- Page 1 WHYNTER OUTDOOR REFRIGERATOR MODEL # : BOR-325FS Instruction Manual Congratulations on your new WHYNTER product. To ensure proper operation, please read this Instruction Manual carefully before using this product. Keep this manual in a safe place for future reference.
-
Page 2: Table Of Contents
TABLE OF CONTENTS PARTS AND FEATURES SAFETY PRECAUTIONS 4 - 5 ENERGY-SAVING TIPS INSTALLATION 5 - 8 ELECTRICAL REQUIREMENTS OPERATION INSTRUCTIONS CARE AND MAINTENANCE TROUBLESHOOTING WARRANTY INFORMATION... -
Page 3: Parts And Features
PARTS AND FEATURES SPECIFICATIONS Description of product Built-in Outdoor refrigerator Model BOR-325FS Voltage/Frequency AC 115V~60Hz 1. Light Amperage 2.0A 2. Fan Stainless Cabinet; Stainless 3. Shelves Color Door 4. Door 5. Light Switch Refrigerant R134a, 1.94 oz. 6. Vent High/Low side pressure 190 / 90 psig 7. -
Page 4: Safety Precautions
TO REDUCE THE RISK OF FIRE, ELECTRICAL WARNING SHOCK, OR INJURY WHEN USING YOUR OUTDOOR REFRIGERATOR, FOLLOW THESE BASIC PRECAUTIONS: All repairs, disassembly and modifications should be performed only by qualified technicians. Attempting to perform this yourself could result in fire, malfunction or injury. ... -
Page 5: Energy-Saving Tips
Pull out the plug before doing any maintenance on the unit to avoid electric shock. Never pull out plug when hands are wet! This unit is not intended for the storage of medicines or chemical reagents. Keep packing materials away from children. -
Page 6: Location Requirements
near any source of heat or moisture, or in direct sunlight. Direct sunlight may affect the finish and, nearby heat sources will cause higher electrical consumption. Install the outdoor refrigerator in a well-ventilated area where the ambient temperature is above 25°F and below 100°F ... - Page 7 Reversing the Door Swing Tools needed: Flathead screwdriver, Phillips screwdriver IMPORTANT: Before you begin, unplug the refrigerator or disconnect power. To remove door from hinges: 1. Remove the top hinge cover and bottom louver. 2. Using a Phillips screwdriver, remove the screws, then remove top hinge mat and top hinge. Keep the parts together and set them aside.
-
Page 8: Electrical Requirements
Leveling the Refrigerator It is important for the refrigerator to be leveled in order to work properly. It can be raised or lowered by turning the four feet on the bottom of the machine. We recommend using a carpenter’s level to check the machine. 1. -
Page 9: Operation Instructions
OPERATION INSTRUCTIONS IMPORTANT: Do not plug in the refrigerator for 24 hours after unit is set in place. Failure to do so may result in the unit working improperly. This refrigerator has a rotary temperature control knob (thermostat) inside the unit which is marked with the settings OFF-COLD-COLDEST in order of increasing coldness. -
Page 10: Care And Maintenance
CARE AND MAINTENANCE Before proceeding with cleaning and maintenance operations, make sure the power line of the unit is disconnected and the water line is shut off. Cleaning the Outside Unplug your refrigerator. Clean the outside with a cloth dampened in warm soapy water. Dry thoroughly with a soft cloth. -
Page 11: Troubleshooting
TROUBLESHOOTING Many common refrigerator problems are easily resolved. Try the troubleshooting suggestions below to see if the problems can be resolved before having to contact the service department. PROBLEM POSSIBLE CAUSE SOLUTIONS Ensure the appliance is There is a power failure. plugged in and the power ... -
Page 12: Warranty Information
(within two months of purchase; after two months to one year, customer will be responsible for freight cost to Whynter’s service department), along with an explanation of the claim to Whynter LLC. Please package the Outdoor Refrigerator carefully in its original packaging material to avoid damage in transit.
