Other Features - Icom IC-M506 Specifications

ombo
ITU Class D DSC (Meets ITU-R M493-13)
The built-in DSC watch function monitors Ch. 70 (DSC chan-
BUILT-IN
CLASS D DSC
nel) activity, even while you are receiving another channel.
DSC functions include: distress, individual, group, all ships, ur-
gency, safety, position request/report, polling request and DSC
test calls. Up to 100 DSC address IDs can be programmed.
Rear Microphone Version*
With this version, the microphone connector is drawn from
REAR MICROPHONE
VERSION
the rear panel and a 6.1m (20ft) microphone extension cable
is supplied to allow
you clean and neat
panel installation.
* Ask your dealer for de-
tails.
IPX8 Submersible Plus
The IC-M506 and supplied HM-205B/RB microphone can
IPX8
SUBMERSIBLE PLUS
withstand 1m (3.2ft) depth of water for 60 minutes.

Other Features

• Auto and manual foghorn function
• Simple remote control speaker-microphone, HM-205B/RB
• 15W audio output power (with external speaker)
• Weather channels with alert function (USA version only)
• AquaQuake™ draining function
• Optional voice scrambler, UT-112 for private conversation
• MA-500TR AIS transponder and MarineCommander™ compatible
* AIS receiver and NMEA 2000 interface units are options, depend- * AIS receiver and NMEA 2000 interface units are options, depend-
ing on version. ing on version.
Optional COMMANDMIC
Full Control and Intercom
The optional COMMANDMIC, HM-195B/
SW provides 2nd station capability for
FULL CONTROL
using the IC-M506 from up to 18.3m (60ft)*
away such as a separate cabin or tower.
Most functions including DSC and AIS
functions can be controlled from the COM-
MANDMIC and can be used as an inter-
com with the IC-M506.
* Two optional OPC-1541 extension cables required.
IPX7 Submersible Construction
The HM-195B/SW withstands submersion
IPX7
SUBMERSIBLE in up to 1m (3.2ft) depth of water for 30
minutes.
™
for 2nd Station Capability
™
Same Menu-Driven
User Interface with IC-M506
NEW INTERFACE
The HM-195B/SW provides same user in-
terface with the IC-M506. The directional
keypad and softkey buttons allow you to
perform various operations and settings.
The audio and backlight levels can be set
independently from the IC-M506.
Other Features
• External speaker connection
• Black and super white color version
• Remote power ON/OFF function
• One COMMANDMIC can be used
"Distress" button on
the back of the unit
