3COM BASELINE SWITCH 2250 PLUS DATA SHEET
®
Product Benefits
FEATURES
Outstanding value
Flexible Gigabit uplinks
Browser-based user interface for switch
configuration and administration
VLANs
Link aggregation (trunking)
Traffic monitoring (port mirroring)
Limited Lifetime Warranty and
Advanced Hardware Replacement

Product Features

PERFORMANCE
Switching Capacity
Forwarding Rate
Forwarding Method
LAYER 2 SWITCHING
MAC Addresses
VLAN
Link Aggregation
Auto Negotiation
Traffic Control
CONVERGENCE
Priority Queuing
MANAGEMENT
Device Management
2
BENEFITS
Take advantage of flexible, configurable and powerful switching that costs not much more than an
unmanaged switch.
Choose to daisychain multiple units together via the built-in copper Gigabit uplink ports or connect to a
network backbone via SFP-based fiber modules.
Extremely easy-to-use user interface allows even the most novice users to configure the switch during initial
setup or normal operation.
Segment the network by grouping users based on their data or traffic exchange requirements. This ensures
optimal use of available bandwidth as traffic flow is directed according to the needs of the business.
Group together any number of copper or fiber ports to form an ultra-high bandwidth pipe connecting the
switch to a network backbone and prevent any traffic bottlenecks. The switch supports up to four trunks
and up to eight ports per trunk.
Administrators can examine suspect data streams received on any port by mirroring the data stream to a
monitoring port.
Offerring complete peace of mind.
Description
13.6 Gbps
10.1 Mpps
Store and Forward
8,000 MAC addresses
256 VLAN's (IEEE802.1Q)
Manual as per IEEE802.3ad
Auto-negotiation and Automatic MDI/MDIX on all ports
IEEE802.3x full-duplex flow control
Four hardware queues per port
Weighted round-robin queuing
Web-based configuration for:
• Port, speed, duplex configuration
• VLANs
• Link Aggregation
• Traffic Monitoring
F R E E D O M T O C H O O S E A B E T T E R N E T W O R K
