H. Startup
1. All parts are factory-adjusted. Improper adjustments may adversely affect
safety, performance, component life, and warranty coverage.
2. If the icemaker is turned off, wait for at least 3 minutes before restarting the
icemaker to prevent damage to the compressor.
3. At startup, confirm that all internal and external connections are free of leaks.
1) Make sure the power switch is in the "OFF" position, and the icemaker is unplugged.
See Fig. 4.
2) Open the water supply line shut-off valve.
3) Remove the louver and air filter. Move the control switch to the "ICE" position. Replace
the louver and air filter in their correct positions.
4) Plug in the icemaker. Move the power switch to the "ON" position to start the automatic
icemaking process. Once the unit starts to produce ice, allow it to run for another
30 minutes.
5) Dispense all of the ice from the storage bin. Also confirm that the water dispenser is
operating correctly.
6) Move the power switch to the "OFF" position, then unplug the icemaker.
7) Remove the front panel. On the push-button model, disconnect the connector. Remove
the top panel, then remove the bin top. Clean the storage bin liner and actuator using
a neutral cleaner. Rinse thoroughly after cleaning. CAUTION: Be sure to keep the
switch mounted on the bin top dry.
8) Set the bin top in place without fastening it.
Front Panel
Fig. 4
WARNING
Connector
(push-button
model only)
Power Switch
Drain Pan
Power Cord
Top Panel
Bin Top
Actuator
Storage Bin
Agitator
Air Filter
Control Switch
14
Louver
