- Page 1 Operating Instructions Outdoor Patio Heater Model: GGOH300...
-
Page 2: Read Me First
Some edges may be sharp from the manufacturing process and may result in cuts if not handled with care. o Before attempting to assemble your Goldair Patio Heater, ensure all parts are correct and contained within the box as per the components list. -
Page 3: Gas Leak Testing
Read Me First Page 2 Gas Leak Testing It is important that you leak test the Patio Heater before first use and every time the gas cylinder is refilled and reconnected to the Patio Heater. To complete a Leak Test: •... -
Page 4: Purging The Gas Line
Read Me First Page 3 Purging The Gas Line It is very important to purge the line free from air to get the LPG to the head unit. o Turn off LPG Cylinder. o Disconnect LPG Cylinder. o Turn the gas burner knob on for a minute or so releasing air from the line. o Turn off burner knob. -
Page 5: Safety Guide
Safety Guide Page 4 • Do not operate this Patio Heater before reading the instruction booklet • Do not place articles on or against this Patio Heater • Do not use or store flammable or combustible materials, chemicals or spray aerosols near your Patio Heater •... - Page 6 Safety Guide Page 5 Always choose a safe location for the Patio Heater, keeping in mind the safety precautions outlined. Ensure all packaging has been removed from the unit before use. NOTE This Patio Heater shall only be used in an above ground open air situation with natural ventilation, without stagnant areas, where gas leakage and products of combustion are...
- Page 7 Safety Guide Page 6 A strong gas smell or hissing sound of escaping gas indicates a serious problem with the Patio Heater or LPG cylinder. Failure to immediately follow the steps listed below could result in a fire or explosion that could cause serious injury, death or property damage. •...
- Page 8 Safety Guide Page 7 GAS CYLINDER INFORMATION 1. This Patio Heater is designed to be used with a gas cylinder not exceeding 9KG. 2. The gas cylinder supply valve must be turned off when the Patio Heater is not in use. 3.
-
Page 9: Regulator Connection
Safety Guide Page 8 REGULATOR CONNECTION 1. Check that the control knob is in the ‘Off’ position. 2. Make sure the cylinder valve is off. 3. Remove the protective cap from the cylinder, if present. 4. Leak test the connection with a soapy water solution (Procedure located on Page 2 of this manual) NOTE 1. - Page 10 Safety Guide Page 9 • Proper clearance from combustible materials must be maintained at all times. The minimum clearances is as follows: Perpetual: 700mm Ceiling: 1500mm • Turn off all gas valves including cylinder after use. • Do not allow build up of unburned gas. •...
-
Page 11: Parts Diagram
Parts Diagram Page 10... -
Page 12: Assembly Procedure
Assembly Procedure Page 11 Note: Tools required for assembly - 2 x adjustable spanners, Medium Philips screwdriver... - Page 13 Assembly Procedure Page 12 Step 6. The Patio Heater is intended to be used with a standard 9kg LPG cylinder. This is the type of cylinder that can be refilled at petrol station or swapped for similar cylinder. Place the cylinder in position into the stand, ensuring that the cylinder sits flush on the ground inside the unit.
- Page 14 Operating your Patio Heater Page 13 • If the burner makes hissing sounds when lit, it may be burning inside. Turn burner off, allow it to cool and try again. • Close the gas cylinder valve after each use. • Never use the Patio Heater in strong winds •...
- Page 15 Operating your Patio Heater Page 14 Lighting the Patio Heater Lighting the Patio Heater is easy, but must be done with due care. NOTE: White smoke may appear around the radiant head during the first minutes of the initial firing. Make sure that the gas is turned on at the cylinder.
- Page 16 Operating your Patio Heater Page 15 Difficulty lighting If the burner doesn’t light first go, check the gas controls and try a couple more times. If the burner still does not light, wait a few minutes to allow the gas to disperse before trying again.
-
Page 17: Maintenance
Maintenance Page 16 • Do not perform any servicing on the Patio Heater yourself. This includes internal adjustment of the regulator and gas valves. Servicing can only be carried out by authorised technicians. Your Patio Heater should be serviced annually by a certified gas service agent. - Page 18 Maintenance Page 17 Storing your Patio Heater Your Patio Heater is designed to be used outdoors. However, just like a car, you will prolong the life of the Patio Heater if you store it out of direct exposure to the elements when not in use.
- Page 19 Maintenance Page 18 On-going Maintenance Your Patio Heater requires regular maintenance (interior and exterior). The use on a Patio Heater cover in conjunction with the instructions below will help to ensure it remains in proper working order and maintains its appearance. Exterior: Stainless Steel Patio Heater’s Overtime dirt and salt may build up on your heater.
-
Page 20: Troubleshooting
Troubleshooting Page 19... -
Page 21: One Year Warranty
Warranty period will be at your are expressly excluded. cost. If your Goldair product fails to operate Consumers Guarantee Act (1993). satisfactorily, please contact Goldair via phone In accordance with the above act, consumers in the first instance. - Page 22 TECHNICAL SPECIFICATION Model No: GGOH300 Gas Type: LPG Injector Size: 1.6mm for Main Total Gas Consumption: 10.9 kW Gas Pressure: 2.75kPa SUPPORT AND TECHNICAL ADVICE PO Box 100707, NSMC, Auckland, New Zealand Monday – Friday 8am-5pm Phone: 0800 232 633...
