INSTALLATION, OPERATION AND MAINTENANCE MANUAL
IMPORTANT: PLEASE READ THIS MANUAL BEFORE INSTALLING UNIT
WARNINGS:
DO NOT CONNECT POWER SUPPLY until unit is completely installed.
Make sure electrical service to the fan and light is locked in"OFF" position.
WARNING!
TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR INJURY TO PERSONS –
OBSERVE THE FOLLOWING:
a. Use this unit only in the manner intended by the manufacturer. If you have any questions, contact your
manufacturer's representative.
b. CAUTION: Before installation, servicing or cleaning unit, switch power off at service panel and lock the service
disconnecting means to prevent power from being switched on accidentally. When the service disconnecting
means cannot be locked, securely fasten a prominent warning device, such as tag, to the service panel.
c. Installation work and electrical wiring must be done by qualified person(s) in accordance with all applicable
codes and standards. This unit is only for use in non-fire-rated installations.
d. When cutting or drilling into wall and ceiling, do not damage electrical wiring and other hidden utilities.
e. NEVER place a switch where it can be reached from a tub or shower.
f. If this unit is installed over a tub or shower, it must be connected to a GFCI (Ground Fault Circuit Interrupter) –
protected branch circuit.
g. The combustion airflow needed for safe operation of fuel burning equipment may be affected by this unit's
operation. Follow the heating equipment manufacturer's guidelines and safety standards such as those
published by the National Fire Protection association (NFPA), the American Society of Heating, Refrigeration,
and Air Conditioning Engineers (ASHRAE) and the local code authorities.
h. Exhaust fans must always be vented to the outdoors.
CAUTION: "For General Ventilation Use Only. Do Not Use To Exhaust Hazardous Or Explosive Material and Vapors."
CAUTION: BULB USED IN FLUORESCENT MODELS NOT DIMMABLE
CAUTION: USE ONLY FANTECH (MODEL PBB14) FLUORESCENT BULBS AND
PAR16/MR16 GU10 50W MAX. HALOGEN BULBS (FANTECH MODEL PBB50).
PBW Series
PREMIUM BATH FANS
Single Grille Units
4" Duct
PBW100
PBW100F
PBW100H
Advertisement
Related Manuals for Fantech PBW100
Summary of Contents for Fantech PBW100
- Page 1 CAUTION: "For General Ventilation Use Only. Do Not Use To Exhaust Hazardous Or Explosive Material and Vapors." CAUTION: BULB USED IN FLUORESCENT MODELS NOT DIMMABLE CAUTION: USE ONLY FANTECH (MODEL PBB14) FLUORESCENT BULBS AND PAR16/MR16 GU10 50W MAX. HALOGEN BULBS (FANTECH MODEL PBB50).
-
Page 2: Troubleshooting
Flexible Duct Installation Hints 2. Check motor lead wiring, capacitor leads and incoming supply leads Fantech strongly recommends the use of flexible insulated duct where to insure definite contact. ducting passes through unconditioned space or where noise is a factor. - Page 3 Install appropriate diameter duct from the fan to the ceiling grille housing. (Insulated flexible duct Screw is recommended for all Fantech bathroom exhaust applications for quieter Ring 1 operation.) For dual grille models, install duct between fan and wye adapter* (included).
- Page 4 Limitation of Warranty and Liability This warranty does not apply to any FANTECH INC. product or part which has failed as a result of faulty installation or abuse, incorrect electrical connections or alterations made by others, or use under abnormal operating conditions or misapplication of the product or parts. We will not approve for payment any repair not made by us or our authorized agent without prior written consent.
