17" Color Lcd Display With Clearmotiv™ Technology; Specifications; Features; Setup - ViewSonic OptiSync VX710 Specifications

17" OptiSync
1
2
3
1.
Sleek buttons control all major functions
2.
Extended neck, floating head design
3.
Space-saving slim-line panel design is only 2.4" thick
4.
Slim bezel, attractive styling
Available colors:
Black & silver
ViewSonic Corporation's QMS & EMS have been registered to
ISO 9001 & ISO 14001, respectively, by the British Standards Institution.
ViewSonic Corporation • 381 Brea Canyon Road, Walnut, CA 91789
Phone (800) 888-8583 or (909) 444-8888 • In Canada (866) 262-1967 • Fax (909) 839-7922 • SalesInfo@ViewSonic.com • ViewSonic.com
*Leading stand-alone, branded monitor by sales (CRT and LCDs combined; iSuppli/Stanford Resources Monitrak
vary by country; see your ViewSonic representative for complete details. Corporate names, trademarks stated herein are the property of their respective companies. Copyright © 2005 ViewSonic Corporation. All rights reserved. [12291-00B-01/05] VX710-1
For more product information, visit us on the web at ViewSonic.com
710
VX LCD Display
®
Slim Bezel Display
17" COLOR LCD DISPLAY WITH CLEARMOTIV™ TECHNOLOGY
LCD
INPUT SIGNAL
COMPATIBILITY PC
CONNECTOR
POWER
CONTROLS
4
OPERATING
CONDITIONS
DIMENSIONS
(W x H x D)
WEIGHT
REGULATIONS
POWER MANAGEMENT
PACKAGE CONTENTS
WARRANTY
® and Flat Panel Monitrak, ®
Type 17" Color TFT Active Matrix SXGA LCD
Display Area 13.3" horizontal x 10.6" vertical; 17.0" diagonal
Optimum Resolution 1280x1024
Contrast Ratio 450:1 (typ)
Viewing Angles 160° horizontal, 160° vertical @ contrast ratio > 5
Response Time 16ms (typ)
Light Source Long life, 40,000 hrs. (typ)
Brightness 260 cd/m2 (typ)
Panel Surface Anti-glare
Video RGB analog (75 ohms, 0.7 Vp-p); DVI-D (TMDS, 100 ohms)
Sync H/V separated (TTL), composite, sync-on-green
Frequency F h :24~82kHz, F v :50~85Hz
VGA up to 1280x1024 non-interlaced
Mac ** Power Mac™ G3/G4 1280x1024
®
Analog 15-pin mini D-sub and DVI-D
Power 3-pin AC plug, (CEE22)
Voltage AC 100–240V, 50–60Hz (auto switch)
Consumption 35W (max)
Basic Power, 1, down, up, 2
®
OnView Auto image adjust, brightness, contrast, ViewMatch
9300K, 6500K(default), 5400K, user color (RGB), input select (analog, digi-
tal), information (resolution, H. frequency, V. frequency, pixel clock, model
number, serial number, manual image adjust (H. size, H. position, V. posi-
tion, fine tune, sharpness, scaling, setup menu, language (English, French,
German, Italian, Spanish, Finnish, Japanese, Traditional Chinese, Simplified
Chinese), input priority, resolution notice, OSD position, OSD timeout, OSD
background, touch tone, OSD pivot, memory recall
Temperature 32°—104°F (0°—40°C)
Humidity 10—90% (no condensing)
Physical 388mm x 438mm x 177mm (with stand)
15.3" x 17.2" x 7.0" (with stand)
388mm x 332mm x 62mm (without stand)
15.3" x 13.1" x 2.4" (without stand)
Net 11.0 lb. (5.0 kg) (with stand)
Gross 16.8 lb. (7.6 kg) (with stand)
UL, cUL, FCC-B, CB, CE, ENERGY, NOM, NEMKO/GS(covers TUV/GS),
NEMKO ERGO (covers TUV/ERGO, ISO13406-2 & MPR II), TCO'99, GOST-R
20 original copies hygienic, (SASO), PCBC, VCCI, BSMI, CCC, (PSB), (C-TICK),
Argentina-S, PSE (power adapter), Green Mark
Meets TCO'99 and ENERGY standards
LCD display, power cable, Quick Start Guide, ViewSonic Wizard CD,
15-pin VGA video cable
One-year limited warranty on parts, labor and backlight for units purchased
in the U.S. only. Three-year limited warranty on units purchased outside of
the U.S.
4Q04 Report) **Adapter may be required. Analog adapter available from ViewSonic. Specifications subject to change without notice. Selection, offers and programs may
®
color adjust (SRGB,
