Operating Instructions
Outdoor Patio Heater
Model: GGOH100, GGOH200

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GGOH100 and is the answer not in the manual?

Questions and answers

Related Manuals for Goldair GGOH100

Summary of Contents for Goldair GGOH100

  • Page 1 Operating Instructions Outdoor Patio Heater Model: GGOH100, GGOH200...

  • Page 2: Read Me First

    Some edges may be sharp from the manufacturing process and may result in cuts if not handled with care. o Before attempting to assemble your Goldair Patio Heater, ensure all parts are correct and contained within the box as per the components list.

  • Page 3: Gas Leak Testing

    Read Me First Page 2 Gas Leak Testing It is important that you leak test the Patio Heater before first use and every time the gas cylinder is refilled and reconnected to the Patio Heater. To complete a Leak Test: •...

  • Page 4: Purging The Gas Line

    Read Me First Page 3 Purging The Gas Line It is very important to purge the line free from air to get the LPG to the head unit. o Turn off LPG Cylinder. o Disconnect LPG Cylinder. o Turn the gas burner knob on for a minute or so releasing air from the line. o Turn off burner knob.

  • Page 5: Safety Guide

    Safety Guide Page 4 • Do not operate this Patio Heater before reading the instruction booklet • Do not place articles on or against this Patio Heater • Do not use or store flammable or combustible materials, chemicals or spray aerosols near your Patio Heater •...
  • Page 6 Safety Guide Page 5 Always choose a safe location for the Patio Heater, keeping in mind the safety precautions outlined. Ensure all packaging has been removed from the unit before use. NOTE This Patio Heater shall only be used in an above ground open air situation with natural ventilation, without stagnant areas, where gas leakage and products of combustion are...
  • Page 7 Safety Guide Page 6 A strong gas smell or hissing sound of escaping gas indicates a serious problem with the Patio Heater or LPG cylinder. Failure to immediately follow the steps listed below could result in a fire or explosion that could cause serious injury, death or property damage. •...
  • Page 8 Safety Guide Page 7 GAS CYLINDER INFORMATION 1. This Patio Heater is designed to be used with a gas cylinder not exceeding 9KG. 2. The gas cylinder supply valve must be turned off when the Patio Heater is not in use. 3.

  • Page 9: Regulator Connection

    Safety Guide Page 8 REGULATOR CONNECTION 1. Check that the control knob is in the ‘Off’ position. 2. Make sure the cylinder valve is off. 3. Remove the protective cap from the cylinder, if present. 4. Leak test the connection with a soapy water solution (Procedure located on Page 2 of this manual) NOTE 1.
  • Page 10 Safety Guide Page 9 • Proper clearance from combustible materials must be maintained at all times. The minimum clearances is as follows: Perpetual: 700mm Ceiling: 1500mm • Turn off all gas valves including cylinder after use. • Do not allow build up of unburned gas. •...

  • Page 11: Parts Diagram

    Parts Diagram Page 10...

  • Page 12: Assembly Procedure

    Assembly Procedure Page 11 Note: Tools required for assembly - 2 x adjustable spanners, Medium Philips screwdriver Step 1. Put the 3x Support Posts (part#9) in position on the Base (part#10). Use 3x M8 x16mm bolts to join the Support Posts and Base. Step 2.
  • Page 13 Assembly Procedure Page 12 Step 3. Insert gas regulator hose up through the Post with the regulator end at the bottom. Put the Tank Housing (part#8) through the Post (part#7). Ensure the regulator does not fall back inside the Post. Step 4.
  • Page 14 Assembly Procedure Page 13 Step 5. Connect the end of the regulator hose to the bottom of the burner gas inlet thread, tighten with a spanner and conduct a leak test Procedure located on Page 2 of this manual). Fix the burner base to the post by 4x M6 x10mm bolts. Step 6.
  • Page 15 Assembly Procedure Page 14 Step 7. Lay out the 4x pieces of Reflector (part#4) as shown: Step 8. Secure the Reflector pieces one by one with M5 bolts, and nuts. Step 9. Once all four Reflector pieces are together, install a M6 bolt and nut with 2x washers in the centre. Step 10.
  • Page 16 Assembly Procedure Page 15 Step 11. Put the Reflector on top of the Burner and insert 4x Burner/Reflector support bolts. Fit washers into each support bolt and tighten each by M8 castle nut. Step 12. Attach the Wheels by lining up holes in Wheel Bracket with corresponding holes in base. Be sure that the Wheel Assembly is parallel to the base and fully tighten the bolts.
  • Page 17 Assembly Procedure Page 16 Step 13. The Patio Heater is intended to be used with a standard 9kg LPG cylinder. This is the type of cylinder that can be refilled at petrol station or swapped for similar cylinder. Place the cylinder in position into the stand, ensuring that the cylinder sits flush on the ground inside the unit.
  • Page 18 Operating your Patio Heater Page 17 • If the burner makes hissing sounds when lit, it may be burning inside. Turn burner off, allow it to cool and try again. • Close the gas cylinder valve after each use. • Never use the Patio Heater in strong winds •...
  • Page 19 Operating your Patio Heater Page 18 Lighting the Patio Heater Lighting the Patio Heater is easy, but must be done with due care. Make sure that the gas is turned on at the cylinder. Purging the Gas Line If a new tank has just been connected, please allow at least one minute for the air in the gas pipeline to purge out at the High position.
  • Page 20 Operating your Patio Heater Page 19 Turning off To turn the Patio Heater off, it is best to turn the cylinder off first, and allow the gas left in the hose to burn off. This will only take a couple of seconds. Then press in knob control and turn to the OFF position.

  • Page 21: Maintenance

    Maintenance Page 20 • Do not perform any servicing on the Patio Heater yourself. This includes internal adjustment of the regulator and gas valves. Servicing can only be carried out by authorised technicians. Your Patio Heater should be serviced annually by a certified gas service agent.
  • Page 22 Maintenance Page 21 Storing your Patio Heater Your Patio Heater is designed to be used outdoors. However, just like a car, you will prolong the life of the Patio Heater if you store it out of direct exposure to the elements when not in use.
  • Page 23 Maintenance Page 22 On-going Maintenance Your Patio Heater requires regular maintenance (interior and exterior). The use on a Patio Heater cover in conjunction with the instructions below will help to ensure it remains in proper working order and maintains its appearance. Exterior: Stainless Steel Patio Heater’s Overtime dirt and salt may build up on your heater.

  • Page 24: Troubleshooting

    Troubleshooting Page 23...

  • Page 25: One Year Warranty

    Warranty period will be at your are expressly excluded. cost. If your Goldair product fails to operate Consumers Guarantee Act (1993). satisfactorily, please contact Goldair via phone In accordance with the above act, consumers in the first instance.
  • Page 26 TECHNICAL SPECIFICATION Model No: GGOH100, GGOH200 Gas Type: LPG Injector Size: 1.9mm for Main Total Gas Consumption: 14.0 kW Gas Pressure: 2.75kPa SUPPORT AND TECHNICAL ADVICE PO Box 100707, NSMC, Auckland, New Zealand Monday – Friday 8am-5pm Phone: 0800 232 633...
