American Standard Wall Supply 7544.018 Specification Sheet

GENERAL DESCRIPTION:

Brass wall supply with screwdriver stop, union, 3/8" NPT
nipples. Wall mounted. Chrome finish. Can be used with
pedal valve 7679.012.
SUGGESTED SPECIFICATION
Wall mounted brass supply valve shall feature a screwdriver stop, union and nipples. Shall feature Polished Chrome finish.
Fitting shall be American Standard Model# 7544.018.
© 2008 AS America Inc.
3/8 NPT THREADS
64mm
(2-1/2)
DIA.
MODEL NUMBER:
7544.018 Wall Supply - 3/8"
With screwdriver stop. For use with 7679.012 pedal
valve.
143mm
(5-5/8)
57mm
(2-1/4)
MIN.
3/8 NPT THREADS

PRODUCT FEATURES:

Brass Construction:
applications.
Brass Supply Valve:
Renewable seat. Wall mounted.
Polished Chrome Finish:
applications.
L101
WALL SUPPLY
225mm
(8-7/8)
Durable - excellent in high use
Brass loose key stop valve.
Excellent in commercial
