- Page 1 The Ideal Home Entertainment Center 2006 Thermaltake Technology Co., Ltd. All Rights Reserved. All other registered trademarks belong to their respective companies.
-
Page 2: Table Of Contents
Contents ontents hapter 1. Product Introduction 1.1 Specification hapter 2. Case Mechaniacl Operation 2.1 How to open the side panel 2.2 5.25"device installation 2.3 3.5" device installation 2.4 Tool-free PCI slot Usage 2.5 Power Supply Unit Installation hapter 3. Motherboard & Leads Installation 3.1 Motherboard Installation 3.2 Case LED Connection 3.3 Case Open Alarm Connection... -
Page 3: Chapter 1. Product Introduction
Chapter 1. Product Introduction 1.1 Specification VE1000SWA VE1000SNA VE1000BWS VE1000BNS Model VE1000SWA VE1000SNA Model VE1000BWS VE1000BNS Case Type Cube Tower Case Type Cube Tower Dimension 330 x 360 x 720 mm ( W*D*H) Dimension 330 x 360 x 720 mm (W*D*H) -
Page 4: Chapter 2. Case Mechaniacl Operation
Chapter 2. Case Mechaniacl Operation 2.2 5.25"device installation 2.1 How to open the side panel Firstly, please release the thumb screws of HDD cage shown as picture. Please find the side panel key in the back of the chassis, then unlock it as shown. -
Page 5: Device Installation
2.3 3.5" device installation Unscrew the screws on the both side of 5.25"cage. Remove the 5.25" cover. Remove the 3.5" bay cover if you would like to install Floppy Disk Drive. (If no, please see the step 5) Insert the device into the desired location of 5.25"... -
Page 6: Tool-Free Pci Slot Usage
2.4 Tool-free PCI slot Usage Insert hard drive disk into the desired location of cage Squeeze and pull out-ward the tool-free clip securing the PCI bracket. Take off the PCI bracket. Secure hard drive disk with enclosed screws from the both side of the cage. -
Page 7: Power Supply Unit Installation
Chapter3 Motherboard & Leads Installation 2.5 Power Supply Unit Installation Important Notice - Contents below are additional information for proper motherboard installation for Thermaltake Chassis. Please find out the mylars types from the accessory box (clear plastic films) Install power supply unit as... -
Page 8: Motherboard Installation
3.1 Motherboard Installation How to open the front panel Each motherboard has different standoff layout. It is highly suggested that you refer to your motherboard's manual when installing motherboard into the Case. The cases are applicable with Standard ATX and Micro ATX motherboards. Your motherboard may require a special I/O Panel, which should be included with your motherboard. -
Page 9: Case Led Connection
3.2 Case LED Connection 3.4 USB 2.0 & IEEE 1394 Firewire Connection On the front of the case, you can find some LEDs and switch leads (POWER SW*1, POWER LED*1, H.D.D. LED*1, RESET SW*1) USB connection Please consult user manual of your motherboard manufacturer, then connect these leads to the panel header on the motherboard. -
Page 10: Audio Connection
3.5 Audio Connection Please check your motherboard ,does it support AC'97 or HD-Audio , choose one of them to connect. IEEE1394 Firewire connection Please consult your motherboard manual to find HD AUDIO out the section of "IEEE1394 Firewire connection". Splout L Return L IEEE1394 ( Brank ) -
Page 11: Esata Connection
3.6 eSATA connection Chapter4 Other 4.1 Media LAB (VFD display) Installation (Optional) Please remove the front panel (See "how to open the front panel" ) Connect this to your motherboard at the "HDD LED". arrow means "+" Remove the 4 screws from 5.25"... -
Page 12: 7"Lcd Monitor Installation (Optional)
4.2 7"LCD monitor Installation (Optional) Please connect the Power SW connector to the PWR_SW connectors on the VFD core as shown. Unscrew the both side screws of 7" drive bay cover. Installation complete, please re- install the front panel and the chassis casing of the Mozart TX chassis Pull out the both side clips... - Page 13 Insert the 7"device Install the 7" cage onto the 7" drive bay Install the frame. Push all the metal clips to fix the cage.
-
Page 14: Secondary System Mini Itx Installation(Optional)
Secondary System Mini ITX Installation(Optional) 4.3 Secondary System Mini ITX Installation (Optional) This mini ITX upgrade kit (optional) includes following items This side towards the 5.25" PSU -270W (Please rear of the chassis. install to 5.25" drive bay) The circles mean the screw holes of mini ITX IDE data cable x 1 SATA data cable x 1 Power on/off and Reset switch (please install to 5.25"drive bay...
