American Standard Tropic 7028.201 Specification Sheet

GENERAL DESCRIPTION:

Durable cast brass spout and metal lever handles. Cast
brass waterway with one-half inch male inlet shanks and
brass coupling nuts. 1/4 turn washerless ceramic disc
valve cartridges. 20 inch (500mm) long flexible stainless
steel drain cable is pre-assembled to faucet body. Metal
Speed Connect ® drain body with 1-1/4 "
piece. 1.5 gpm/5.7L/min. maximum flow rate.
SUGGESTED SPECIFICATION:
4" centerset lavatory faucet shall feature a cast brass spout and waterway with 1/2" male inlet shanks. Shall feature 1/4 turn
washerless ceramic disc valve cartridges. Shall also feature a metal drain body with stainless steel cable actuation. Fitting
shall be American Standard Model # 7038.201.___.
© 2008 AS America Inc.
244mm
(9-5/8)
101mm
25mm
(1)
102mm
FOR GROUND JOINT
(4)
OR 1/2" O.D. SLIP
CONNECTION
165mm
(6-1/2)
(32mm) tail
TWO-HANDLE CENTERSET LAVATORY FAUCET
MODEL NUMBER:
7038.201 Tropic 2 Handle Centerset
Metal Speed Connect
Metal Lever handles.
122mm
(4-3/4)
(4)

PRODUCT FEATURES:

Cast Brass Spout and Waterway:
prolonged contact with water.
Ceramic Disc Valve Cartridges:
smooth handle operation and drip-free performance.
Low Lead:
Meets NSF Standard 61/Section 9 & Prop 65 lead
requirements.
Exclusive Speed Connect Metal Drain:
• Fewer Parts - installs in less time.
• No adjustments required - seals the first time, every time.
• Flexible stainless steel cable - installs effortlessly in tight spaces.
Simple Installation:
Faucet drops in from top. Quick spin nuts secure faucet in
place.
C81
® pop-up drain.
189mm
(7-1/2)
133mm
(5-1/4)
64mm
(2-1/2)
32mm OD
(1-1/4 OD)
Assure a lifetime of
Fast and easy one person installation.
TROPIC
Durable. Ideal for
