2014 GMC Sierra Denali Owner Manual

In Brief . . . . . . . . . . . . . . . . . . . . . . . . 1-1

Instrument Panel . . . . . . . . . . . . . . 1-2

Initial Drive Information . . . . . . . . 1-4

Vehicle Features . . . . . . . . . . . . . 1-16

Performance and

Maintenance . . . . . . . . . . . . . . . . 1-20

Keys, Doors, and

Windows . . . . . . . . . . . . . . . . . . . . 2-1

Keys and Locks . . . . . . . . . . . . . . . 2-1

Doors . . . . . . . . . . . . . . . . . . . . . . . . . . 2-9

Vehicle Security. . . . . . . . . . . . . . 2-11

Exterior Mirrors . . . . . . . . . . . . . . . 2-13

Interior Mirrors . . . . . . . . . . . . . . . . 2-17

Windows . . . . . . . . . . . . . . . . . . . . . 2-18

Roof . . . . . . . . . . . . . . . . . . . . . . . . . . 2-21

Seats and Restraints . . . . . . . . . 3-1

Head Restraints . . . . . . . . . . . . . . . 3-2

Front Seats . . . . . . . . . . . . . . . . . . . . 3-3

Rear Seats . . . . . . . . . . . . . . . . . . . . 3-8

Safety Belts . . . . . . . . . . . . . . . . . . . . 3-9

Airbag System . . . . . . . . . . . . . . . . 3-18

Child Restraints . . . . . . . . . . . . . . 3-31

Storage . . . . . . . . . . . . . . . . . . . . . . . 4-1

Storage Compartments . . . . . . . . 4-1

Additional Storage Features . . . 4-4

Instruments and Controls . . . . 5-1

Controls . . . . . . . . . . . . . . . . . . . . . . . 5-2

Warning Lights, Gauges, and

Indicators . . . . . . . . . . . . . . . . . . . . 5-8

Information Displays . . . . . . . . . . 5-28

Vehicle Messages . . . . . . . . . . . . 5-31

Vehicle Personalization . . . . . . . 5-41

Universal Remote System . . . . 5-48

Lighting . . . . . . . . . . . . . . . . . . . . . . . 6-1

Exterior Lighting . . . . . . . . . . . . . . . 6-1

Interior Lighting . . . . . . . . . . . . . . . . 6-6

Lighting Features . . . . . . . . . . . . . . 6-8

Infotainment System . . . . . . . . . 7-1

Introduction . . . . . . . . . . . . . . . . . . . . 7-1

Climate Controls . . . . . . . . . . . . . 8-1

Climate Control Systems . . . . . . 8-1

Air Vents . . . . . . . . . . . . . . . . . . . . . . . 8-5

Maintenance . . . . . . . . . . . . . . . . . . . 8-5

Driving and Operating . . . . . . . . 9-1

Driving Information . . . . . . . . . . . . . 9-2

Starting and Operating . . . . . . . 9-23

Engine Exhaust . . . . . . . . . . . . . . 9-32

Automatic Transmission . . . . . . 9-33

Drive Systems . . . . . . . . . . . . . . . . 9-38

Brakes . . . . . . . . . . . . . . . . . . . . . . . 9-45

Ride Control Systems . . . . . . . . 9-48

Cruise Control . . . . . . . . . . . . . . . . 9-51

Driver Assistance Systems . . . 9-54

Fuel . . . . . . . . . . . . . . . . . . . . . . . . . . 9-62

Trailer Towing . . . . . . . . . . . . . . . . 9-67

Conversions and Add-Ons . . . 9-87

Vehicle Care . . . . . . . . . . . . . . . . . 10-1

General Information . . . . . . . . . . 10-2

Vehicle Checks . . . . . . . . . . . . . . . 10-3

Headlamp Aiming . . . . . . . . . . . 10-35

Bulb Replacement . . . . . . . . . . 10-36

Electrical System . . . . . . . . . . . . 10-39

Wheels and Tires . . . . . . . . . . . 10-48

Table of Contents
