PRO-SW220P 200-Watt-Powered Subwoofer
Your RCA PRO-SW220P 200-Watt
Powered Subwoofer is designed to give
you the best possible low frequency sound
for the ultimate home theater experience.
You will be astonished by the realism it
adds to movie sound effects and the power
it lends to all kinds of music.
The subwoofer combines the power of a
built-in 200-watt RMS amplifier with a
responsive, 12-inch coated paper cone
woofer — all housed in a ported bass-
reflex enclosure to produce tight, floor-
rumbling powerful bass (down to 36 Hz)
that you can feel as well as hear. The
power indicator lets you know when the
subwoofer is operating.
Your subwoofer has an adjustable high cut
filter and high and low level inputs so it is
easily incorporated into existing systems,
or used as an integral part of a subwoofer/
satellite combination.
Its other features include:
Auto On/Off — automatically switches
the PRO-SW220P's amplifier to standby if
the subwoofer does not receive a signal for
about 11 minutes.
Standby Indicator — power indicator
changes color when the subwoofer is
connected to power but not receiving a
signal.
High-Level Input — lets you connect the
subwoofer to an amplifier's or receiver's
speaker outputs.
Note: You need speaker wire (not
supplied) to connect the subwoofer to an
amplifier or receiver's speaker outputs.
High Level Output — lets you connect
the subwoofer between an amplifier or
receiver (without line out terminals) and
other speakers.
Low Level Input — lets you connect the
subwoofer to an amplifier's or receiver's
subwoofer out or pre out jacks. These
inputs automatically sum left and right
channel information.
Note: You need phono cables (not
supplied) to connect the subwoofer to an
amplifier or receiver's subwoofer out or
pre out jacks.
Volume Control — lets you match the
PRO-SW220P's output level to your
satellite speakers' output (if used).
Phase (Polarity) Switch — Inverts the
subwoofer's output polarity so you can set
it to match the main speakers.
Frequency Hz Control — lets you set the
high frequency cutoff point. Rotated fully
clockwise, the subwoofer cuts high
frequencies over 200 Hz. Rotated fully
counterclockwise, it cuts high frequencies
over 50 Hz.
© 2001 RadioShack Corporation.
All Rights Reserved.
