Summary of Contents for Gigabyte GA-E350N

  • Page 1 Инструкция для Gigabyte GA-E350N Перейти в карточку товара 8 800 775 98 98...
  • Page 2 GA-E350N User's Manual Rev. 1001 12ME-E350N-1001R...
  • Page 3 Motherboard GA-E350N Motherboard GA-E350N Jun. 15, 2012 Jun. 15, 2012...

  • Page 4: Identifying Motherboard Revision

    Copyright © 2012 GIGA-BYTE TECHNOLOGY CO., LTD. All rights reserved. The trademarks mentioned in this manual are legally registered to their respective owners. Disclaimer Information in this manual is protected by copyright laws and is the property of GIGABYTE. prior notice. No part of this manual may be reproduced, copied, translated, transmitted, or published in any form or by any means without GIGABYTE's prior written permission.

  • Page 5: Table Of Contents

    Table of Contents GA-E350N Motherboard Layout ..................5 GA-E350N Motherboard Block Diagram .................6 Chapter 1 Hardware Installation ..................7 Installation Precautions ..................7 ..................8 Installing the Memory ..................10 Installing an Expansion Card ................. 10 Back Panel Connectors .................. 11 Internal Connectors ..................13 Chapter 2 BIOS Setup ....................21...

  • Page 6: Ga-E350N Motherboard Layout

    GA-E350N Motherboard Layout ATX_12V CPU_FAN KB_MS AMD E-350D APU SYS_FAN GA-E350N USB_HDMI F_USB2 AMD A45 FCH F_USB1 Realtek USB_LAN GbE LAN SPDIF_O AUDIO F_AUDIO CODEC Box Contents GA-E350N motherboard Motherboard driver disk Two SATA cables User's Manual I/O Shield The box contents above are for reference only and the actual items shall depend on the product package you obtain.

  • Page 7: Ga-E350N Motherboard Block Diagram

    GA-E350N Motherboard Block Diagram CPU CLK+/- (100 MHz) D-Sub DDR3 1333 (O.C.)/1066 MHz E-350D APU Single Channel HDMI RJ45 4 SATA 3Gb/s PCIe CLK Realtek (100 MHz) GbE LAN 8 USB 2.0/1.1 AMD A45 FCH PCI Express Bus Dual BIOS...

  • Page 8: Chapter 1 Hardware Installation

    Chapter 1 Hardware Installation Installation Precautions The motherboard contains numerous delicate electronic circuits and components which can become damaged as a result of electrostatic discharge (ESD). Prior to installation, carefully read the user's manual and follow these procedures: Prior to installation, make sure the chassis is suitable for the motherboard. Prior to installation, do not remove or break motherboard S/N (Serial Number) sticker or warranty sticker provided by your dealer.
  • Page 9 Built in with an AMD E-350D Dual-Core processor Built in with an AMD Radeon HD 6310 (DirectX 11) graphics core ™ Chipset AMD A45 FCH Memory 2 x 1.5V DDR3 DIMM sockets supporting up to 16 GB of system memory * Due to Windows 32-bit operating system limitation, when more than 4 GB of physical memory is installed, the actual memory size displayed will be less than 4 GB.
  • Page 10 Back Panel 1 x PS/2 keyboard port Connectors 1 x PS/2 mouse port 1 x parallel port 1 x serial port 1 x D-Sub port 1 x HDMI port 4 x USB 2.0/1.1 ports 1 x RJ-45 port 3 x audio jacks (Line In/Line Out/Microphone) I/O Controller iTE I/O Controller Chip Hardware...

  • Page 11: Installing The Memory

    Installing the Memory Read the following guidelines before you begin to install the memory: Make sure that the motherboard supports the memory. It is recommended that memory of the same capacity, brand, speed, and chips be used. (Go to GIGABYTE's website for the latest supported memory speeds and memory modules.) Always turn off the computer and unplug the power cord from the power outlet before installing the memory to prevent hardware damage.

  • Page 12: Back Panel Connectors

    Back Panel Connectors PS/2 Keyboard and PS/2 Mouse Port Use the upper port (green) to connect a PS/2 mouse and the lower port (purple) to connect a PS/2 keyboard. Parallel Port Use the parallel port to connect devices such as a printer, scanner and etc. The parallel port is also called a printer port.
  • Page 13 RJ-45 LAN Port The Gigabit Ethernet LAN port provides Internet connection at up to 1 Gbps data rate. The following describes the states of the LAN port LEDs. Connection/ Connection/Speed LED: Activity LED: Speed LED Activity LED State Description State Description Orange 1 Gbps data rate...

  • Page 14: Internal Connectors

    Internal Connectors ATX_12V F_PANEL F_AUDIO CPU_FAN SPDIF_O SYS_FAN F_USB1/F_USB2 SATA2 0/1/2/3 PWR_LED CLR_CMOS Read the following guidelines before connecting external devices: First make sure your devices are compliant with the connectors you wish to connect. Before installing the devices, be sure to turn off the devices and your computer. Unplug the power cord from the power outlet to prevent damage to the devices.
  • Page 15 1/2) ATX_12V/ATX (2x2 12V Power Connector and 2x12 Main Power Connector) With the use of the power connector, the power supply can supply enough stable power to all the components off and all devices are properly installed. The power connector possesses a foolproof design. Connect the power supply cable to the power connector in the correct orientation.
  • Page 16 3/4) CPU_FAN/SYS_FAN (Fan Headers) The motherboard has a 3-pin CPU fan header (CPU_FAN) and a 4-pin system fan header (SYS_FAN). Most fan headers possess a foolproof insertion design. When connecting a fan cable, be sure to connect it in the correct orientation (the black connector wire is the ground wire). For optimum heat dissipation, it is recommended that a system fan be installed inside the chassis.
  • Page 17 6) PWR_LED (System Power LED Header) This header can be used to connect a system power LED on the chassis to indicate system power status. The LED is on when the system is operating. The LED is off when the system is in S3/S4 sleep state or powered off (S5).
  • Page 18 8) F_PANEL (Front Panel Header) Connect the power switch, reset switch and system status indicator on the chassis to this header according to the pin assignments below. Note the positive and negative pins before connecting the cables. RES+ Power Switch Reset Switch RES- MSG-...
  • Page 19 9) F_AUDIO (Front Panel Audio Header) your chassis front panel audio module to this header. Make sure the wire assignments of the module connector match the pin assignments of the motherboard header. Incorrect connection between the module connector and the motherboard header will make the device unable to work or even damage it. For HD Front Panel Audio: For AC'97 Front Panel Audio: Pin No.
  • Page 20 11) F_USB1/F_USB2 (USB 2.0/1.1 Headers) optional USB bracket. For purchasing the optional USB bracket, please contact the local dealer. Pin No. Power (5V) Power (5V) USB DX- USB DY- USB DX+ USB DY+ No Pin Do not plug the IEEE 1394 bracket (2x5-pin) cable into the USB 2.0/1.1 header. Prior to installing the USB bracket, be sure to turn off your computer and unplug the power cord from the power outlet to prevent damage to the USB bracket.
  • Page 21 13) CLR_CMOS (Clear CMOS Jumper) CMOS values to factory defaults. To clear the CMOS values, use a metal object like a screwdriver to touch the two pins for a few seconds. Open: Normal Short: Clear CMOS Values Always turn off your computer and unplug the power cord from the power outlet before clearing the CMOS values.

  • Page 22: Chapter 2 Bios Setup

    The following screens may appear when the computer boots. A. The LOGO Screen (Default) Function Keys B. The POST Screen Award Modular BIOS v6.00PG, An Energy Star Ally Copyright (C) 1984-2012, Award Software, Inc. GA-E350N D5a Motherboard Model BIOS Version Function Keys 05/31/2012-Zacate-Hudson-7A66EG04C-00 - 21 -...

  • Page 23: The Main Menu

    The Main Menu Once you enter the BIOS Setup program, the Main Menu (as shown below) appears on the screen. Use arrow keys to move among the items and press <Enter> to accept or enter a sub-menu. (Sample BIOS Version: D5a) CMOS Setup Utility-Copyright (C) 1984-2012 Award Software Load Fail-Safe Defaults MB Intelligent Tweaker(M.I.T.)

  • Page 24: Mb Intelligent Tweaker(M.i.t.)

    MB Intelligent Tweaker(M.I.T.) CMOS Setup Utility-Copyright (C) 1984-2012 Award Software MB Intelligent Tweaker(M.I.T.) Item Help Menu Level x CPU Host Clock x Memory Clock x5.33 1066Mhz ******** System Voltage Optimized ******** x DIMM OverVoltage Control Auto Normal CPU Vcore 1.3500V : Move Enter: Select +/-/PU/PD: Value...
  • Page 25 CPU Frequency(MHz) Allows you to manually set the CPU host frequency. Options are 1600MHz. (Default: Normal) CPU Host Clock Control Enables or disables the control of CPU host clock. Auto (default) allows the BIOS to automatically adjust the CPU host frequency. Manual allows the CPU Frequency (MHz) Note: If your system fails to boot after overclocking, please wait for 20 seconds to allow for automated system reboot, or clear the CMOS values to reset the board to default values.
  • Page 26 Row Precharge Time Options are: Auto (default), 5T~14T. Minimum RAS Active Time Options are: Auto (default), 15T~36T. TwTr Command Delay Options are: Auto (default), 4T~8T. Trfc0 for DIMM1 Options are: Auto (default), 90ns, 110ns, 160ns, 300ns, 350ns. Trfc1 for DIMM2 Options are: Auto (default), 90ns, 110ns, 160ns, 300ns, 350ns.

  • Page 27: Standard Cmos Features

    Standard CMOS Features CMOS Setup Utility-Copyright (C) 1984-2012 Award Software Standard CMOS Features Item Help Date (mm:dd:yy) Tue, May 22 2012 Menu Level Time (hh:mm:ss) 22:31:24 IDE Channel 0 M Extended Memory 766M : Move Enter: Select +/-/PU/PD: Value F10: Save ESC: Exit F1: General Help F5: Previous Values...

  • Page 28: Advanced Bios Features

    Advanced BIOS Features CMOS Setup Utility-Copyright (C) 1984-2012 Award Software Advanced BIOS Features Item Help Menu Level : Move Enter: Select +/-/PU/PD: Value F10: Save ESC: Exit F1: General Help F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults The settings in this submenu are synchronous to those under the same items on the MB Intelligent Tweaker(M.I.T.) main menu.

  • Page 29: Integrated Peripherals

    First/Second/Third Boot Device press <Enter> to accept. Options are: LS120, Hard Disk, CDROM, ZIP, USB-FDD, USB-ZIP, USB-CDROM, USB-HDD, Legacy LAN, Disabled. Password Check Set Supervisor/User Password item in the BIOS Main Menu. Setup A password is only required for entering the BIOS Setup program. (Default) System A password is required for booting the system and for entering the BIOS Setup program.
  • Page 30 OnChip SATA Controller Enables or disables the integrated SATA controllers. (Default: Enabled) OnChip SATA Type Native IDE Allows the SATA controllers to operate in Native IDE mode. Enabled Native IDE mode if you wish to install operating systems that support Native mode. (Default) Serial ATA features such as Native Command Queuing and hot plug.

  • Page 31: Power Management Setup

    Onboard Audio Function Enables or disables the onboard audio function. (Default: Enabled) If you wish to install a 3rd party add-in audio card instead of using the onboard audio, set this item to Disabled. USB Controllers Enables or disables the integrated USB controller. (Default: Enabled) Disabled will turn off all of the USB functionalities below.
  • Page 32 ACPI Suspend Type S3(STR) Enables the system to enter the ACPI S3 (Suspend to RAM) sleep state (default). In S3 sleep state, the system appears to be off and consumes less power than in the S1 state. When signaled by a wake-up device or event, the system resumes to its working state exactly where it was left off.

  • Page 33: Pc Health Status

    AC Back Function Determines the state of the system after the return of power from an AC power loss. Soft-Off The system stays off upon the return of the AC power. (Default) Full-On The system is turned on upon the return of the AC power. Memory The system returns to its last known awake state upon the return of the AC power.

  • Page 34: Load Fail-Safe Defaults

    Current Voltage(V) Vcore/DDR15V/+12V/VCC3 Displays the current system voltages. Current System/CPU Temperature Displays current System/CPU temperature. Current CPU/SYSTEM FAN Speed (RPM) Displays current CPU/system fan speed. CPU Warning Temperature Sets the warning threshold for CPU temperature. When CPU temperature exceeds the threshold, BIOS will emit warning sound.

  • Page 35: Set Supervisor/User Password

    2-11 Set Supervisor/User Password CMOS Setup Utility-Copyright (C) 1984-2012 Award Software MB Intelligent Tweaker(M.I.T.) Load Fail-Safe Defaults Standard CMOS Features Load Optimized Defaults Advanced BIOS Features Set Supervisor Password Integrated Peripherals Set User Password Power Management Setup Save & Exit Setup Enter Password: Exit Without Saving PC Health Status...

  • Page 36: Exit Without Saving

    2-13 Exit Without Saving CMOS Setup Utility-Copyright (C) 1984-2012 Award Software MB Intelligent Tweaker(M.I.T.) Load Fail-Safe Defaults Standard CMOS Features Load Optimized Defaults Advanced BIOS Features Set Supervisor Password Quit Without Saving (Y/N)? N Integrated Peripherals Set User Password Power Management Setup Save &...

  • Page 37: Regulatory Statements

    Regulatory Statements Regulatory Notices This document must not be copied without our written permission, and the contents there of must not be imparted to a third party nor be used for any unauthorized purpose. Contravention will be prosecuted. We believe that the information contained herein was accurate in all respects at the time of printing.
  • Page 38 - 37 -...
  • Page 39 - 38 -...
  • Page 40 - 39 -...
  • Page 41 Contact Us GIGA-BYTE TECHNOLOGY CO., LTD. Address: No.6, Bao Chiang Road, Hsin-Tien Dist., New Taipei City 231,Taiwan TEL: +886-2-8912-4000, FAX: +886-2-8912-4003 Tech. and Non-Tech. Support (Sales/Marketing) : http://ggts.gigabyte.com.tw WEB address (English): http://www.gigabyte.com WEB address (Chinese): http://www.gigabyte.tw You may go to the GIGABYTE website, select your language in the language list on the top right corner of the website. GIGABYTE Global Service System To submit a technical or non-technical (Sales/Marketing) question, please link to:...
  • Page 42 Gigabyte GA-E350N Описание Характеристики...
