Robertshaw 9615 Specifications

150-1501F.qxd 3/17/04 11:57 AM
Features and Benefits
Quick Connect Wiring
Fast and easy installation. Uses sturdy wire clamps –
no wrap-around of screws.
Automatic Compressor Short Cycle Protection
A system safeguard. Reduces wear and tear of
HVAC equipment.
7 Day Programming
Seven separate daily programs with four time and
temperature changes per day allow maximum flexibility.
QuickSet
TM
Allows 7 days to be programmed all at once.
EER TM (Energy Efficient Recovery)
Increased energy savings. EER
recovery from setback temperature to minimize use
of auxiliary systems.
Worry-Free Memory Storage
Even during power outages, 2"AA" batteries continuously
maintain all program parameters, including time of day.
Adjustable 1st and 2nd Stage Temperature Differential
Maintains optimal customer comfort.
Temporary Program Override
Allows for manual temperature adjustment.
Toll-Free Assistance
Toll-Free Technical Service number printed right on the
thermostat provides immediate assistance.
Page 1
®
allows gradual
TM
9615
G E O
GAS ELECTRIC OIL
7 Day Programmable
2 Heat / 2 Cool
Affordable Comfort Control
The Robertshaw 9615 programmable thermostat is the perfect
solution to keeping your home comfortable year-round. Not only
that, setting back your thermostat twice each day can reduce
energy costs up to 25%. Set it and save. Today's busy lifestyle
demands hands-free temperature control, and with a
programmable thermostat, you've got it. In the QuickSet
set seven daily programs for summer and winter all at once.
Individual days can be customized to match any lifestyle. You
will always come home to a comfortable setting, and you'll save
energy without even thinking about it.
The 9615 is compatible with all standard 24 Volt AC heating
and cooling systems, up to two stage heat and two stage cool.
Green LED indicates auxiliary heat stage operation.
When you select a Robertshaw thermostat, you've made the
choice of an industry partner that's been making quality
products for 100 years. Come home to affordable comfort.
Come home to Robertshaw .
SM
Technical service available:
1-800-445-8299
M-F 7:30 a.m. - 5:30 p.m. CST
PROGRAMMABLE
THERMOSTAT
mode,
TM
BATTERY
OPERATED
