D-Link DCS-900 User Manual

D-Link DCS-900 User Manual

Wired network camera
Hide thumbs Also See for DCS-900:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Installation Manual, Manual

Advertisement

Table of Contents
loading

Related Manuals for D-Link DCS-900

Summary of Contents for D-Link DCS-900

  • Page 2: Table Of Contents

    SETUP > Time and Date ..................................... 41 MAINTENANCE ........................................42 MAINTENANCE > Device Management................................42 MAINTENANCE > Backup and Restore................................44 MAINTENANCE > Firmware Update ................................45 STATUS ............................................46 STATUS> Device Info ......................................46 HELP............................................47 Installing the DCS-900 Behind a Router ..................................... 48...
  • Page 3 Assigning and Opening the HTTP Port on the DCS-900 ............................48 1) Open the HTTP Port ......................................48 Router Setup and Installation....................................... 49 Assigning and Opening Virtual Server Ports ................................50 2) Open Virtual Server Ports To Enable Remote Image Viewing........................50 Viewing Your Camera ........................................
  • Page 4 Uninstall IPView SE ..........................................81 Frequently Asked Questions ........................................ 82 Wired Network Camera Features....................................82 Wired Network Camera Installation .................................... 83 How to Ping Your IP Address......................................84 Adjusting the Camera Focus ........................................ 86 Technical Specifications ........................................87...

  • Page 5: Package Contents

    Introduction Congratulations on your purchase of the DCS-900 Wired Network Camera! The DCS-900 is a versatile and unique solution for your small office or home. Unlike a PC Camera, the DCS-900 is a stand-alone system with a built-in CPU and Web server that transmits high quality video images for monitoring. The DCS-900 can be accessed remotely, and controlled from any PC/Notebook over the Intranet or Internet via a web browser.

  • Page 6: Features And Benefits

    Features and Benefits Simple to Use - The DCS-900 is a stand-alone system with a built-in CPU, requiring no special hardware or software such as PC frame grabber cards. The DCS-900 supports both ActiveX mode for Internet Explorer and Java mode for Internet Explorer and Netscape Navigator™.

  • Page 7: Hardware Overview

    Hardware Overview Connections LEDs...

  • Page 8: Hardware Installation

    Attach the External Power Supply Attach the external power supply to the DC power input connector located on the rear panel of the DCS-900 and connect it to a wall outlet or power strip. NOTE: Power source is confirmed when the red LED Power Indicator located to the right of the lens on the DCS-900 is illuminated.

  • Page 9: Security

    Administrator for defined users who have a User Name and Password. The Administrator can release a public User Name and Password so that when remote users access the DCS-900 they will be allowed to view the images transmitted by the DCS-900.

  • Page 10: Auto-Run Installation

    Insert the Installation CD-ROM into your computer’s CD-ROM drive to initiate the Auto-Run program. The content of the Installation CD-ROM includes: • View Quick Installation Guide - click to preview the Quick Installation Guide in PDF format for step-by-step instructions of the DCS-900 Installation.

  • Page 11: Quick Installation

    Quick Installation Click the Start button to start the Quick Installation.
  • Page 12 Follow the simple steps below to quickly install the device, click NEXT>>.
  • Page 13 After done the connection of Ethernet cable, click NEXT>>.
  • Page 14 Follow the instruction below to power up the device, and then click NEXT>>.
  • Page 15 Then the system will automatically search the device.
  • Page 16 Select your camera’s MAC ID from the MAC ID List, and then click NEXT>>.
  • Page 17 DCC (D-Link Click’n Connect) will auto-detect whether your Internet connection with or without DHCP and diagnose that if DHCP is also available for your IP camera or not in order to display the next corresponding screen. With DHCP: Since DHCP is available for your Internet connection and IP camera, DCC will start DHCP assign automatically for your IP camera and display the following screen...
  • Page 18 Without DHCP: If DHCP is not available for your network and IP camera, the following screen will show up to allow you select Fixed IP Address or PPPoE for your Internet connection. For Fixed IP Address: If your camera is directly connected to a DSL Modem and your ISP has supplied you with a fixed IP for your Internet connection, you may select this option and click NEXT>>...
  • Page 19 When Fixed IP Address is selected for your Internet connection, you need to fill the IP information in the related fields, and then click NEXT>>.
  • Page 20 The installation is now complete. You may click ADVANCED Options to enter your IP camera’s Web Configuration or EXIT to leave the screen.
  • Page 21 For PPPoE: Select PPPoE option and click NEXT>> button.
  • Page 22 Enter Username and Password that are supplied by your ISP in the related fields and click NEXT>>.
  • Page 23 The installation is now complete. You may click ADVANCED Options to enter your IP camera’s Web Configuration or EXIT to leave the screen.

  • Page 24: Multicamera Management

    Multicamera Management Click Multicamera Management of the Installation CD.
  • Page 25 Follow the simple steps below to run the Setup Wizard to guide you quickly through the installation process. Click Next.
  • Page 26 Click Yes.
  • Page 27 Click Next.
  • Page 28 Click Finish.
  • Page 29 Be aware that the Setup Wizard is offered for you to do configuration of your camera in the future only. Not necessary to run the Setup Wizard for your first time using the camera. To run the Setup Wizard, click on Start Programs D-Link Setup Wizard. Your camera’s IP Address will be displayed under the heading of Current IP Address along with its corresponding MAC Address. Click Wizard.
  • Page 30 You must change the Admin ID and Password immediately to protect your camera against unauthorized access. By default, the Admin ID and Password are blank. To change the Admin ID and Password, select both Change boxes and enter a New ID and New Password. Click Next.
  • Page 31 Enter an IP Address and Subnet Mask for your camera if you want to change the current settings. Enter your Gateway and DNS settings. These settings must correspond with your network settings for you to access the camera. If you are unsure of what these settings should be, check with your network administrator. If you are connecting to a router, the Gateway and DNS 1 entries should be the IP address of your router.
  • Page 32 If you need to make any changes, click Back to modify your settings. Otherwise, click Restart to save your settings.
  • Page 33 Your setup is now complete! Click Link to launch your web browser and view your images.

  • Page 34: Using The Configuration Menu

    Using the Configuration Menu After completing the Setup Wizard, you are ready to use your camera. The Web configuration utility is designed to easily access and configure your DCS-900. Click the “Link” button will open up the main configuration page.

  • Page 35: Live Video

    LIVE VIDEO This section allows you to display your IP camera's live video by using Activex or Java. LIVE VIDEO > Camera Please make sure that you have the latest version of Java installed on your computer to ensure proper operation when viewing the video in Java mode. Java can be downloaded for free from Sun’s web site.

  • Page 36: Setup

    SETUP This section allows you to further set up or change the configuration of your IP camera. SETUP > Network Setup This option, Network Setup, allows you to configure your LAN and Internet configuration, including the settings for LAN, PPPoE, and port. After done the configuration, you may click Save Settings button to save the new settings or Don’t Save Settings button to abandon it.
  • Page 37 ISP or your network administrator. Second HTTP Port – Most ISPs do not open port 80 (a DCS-900 default video transfer port) for their residential customers, the DCS-900 has the ability to use a different port by enabling the second http port for its video transfer.

  • Page 38: Setup > Dynamic Dns

    IP address, is useful. With most Cable and DSL connections, you are assigned a dynamic IP address and that address is used only for the duration of that specific connection. With the DCS-900, you can set up your DDNS service and the DCS-900 will automatically update your DDNS server every time it receives a different IP address.

  • Page 39: Setup > Video

    SETUP > Video This Video option allows you to set up your IP camera’s video quality, resolution, and Frame rate. After done the configuration, you may click Save Settings button to save the new settings or Don’t Save Settings button to abandon it. Video Setting –...
  • Page 40 Auto. Brightness Control: Allows you to adjust the brightness level. The default setting is 64. Contrast Control: Allows you to adjust the contrast level. The default setting is 64. Saturation Control: Allows you to adjust the saturation level. The default setting is 64. Light Frequency: Adjust the light frequency to suit your area of operation.

  • Page 41: Setup > Mail

    SETUP > Mail This option allows you to configure mail settings. If you want to specify the IP camera email settings, you may check By E-mail checkbox and modify the further related settings on the Mail Settings section. If you are setting up motion detection and will not be recording onto a PC, you can setup an FTP or SMTP account in the camera.
  • Page 42 E-Mail Account – SMTP Server Address: The domain name or IP address of external mail server. Sender e-mail Address: The e-mail address of the person sending the camera snapshots. Receiver e-mail Address: The e-mail address of recipient for the SMTP server. User Name: If the SMTP server uses authentication you must enter your user name here Password: This is the password that you use with your user name to connect to the SMTP server.

  • Page 43: Setup > Ftp

    SETUP > FTP This option is used to set up FTP upload configuration.
  • Page 44 FTP Server – Host Address: This is the IP address of the FTP server that you will be connecting to. Port Number: Default is port 21. If changed, external FTP client program must change the server connection port accordingly. User Name: Specifies the user name to access the external FTP server. If you are to upload snapshots to an FTP server you will need to fill in the Domain name or IP address of your external FTP server.

  • Page 45: Setup > Time And Date

    SETUP > Time and Date This option allows you to configure, update, and maintain the correct time on the internal system clock. From this section you can set the time zone that you are in and set the NTP (Network Time Protocol) Server. Daylight Saving can also be configured to automatically adjust the time when needed. After done the configuration, you may click Save Settings button to save the new settings or Don’t Save Settings button to abandon it.

  • Page 46: Maintenance

    Administrator for defined users who have a User Name and User Password. The Administrator can release a public User Name and Password so that when remote users access the DCS-900 they will be allowed to view the images transmitted...
  • Page 47 Location: Enter information of where your camera is located. LED Control: You can set the LED of the DCS-900 to on (Normal), off (OFF), or blink randomly (Dummy). User Access Control: Allow you to enable or disable user access control.

  • Page 48: Maintenance > Backup And Restore

    MAINTENANCE > Backup and Restore The Backup and Restore option not only allows you to save the current configuration in a computer for backup by clicking Save button, but also allows you to reload a configuration that you saved before by clicking Browse to direct to the backup file, and then clicking Update Settings button for reloading with rebooting the device. Beside, you are also allowed to return your IP camera to the default settings by clicking Restore Device button, and restart the camera by clicking Restart Device button.

  • Page 49: Maintenance > Firmware Update

    First, check the D-Link support site for firmware updates at http://support.dlink.com. Make sure that the firmware you want to use is saved on the local hard drive of your computer. Click on Browse to search the local hard drive for the firmware that you downloaded from the D-Link Website (support.dlink.com) to be used for the update.

  • Page 50: Status

    The Status section provides the detail information about your IP camera. STATUS> Device Info The Device Info option lists the following important settings that are currently set for your DCS-900, including detail information about Device Status, Ethernet Status, Video Status, Network Status, and Active Users.

  • Page 51: Help

    HELP The Help screen provides you brief information about the DCS-900 for your reference.

  • Page 52: Installing The Dcs-900 Behind A Router

    Installing the DCS-900 Behind a Router Assigning and Opening the HTTP Port on the DCS-900 (For Installing Multiple Cameras) Opening ports will allow users to view the camera via the Internet. The ports that are opened must be unique for each camera in order to successfully view the images remotely.

  • Page 53: Router Setup And Installation

    Router Setup and Installation The following steps generally apply to any router that you have on your network. The D-Link DIR-300 is used as an example to clarify the configuration process. Your WAN IP Address information will be listed on following window.

  • Page 54: Assigning And Opening Virtual Server Ports

    Assigning and Opening Virtual Server Ports 2) Open Virtual Server Ports To Enable Remote Image Viewing The Virtual Server Ports of your router must be opened for remote access to your camera. This is also referred to as port forwarding. Please proceed as follows: ‧...

  • Page 55: Viewing Your Camera

    Viewing Your Camera After all settings have been entered correctly, a user inside or outside your network will have access to the camera through a standard Web browser. To access from the Internet, simply type in the IP Address of the router given to you by your ISP, a colon, and the port number that you gave your camera. (e.g. http://205.163.122.96:83).

  • Page 56: Ipview Se Application Installation

    IPView SE software is included for administrators to manage up to 4 DCS-900s remotely. Administrators can also record to hard drive and configure advanced settings for the DCS-900. IPView SE is a complete software management tool for the DCS-900 and includes all configurable settings available in the web...
  • Page 57 Click Next.
  • Page 58 Click Yes.
  • Page 59 Click Next.
  • Page 60 Click Finish.
  • Page 61 After successfully installing the IPView SE, the application program for the DCS-900 is automatically installed to \Programs\IPView SE Directory. To start running the IPView SE click on Start Programs IPView SE IPView SE. Once the IPView SE application control panel is executed, the interface will appear.

  • Page 62: Ipview Se

    IPView SE This section describes the operation of the IPView SE application user interface with detailed procedures for using the application. IPView SE allows you to manage your cameras by enabling you to search, configure, and preview all the DCS-900s from one location. It is designed with a user-friendly interface for ease of control and navigation.

  • Page 63: Ipview Se Icon Description

    IPView SE Icon Description...

  • Page 64: How To Add A New Camera

    How to Add a New Camera To add a new camera, select the Camera button from the IPView SE. Make sure that the green lights are on when clicking the camera button. Select the camera you would like to connect to and click Add A Camera. If the camera is not listed in this list, click the Input IP Address button. Enter the IP Address of the camera in the specified field and click Add.
  • Page 65 If you are unsure of the IP Address of the camera, you can click on Search to search for all available cameras that are installed on your local area network. NOTE: Only cameras on your local area network can be located using Search in IPView SE. If you want to add a camera via the Internet, you must enter in a public IP Address.

  • Page 66: How To Delete A Camera

    How to Delete a Camera Click the Liberate Camera button on the IPView SE, while you are connected to the camera you would like deleted. The IPView SE camera button becomes available as soon as you click on the Liberate Camera button. The green light from under the camera button will become grey.

  • Page 67: How To Change The Ip Address

    How to Change the IP Address To change a camera’s IP Address, you must highlight the camera you wish to change. Click the Change IP Address button and the Change IP Address dialog box will appear. Select Manually Assign IP if you want to connect manually to the camera by providing the IP Address, Subnet Mask, and Default Gateway. Select DHCP if you do not wish to assign an IP address to your camera.

  • Page 68: How To Format The Camera View

    How to Format the Camera View Select the Combine button on the IPView SE and you should see all four cameras combined (see image below). A maximum of 4 cameras can be viewed simultaneously with IPView SE.

  • Page 69: How To Rotate The View

    How to Rotate the View In View Mode format, click on the Rotate button and the image should rotate 90° to the left (see image below).

  • Page 70: View/List

    View/List Click the View/List button . All the cameras and their properties, such as the camera name IP Address, user name, and functional information, will be displayed in the View/List screen. Zoom Click the Zoom button to zoom in on the camera image. The options under zoom are Fit Window x1, x1.5, x2, x2.5, x3, x3.5, and x4.

  • Page 71: Color Setting

    Color Setting Click the Color Setting button to adjust the Brightness, Contrast, and Hue. Wake Up Control Panel Click the Wake Up Control Panel button to open the control panel again when it is closed. Always on Top Click the Always on Top button to have the display screen always appear on top.

  • Page 72: How To Take A Snap-Shot With The Camera

    How to take a Snap-Shot with the Camera In View Mode format select the Snapshot button located on the upper left corner of the screen. A Save Image dialog box will appear for you to save the snapshot picture.

  • Page 73: How To Start Recording

    Camera Settings Once you have completed the initial configuration of the DCS-900 using the Web-based interface, you can review or change your configuration using either the Web-based configuration utility or the Settings in the DCS-900 IPView SE. Configure Camera from Web Click the Configure Camera from Web button to start configuring your camera from the web again (see page 24).

  • Page 74: Motion Setting

    Motion Setting Click the Motion Setting button to setup the options for motion recording. On this screen you can select to Invoke Alarm and/or Sent E-mail. Click the E-mail Setting button to configure your E-mail. The Sensitivity Level can be adjusted between Low and High for motion recording.

  • Page 75: Manual Recording

    Manual Recording Click the Manual Recording button to begin recording images from you camera. Schedule Recording Click the Schedule Recording button to record based on a specific time and date. Click Add to set the time and date recording.
  • Page 76 Select Date Mode and enter in the Start date/time, and Stop date/time. The camera will start to record according to the specified date and time period entered. Select Week Mode to specify which date to record during the time period.

  • Page 77: Motion Recording

    Motion Recording Clicking on the Motion Recording button will record images upon motion detection. When this option is selected and the camera detects motion within the range of the viewing window, recording will be triggered. Recording will continue until no motion is detected. Click on the Motion Setting button to set the sensitivity levels for motion recording.

  • Page 78: Scan

    Scan Click the Scan button to display each camera one by one. When this option is selected the camera(s) will briefly display their images in the View Mode format. Camera’s Extra Information Click the Camera’s Extra Information button to view information about your camera.

  • Page 79: Play

    Play Click the Play button to playback video recorded from your camera.

  • Page 80: System Configure

    IPView SE. Profile: The DCS-900 will not have a profile to load initially, you will have to select all of your cameras and then click the Save or Save As buttons to save your profile. Up to four cameras can be saved per configuration, there are no limits...
  • Page 81 Log Storage: The Single HDD Reserved Space option permits reserved HDD space from 500 MB to 1000 MB. The Split Recording File option is used to adjust the file size for recording the video images (the default setting is 10MB). If the recorded video files reach the file size, video images will be recorded into another file automatically.
  • Page 82 To modify the storage, click the Modify button. You should see the storage dialog box again. To delete a record of storage, select the path and click the Delete button. If you try to delete the very last storage in the list, you will receive a warning message telling you to keep one record of storage at least.
  • Page 83 the amount of space left on your drive before overwrite takes place. For instance if you select 1000 MB and your total hard drive space is 3000MB, as soon as your drive reaches over a 1000 MB capacity your files will be overwritten. You can specify between 300MB to 10GB hard drive reserve space, depending on the free space available on your hard drive.

  • Page 84: About

    About Click the Help/About icon, and then select About for camera details such as software version.

  • Page 85: Uninstall Ipview Se

    Uninstall IPView SE Click on Start Menu Programs IPView SE Uninstall IPView SE. A new prompt screen will be displayed like the one below confirming the removal. At the Confirm Uninstall dialog box, click OK to continue the process. The InstallShield Wizard prompt will appear. Click Finish to complete the uninstallation procedure.

  • Page 86: Frequently Asked Questions

    7 Can the Internet Camera be setup as a PC-cam on the computer? No, the Internet Camera is used only on Ethernet and Fast Ethernet network or supported by wireless transmission. The D-Link DSB-C110, DSB-C310 can be used as a PC Camera (Webcam).

  • Page 87: Wired Network Camera Installation

    Wired Network Camera Installation 11 Why does the Power LED not light up constantly? The power supply used might be at fault. Confirm that you are using the provided power supply, which is DC 5V, for the Internet Camera and verify that the power supply is well connected.

  • Page 88: How To Ping Your Ip Address

    How to Ping Your IP Address The PING (Packet Internet Groper) command can determine whether a specific IP Address is accessible by sending a packet to the specific address and waiting for a reply. It is a very useful tool to confirm if the IP Address conflicts with the Internet Camera over the network. Follow the step-by-step procedure below to utilize the PING command.
  • Page 89 If you fail to connect to your camera you will see the following: Check to see if you have entered your camera’s IP Address correctly or reassign your camera’s IP Address.

  • Page 90: Adjusting The Camera Focus

    Adjusting the Camera Focus To help you get the best image quality, keep in mind that while adjusting the DCS-900 focus you can preview the image quality from your Web browser. NOTE: You can further adjust the Internet Camera’s image quality through the Web Configuration under SETUP > Video. Please refer to the Web Configuration section for further details.

  • Page 91: Technical Specifications

    Technical Specifications Network • TCP/IP (DHCP or Static IP Address) • Wired LAN: 10/100Mbps Web Access Requirements • Any Java-Enabled or ActiveX compatible Web Browser,. i.e. current versions of Microsoft Internet Explorer or Netscape Navigator™. Media Streaming Protocol • HTTP Video Specification •...
  • Page 92 Power Source: • 5V, 2.5A Power Consumption • 5W Environmental specification • Operating temperature: 5°C to 50°C • Storage temperature: -25°C to 50°C • Operating relative humidity: 5% to 95% non-condensing...
