Front Surround System
Owner's Manual
PDF versions of this manual can be downloaded from the following website.
http://download.yamaha.com/
UAB
Contents
Supplied items ...................................................................... 2
Features ................................................................................. 3
Frequently asked questions................................................. 3
Part names and functions (sound bar) ................................ 4
Installation............................................................................. 5
Connections........................................................................... 6
Digital connection of an external device ...........................................................7
Operations............................................................................. 8
only) ..................................................................................... 10
Settings ................................................................................ 12
control learning function) .................................................................................. 12
Repeater function) ............................................................................................... 14
Setting the auto power standby function ...................................................... 14
Initializing the sound bar ................................................................................ 14
Troubleshooting ................................................................. 15
Specifications ...................................................................... 18
About this manual
• Illustrations used in this manual refer to the YAS-103. Instructions are common to both YAS-103 and
YAS-93, except where otherwise specified, such as "YAS-103 only."
Marks used in this manual
NOTE
This indicates precautions for use of the product and its feature limitations.
HINT
This indicates supplementary explanations for better use.
