D-Link DCS-6513 Features & Specifications

3 megapixel full hd outdoor dome network camera
Hide thumbs Also See for DCS-6513:

Advertisement

Quick Links

Product Highlights
Motorized Lens with P-Iris
Remote zoom and focus adjustment eliminates the
need for on-site lens adjustment, P-Iris motorized iris
control allows precise depth of field adjustment
3 Megapixel Full HD Resolution
The 3 megapixel progressive CMOS sensor captures
all the details with smooth high definition video and
still images
Versatile Installation
Rugged weatherproof housing and a range of
mounting options allow installation in a wide variety
of indoor and outdoor locations
DCS-6513
3 Megapixel Full HD Outdoor Dome Network Camera
Features
Exceptional Video Quality
• 1/2.8" 3 megapixel progressive CMOS sensor
• 3 to 9 mm motorized varifocal lens
• Full HD resolution of 1920 x 1080 and up to
3 megapixel at 2048 x 1536
• P-Iris technology for superior image quality
• Wide Dynamic Range image enhancement
• H.264, MPEG-4, MJPEG codec support for streaming
and recording
Outdoor Placement
• Built-in IR LED illuminator with a 60 feet range for use
in dark areas
• Built-in heating and cooling ensure the camera can
work in a range of climates from -40° to 122°F
• Range of mounting options for flexible placement
• IP67 weatherproof and IK10 anti-vandal
certified housing
• Weather shield to protect unit when surface
mounted outdoors
Flexibility
• microSD/SDHC card slot for onboard storage
• 10/100 Fast Ethernet port with PoE ensures easy
integration into your network
• DI/DO socket for connection to external devices
• Audio in and out jacks can be connected to a
microphone and speaker for 2-way communication
The D-Link DCS-6513 Full HD WDR Day & Night Outdoor Dome Network Camera is a high
definition professional surveillance and security solution suitable for small, medium, and
large enterprises. The camera uses a high-sensitivity 3 megapixel progressive scan CMOS
sensor with a motorized P-Iris varifocal lens and onboard WDR image enhancement to deliver
quality video in all conditions. The all-in-one rugged design makes this camera extremely
reliable and ideal for deployment in virtually any environment.
High-Quality Video
The DCS-6513 is equipped with a P-Iris lens that controls the iris with extreme precision. Its
built-in stepping motor maintains the iris opening at an optimal level at all times, resulting
in superior video quality, clarity, and depth of field, so you can see every minute detail of the
area being monitored. The remote focus function eliminates the need for manual focusing at
the camera location and allows you to make adjustments from any computer. To maximize
bandwidth efficiency and improve image quality, the DCS-6513 provides real-time video
compression using the H.264, MPEG-4 and MJPEG codecs, and supports three separate
profiles for simultaneous video streaming and recording. This versatility enables a wide
variety of security applications, such as monitoring public areas to detect incidents and to
coordinate responses, enforcing access control to restricted areas, deterring criminal activity,
or monitoring inventory. Furthermore, bandwidth requirements can be adjusted in real-time
over the network, and recorded video files can be saved to a network attached storage (NAS)
device or microSD card.

Advertisement

loading

Summary of Contents for D-Link DCS-6513

  • Page 1 DCS-6513 3 Megapixel Full HD Outdoor Dome Network Camera Features The D-Link DCS-6513 Full HD WDR Day & Night Outdoor Dome Network Camera is a high definition professional surveillance and security solution suitable for small, medium, and Exceptional Video Quality large enterprises.
  • Page 2 In addition, the included slides out of the way to use all available light. The DCS-6513 also has built-in IR digital input and output connector enables connections to external devices such LED illuminators with a 60 feet range, allowing the camera to keep watch even in as IR sensors, switches and alarm relays.
  • Page 3 DCS-6513 3 Megapixel Full HD Outdoor Dome Network Camera Network Network Protocols • IPv6 • HTTP / HTTPS • IPv4 • Samba client • TCP/IP • PPPoE • UDP • UPnP port forwarding • ICMP • RTP / RTSP/ RTCP • IP filtering • DHCP client • NTP client (D-Link) • QoS • CoS • DNS client • DDNS client (D-Link) • Multicast • SMTP client • IGMP • FTP client • ONVIF compliant Security • Administrator and user group protection • HTTP and RTSP digest encryption • Password authentication System Management System Requirements for Web Interface • Browser: Microsoft Internet Explorer 7 or higher, Firefox 1.5 or higher, or other Java-enabled browser...
  • Page 4: For More Information

    DCS-6513 3 Megapixel Full HD Outdoor Dome Network Camera Order Information Part Number Description DCS-6513 Full HD WDR Day & Night Outdoor Dome Network Camera Optional Accessories Part Number Description DCS-34-2 Pendant Mount: 7.9 x 5.9 inches (201 x 150 mm), 1.45 lbs (665 grams) DCS-34-3 Wall Mount: 9.96 x 5.9 inches (253 x 150 mm), 1.7 lbs (770 grams) For more information U.S.A. | 17595 Mt. Herrmann Street | Fountain Valley, CA 92708 | 800.326.1688 | dlink.com Canada | 2525 Meadowvale Blvd | Mississauga, ON L5N 5S2 | 800.361.5265 | dlink.ca ©2011 D-Link Corporation/D-Link Systems, Inc. All rights reserved. D-Link, D-Link logo, and the D-ViewCam™ logo are registered trademarks of D-Link Corporation or its subsidiaries in the United States and/or other countries. Other trademarks or registered trademarks are the property of...
