American Standard Culinaire ASME A112.19.3 Specification Sheet

CULINAIRE™ 33" STAINLESS STEEL
KITCHEN SINK
❏ 7502.103 Top Mount, Single Faucet Hole
❏ 7502.403 Top Mount, 4 Faucet Holes
• 18 Gauge Stainless Steel
• 18/10 Chrome Nickel content
• Double bowl design
• Top mount
• Choice of 1 or 4 faucet holes
• One accessory hole
• Mounting clips supplied
Nominal Dimensions:
838 x 559 x 209mm
(33" x 22" x 8-1/4")
❏
7502.000 Undercounter Mount
• 18 Gauge Stainless Steel
• 18/10 Chrome Nickel content
• Double bowl design
• Undercounter installation
• Mounting clips and cutout template supplied
Nominal Dimensions:
781 x 470 x 200mm
(30-3/4" x 18-1/2" x 7-7/8")
Bowl sizes:
343mm (13-1/2") wide
410mm (16-1/8") front to back
200mm (7-7/8") deep
Compliance Certifications -
Meets or Exceeds the Following Specifications:
• ASME A112.19.3 for Stainless Steel Plumbing
Fixtures
• CSA B45 for Plumbing Fixtures
To Be Specified:
❏ Color: Stainless Steel
❏ Faucet*:
❏ Faucet Finish:
❏ Basket Strainer: 4331.013
❏ Soap Dispenser: 4503.115
❏ Vinyl Coated Bottom Sink Rack-Sm: 7412.100
* See faucet section for available models
© 2008 AS America Inc.
7502.103 Shown with 4137.100 Culinaire Pull-out
Kitchen Faucet (not included)
7502.000 Shown with 4233.601 Culinaire
Kitchen Faucet (not included)
SEE REVERSE SIDE FOR ROUGHING-IN DIMENSIONS
❏ Vinyl Coated Dish Rack-Sm: 7532.100
❏ Wood Cutting Board-Rectangular: 9001.100
❏ Stainless Steel Colander: 8130.100
❏ Hole Cover Plug: 790773-0070A
❏ Top Mount Clip Kit for 1" plus-thick countertop:
790772-0070A
G3
CULINAIRE™ 33"
DOUBLE BOWL
18 GAUGE STAINLESS STEEL
Revised 2/08
