not
receiving a signal.
High Level Input — lets you connect the
subwoofer to an amplifier’s or receiver’s
speaker outputs.
Note: You need speaker wire (not
supplied) to connect the subwoofer to an
amplifier or receiver’s speaker outputs.
High Level Output — lets you connect
the subwoofer between an amplifier or
receiver (without line out terminals) and
other speakers.
Low Level Input — lets you connect the
subwoofer to an amplifier’s or receiver’s
subwoofer out or pre out jacks. These
inputs automatically sum left and right
channel information.
Note: You need phono cables (not
supplied) to connect the subwoofer to an
amplifier or receiver’s subwoofer out or
pre out jacks.
Volume Control — lets you match the
PRO-SW100P’s output level to your
satellite speakers’ output (if used).
Phase (Polarity) Switch — inverts the
subwoofer’s output polarity so you can set
it to match the main speakers.
Frequency HZ — controls the high
frequency cutoff point. Rotated fully
clockwise, it cuts high frequencies over
200 Hz. Rotated fully counterclockwise, it
cuts high frequencies over 50 Hz.

Advertisement

   Related Manuals for RCA PRO-SW100P

   Summary of Contents for RCA PRO-SW100P

  • Page 1

    Auto On/Off — automatically switches it to match the main speakers. the PRO-SW100P’s amplifier to standby if the subwoofer does not receive a signal for Frequency HZ — controls the high about 11 minutes.

  • Page 2: Safety Instructions

    • Unplug the PRO-SW100P’ s power WARNING: To reduce the risk of fire or cord from the electrical outlet if it will shock hazard, do not expose this product to be left unused for a long time. rain or moisture.

  • Page 3: Choosing A Location

    CHOOSING A LOCATION you place the PRO-SW100P at least 4 inches away from the wall, and at least 2–3 feet away from your television or Cautions: computer’s disk drive system so the • To prevent the cabinet from warping subwoofer’s magnet will not distort the...

  • Page 4: Connecting Speakers

    Connect the amplifier/receiver’s speaker Amplifier/Receiver Right Left Speaker Speaker Sub Out/Pre Out Terminal output terminals to the PRO-SW100P’s speaker terminals. Be Rec Out HIGH LEVEL INPUT HIGH LEVEL INPUT HIGH LEVEL OUTPUT – –...

  • Page 5: Connecting To Power

    1. Separate the conductors for a length of about 2 inches on the end of each wire. Then strip inch of insulation Plug the PRO-SW100P’s AC power cord from the ends of each conductor and into an AC outlet. The STANDBY indicator twist the wire ends.

  • Page 6

    Once you have adjusted VOLUME , use the amplifier/receiver’s CONTROL volume control to control the speakers’ To enjoy your RCA PRO-SW100P 100- volume. Watt Powered Subwoofer for a long time: • Keep the subwoofer dry. If it gets wet, wipe it dry immediately.

  • Page 7: Specifications

    SPECIFICATIONS Amplifier Output ............ 100W RMS (4 Ohms @ 1% THD) Crossover ................50 Hz–200 Hz Adjustable Frequency Response .................. 42–200 Hz Power Voltage ..................AC 120 V/60 Hz Power Consumption ..................120W Dimensions (HWD) ................ 14 × 14 × 15 (311 ×...

  • Page 8

    Limited One-Year Warranty This product is warranted by RadioShack against manufacturing defects in material and workman- ship under normal use for one (1) year from the date of purchase from RadioShack company-owned stores and authorized RadioShack franchisees and dealers. EXCEPT AS PROVIDED HEREIN, Ra- dioShack MAKES NO EXPRESS WARRANTIES AND ANY IMPLIED WARRANTIES, INCLUDING THOSE OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, ARE LIMITED IN DURATION TO THE DURATION OF THE WRITTEN LIMITED WARRANTIES CONTAINED...
