2.5.16 CPU System Agent Voltage Offset Mode Sign [+]
This item allows you to set the CPU system agent voltage offset mode sign. Configuration
options: [+] [‑].
CPU System Agent Voltage Offset [Auto]
This item allows you to set the CPU system agent voltage offset. Increase the value when
increasing DRAM frequency. The values range from 0.001V to 0.999V with a 0.001V interval.
2.5.17 CPU Analog I/O Voltage Offset Mode Sign [+]
This item allows you to set the CPU analog I/O voltage offset mode sign. Configuration
options: [+] [‑].
CPU Analog I/O Voltage Offset [Auto]
This item allows you to set the CPU analog I/O voltage offset. Increase the value when
increasing DRAM frequency. The values range from 0.001V to 0.999V with a 0.001V interval.
2.5.18 CPU Digital I/O Voltage Offset Mode Sign [+]
This item allows you to set the CPU digital I/O voltage offset mode sign. Configuration
options: [+] [‑].
CPU Digital I/O Voltage Offset [Auto]
This item allows you to set the CPU digital I/O voltage offset. Increase the value when
increasing DRAM frequency. The values range from 0.001V to 0.999V with a 0.001V interval.
2.5.19 SVID Support [Auto]
Disabling SVID Support stops the processor from commmunicating with the external voltage
regulator. Configuration options: [Auto] [Disabled] [Enabled].
2.5.20 CPU Input Voltage (VCCIN) [Auto]
This item allows you to set the CPU input voltage. The values range from 0.800V to 2.700V
with a 0.010V interval.
2.5.21 DRAM Voltage [Auto]
Allows you to set the DRAM Voltage. Configuration options: [Auto] [1.20V] [1.35V] [1.40V]
[1.45V] [1.50V] [1.55V] [1.60V] [1.65V] [1.70V] [1.75V] [1.80V]
2.5.22 PCH VLX Voltage [Auto]
Allows you to set the voltage for the I/O on the PCH. Configuration options: [Auto] [+0.10V].
2.5.23 PCH Voltage [Auto]
Allows you to set the Platform Controller Hub voltage. Configuration options: [Auto] [+0.10V].
The system may need better cooling system to work stably under high voltage settings.
