Sharp VC-A560UA Service Manual
  1. Manuals
  2. Brands
  3. Sharp Manuals
  4. VCR
  5. VC-A560UA
  6. Service manual

Sharp VC-A560UA Service Manual

Sharp vcr service manual
Hide thumbs Also See for VC-A560UA:

Advertisement

Table of Contents

VC-A560U(A)/A560U/A560U(B)
VC-H960U/H960U(B)
VC-H961U
1. GENERAL INFORMATION ........................................................................................................... 5
2. DISASSEMBLY AND REASSEMBLY ........................................................................................... 7
3. FUNCTION OF MAJOR MECHANICAL PARTS ......................................................................... 10
5. ELECTRICAL ADJUSTMENT ..................................................................................................... 30
6. MECHANISM OPERATION FLOWCHART AND TROUBLESHOOTING GUIDE ...................... 32
7. TROUBLESHOOTING ................................................................................................................ 38
8. BLOCK DIAGRAM....................................................................................................................... 50
9. SCHEMATIC DIAGRAM AND PWB FOIL PATTERN ................................................................. 58
10. REPLACEMENT PARTS LIST .................................................................................................... 71
11. EXPLODED VIEW OF MECHANICAL PARTS ........................................................................... 80
12. PACKING OF THE SET .............................................................................................................. 85
VC-A560U(A)/A560U/A560U(B)/H960U/H960U(B) ................. Models for U.S.A
SHARP CORPORATION
SERVICE MANUAL
MODELS
In the interests of user-safety (Required by safety regula-
tions in some countries) the set should be restored to its
original condition and only parts identical to those specified
be used.
CONTENTS
VC-H961U ...................... Models for Canada
This document has been published to be used for
after sales service only.
The contents are subject to change without notice.
1
VC-A560U(A)/A560U/A560U(B)
VC-H960U/H960U(B)/H961U
VIDEO CASSETTE RECORDER
VC-A560U(A)
VC-A560U/A560U(B)
VC-H960U/H960U(B)
VC-H961U
S41R7VC-A411U
Page

Advertisement

Table of Contents
loading

Related Manuals for Sharp VC-A560UA

Summary of Contents for Sharp VC-A560UA

  • Page 1: Table Of Contents

    12. PACKING OF THE SET ......................85 VC-H961U ...... Models for Canada VC-A560U(A)/A560U/A560U(B)/H960U/H960U(B) ....Models for U.S.A This document has been published to be used for SHARP CORPORATION after sales service only. The contents are subject to change without notice.
  • Page 2 VC-A560U(A)/A560U/A560U(B) VC-H960U/H960U(B)/H961U IMPORTANT SERVICE NOTES etc.) and measure the AC voltage drop across the BEFORE RETURNING THE VIDEO CASSETTE resistor. Reverse the AC plug on the set and repeat RECORDER AC voltage measurements for each exposed part. Before returning the video cassette recorder to the user, Any reading of 0.45V rms (this corresponds to 0.3mA perform the following safety checks.
  • Page 3 VC-A560U(A)/A560U/A560U(B) VC-H960U/H960U(B)/H961U NOTES DE SERVICE IMPORTANTES AVANT DE RENDRE LE MAGNETOSCOPE pièces métalliques exposées ayant un parcours de retour au châssis (connexions d’antenne, coffret Avant de rendre le magnétoscope à l’utilisateur, effectuer métallique, tétes de vis, boutons et arbres de commande, etc.) et mesurer la chute de tension CA les vérifications de sécurité...
  • Page 4 VC-A560U(A)/A560U/A560U(B) VC-H960U/H960U(B)/H961U PRECAUTIONS IN PART REPLACEMENT When servicing the unit with power on, be careful to the section marked white all over. This is the primary power circuit which is live. When checking the soldering side in the tape travel mode, make sure first that the tape has been loaded and then turn over the PWB with due care to the primary power circuit.

  • Page 5: General Information

    • Simple Recording Timer • Hi-Fi Stereo Sound • Universal Remote Control • Built-in MTS (Multi-channel TV Sound) Decoder • Sharp Super Picture Only for VC-H961U • 5 sec. Timer Backup • Built-in Front AV Jacks • Field-Still/Variable Slow/Frame Advance •...
  • Page 6 VC-A560U(A)/A560U/A560U(B) VC-H960U/H960U(B)/H961U 1-3 LOCATION OF MAJOR COMPONENTS AND CONTROL...

  • Page 7: Disassembly And Reassembly

    VC-A560U(A)/A560U/A560U(B) VC-H960U/H960U(B)/H961U 2. DISASSEMBLY AND REASSEMBLY 2-1 DISASSEMBLY OF MAJOR BLOCKS TOP CABINET : Remove 2 screws 1. TOP CABINET : Remove 2 screws 2 and 7 clips 3. FRONT PANEL : Remove 1 screw 4. OPERATION SHIELD ANGLE : Remove 1 screw 5 with shield angle. : Remove 1 screw 6, 2 screws 7.
  • Page 8 VC-A560U(A)/A560U/A560U(B) VC-H960U/H960U(B)/H961U 2-2 DISASSEMBLING THE MECHANISM/MAIN PWB ASSEMBLY 2. Removing the mechanism and cassette housing. 1. When removing the mechanism from the main PWB, Remove 2 screws 3 fixing the cassette housing to the remove the antenna cover 1 screw 1, and remove the mechanism, and remove the cassette housing.
  • Page 9 VC-A560U(A)/A560U/A560U(B) VC-H960U/H960U(B)/H961U 2-3 CARES WHEN REASSEMBLING INSTALLING THE CASSETTE HOUSING 2. Mechanical initial setting When the cassette housing is installed on the mechanism, After ascertaining the return to the initial set position install the initial setting is essential condition. the cassette housing in the specified position. (This method There are two initial setting methods, namely electrical and is applied only for the mechanism.) mechanical.

  • Page 10: Function Of Major Mechanical Parts

    VC-A560U(A)/A560U/A560U(B) VC-H960U/H960U(B)/H961U 3. FUNCTION OF MAJOR MECHANICAL PARTS (TOP VIEW) Function Function Full erase head A/C head ass’y Supply pole base ass’y Reverse guide lever ass’y Tension arm Reel relay gear Idler wheel ass’y Take-up reel disk Open guide Pinch roller lever ass’y Supply reel disk Drum ass'y Supply main brake...
  • Page 11 VC-A560U(A)/A560U/A560U(B) VC-H960U/H960U(B)/H961U FUNCTION OF MAJOR MECHANICAL PARTS (BOTTOM VIEW) Function Function Syncro Gear Clutch lever Master cam Limiter pulley ass’y Capstan D.D. motor Shifter Reel belt...

  • Page 12: Adjustment, Replacement And Assembly Of Mechanical Units

    VC-A560U(A)/A560U/A560U(B) VC-H960U/H960U(B)/H961U 4. ADJUSTMENT, REPLACEMENT AND ASSEMBLY OF MECHANICAL UNITS The explanation given below relates to the on-site general service (field service) but it does not relates to the adjustment and replacement which need high-grade equipment, jigs and skill. For example, the drum assembling, replacement and adjustment service must be performed by the person who have finished the technical courses.
  • Page 13 VC-A560U(A)/A560U/A560U(B) VC-H960U/H960U(B)/H961U 4-2 MAINTENANCE CHECK ITEMS AND EXECUTION TIME Perform the maintenance with the regular intervals as follows so as to maintain the quality of machine. Maintained 1000 1500 2000 Possible symptom Remarks hrs. hrs. hrs. hrs. encountered Parts Abnormal rotation or significant Guide roller ass’y vibration requires replacement.
  • Page 14 VC-A560U(A)/A560U/A560U(B) VC-H960U/H960U(B)/H961U 4-3 REMOVING AND INSTALLING THE CAS- Notes: SETTE HOUSING 1. In the case when you use the magnet screw driver, never approach the magnet driver to the A/C head, FE head, • Removal and drum. 1. In the cassette removing mode, remove the cassette. 2.
  • Page 15 VC-A560U(A)/A560U/A560U(B) VC-H960U/H960U(B)/H961U 4-5 REEL DISK REPLACEMENT AND HEIGHT Notes: CHECK 1. When installing the reel disk, take due care so that the • Removal tension band ass'y is not deformed and grease does no 1. Remove the cassette housing control assembly. adhere.
  • Page 16 VC-A560U(A)/A560U/A560U(B) VC-H960U/H960U(B)/H961U Note: Notes: Whenever replacing the reel disk, perform the height check- 1. Hold the torque gauge by hand so that it is not moved. ing and adjustment. 2. Do not keep the reel disk in lock state. Do not allow long- time measurement.
  • Page 17 VC-A560U(A)/A560U/A560U(B) VC-H960U/H960U(B)/H961U Notes: 4-9 CHECKING AND ADJUSTMENT OF TAKE- 1. Hold the torque gauge by hand so that it is not moved. UP TORQUE IN VIDEO SEARCH REWIND 2. Do not keep the reel disk in lock state. Do not allow long- MODE time measurement.
  • Page 18 VC-A560U(A)/A560U/A560U(B) VC-H960U/H960U(B)/H961U 4-10 CHECKING THE VIDEO SEARCH REWIND BACK TENSION • Remove the cassette housing control assembly. • After short-circuiting between TP803 and TP802 Tension gauge Pinch roller provided at operation PWB, plug in the power cord. 900 - 1,200gf •...
  • Page 19 VC-A560U(A)/A560U/A560U(B) VC-H960U/H960U(B)/H961U 2. Visually check to see if the position of the tension pole is Tension pole adjustment driver adjusting direction within the 0 ± 0.2mm from the left side line. Standard A = 0 ± 0.2mm Tension pole adjustment driver Make the adjustment with the beginning of a T-120 tape.
  • Page 20 VC-A560U(A)/A560U/A560U(B) VC-H960U/H960U(B)/H961U • Adjustment • Checking the brake torque at the take-up side 1. If the indication of torque cassette meter is lower than the setting, shift the tension spring engagement to the part A. Torque gauge 2. If the indication of torque cassette meter is higher than the setting, shift the tension spring engagement to the part B.
  • Page 21 VC-A560U(A)/A560U/A560U(B) VC-H960U/H960U(B)/H961U 4-15 REPLACEMENT OF A/C (AUDIO/CONTROL) 3. Align the left end of gear of A/C head arm with the punched mark of chassis, tentatively tighten the screws HEAD 1 so as to ensure smooth motion of A/C head arm. 1.
  • Page 22 VC-A560U(A)/A560U/A560U(B) VC-H960U/H960U(B)/H961U 4-16 A/C HEAD HEIGHT ROUGH ADJUSTMENT 4-17 ADJUSTMENT OF TAPE DRIVE TRAIN 1. Tape run rough adjustment 1 Remove the cassette housing control assembly. • Setting Azimuth screw 2 After shortcircuiting between TP803 and TP802 pro- vided at operation PWB, plug in the power cord. 3 Check and adjust the position of the tension pole.
  • Page 23 VC-A560U(A)/A560U/A560U(B) VC-H960U/H960U(B)/H961U Notes: 1. Previously set the tracking control in the center position, and adjust the ATR signal waveform to maximum with X value adjustment nut. Thereby the tape run rough ad- justment is facilitated. 2. Especially the outlet side ATR signal waveform must have higher flatness.
  • Page 24 VC-A560U(A)/A560U/A560U(B) VC-H960U/H960U(B)/H961U 3 Next, press the tracking button (+), (–) and change the ATR signal waveform from max to min and from PB ATR min to max. At this time adjust the height of supply Signal and take-up side guide roller with the adjustment driver (JiGDRiVERH-4) so that the ATR signal wave- form changes nearly parallel.
  • Page 25 VC-A560U(A)/A560U/A560U(B) VC-H960U/H960U(B)/H961U 4-19 REPLACEMENT OF DRUM D.D. MOTOR 4-18 REPLACEMENT OF THE CAPSTAN D.D. 1. Set the ejection mode. (DIRECT DRIVE) MOTOR 2. Withdraw the main power plug from the socket. • Remove the mechanism from the main PWB (refer to 2- 2 item 1 When removing the mechanism from the main •...
  • Page 26 VC-A560U(A)/A560U/A560U(B) VC-H960U/H960U(B)/H961U 4-20 REPLACING THE UPPER AND LOWER 4-21 ASSEMBLING OF PHASE MATCHING DRUM ASSEMBLY MECHANISM COMPONENTS • Assemble the phase matching mechanism compo- • Replacement (Perform in the numerical order) nents in the following order. 1 Remove the motor as stated in 4-19 D.D. motor replace- 1.
  • Page 27 VC-A560U(A)/A560U/A560U(B) VC-H960U/H960U(B)/H961U 1. Make sure that the loading arm T and S are at the Phase- 4-22 INSTALLING THE SHIFTER Matching point as shown below 2. Fix the shifter position setting part to the roading arm T Drum position setting part as shown in figure 3.
  • Page 28 VC-A560U(A)/A560U/A560U(B) VC-H960U/H960U(B)/H961U 4-23 INSTALLING THE MASTER CAM (AT 4-24 REPLACEMENT OF LOADING MOTOR • Removal REAR SIDE OF MECHANISM CHASSIS) 1. Make sure beforehand that the shifter is at initial posi- tion. 2. Place the master cam in the position as shown below. E-ring Apply grease *Apply grease to...
  • Page 29 VC-A560U(A)/A560U/A560U(B) VC-H960U/H960U(B)/H961U 4-25 ASSEMBLY OF CASSETTE HOUSING 1. Proof lever Proof lever spring and Holder R MSPRD0215AJFJ *Proof lever spring fixing direction designated. Figure 4-41. 2. Frame R, Frame L, Drive Arm R, Drive Arm L, Upper Plate. LANGF9661AJFW Top surface should be free from scratches or soil.

  • Page 30: Electrical Adjustment

    VC-A560U(A)/A560U/A560U(B) VC-H960U/H960U(B)/H961U 5. ELECTRICAL ADJUSTMENT Notes: • Before the adjustment: Electrical adjustments discussed here are often required after replacement of electronic components and mechanical parts such as video heads. Check that the mechanism and all electric components are in good working condition prior to the adjustments, otherwise adjustments cannot be completed.
  • Page 31 VC-A560U(A)/A560U/A560U(B) VC-H960U/H960U(B)/H961U SERVO CIRCUIT ADJUSTMENT 5-2 ADJUSTMENT OF FV (False Vertical Sync) OF STILL PICTURE 5-1 ADJUSTMENT OF HEAD SWITCHING Measuring Color TV monitor POINT instrument Measuring Dual-trace oscilloscope Mode Playback still instrument Cassette Self-recorded tape (SP mode) Mode Playback (See Note below 2) Cassette Alignment tape (VROEFZHS)
  • Page 32 VC-A560U(A)/A560U/A560U(B) VC-H960U/H960U(B)/H961U...
  • Page 33 VC-A560U(A)/A560U/A560U(B) VC-H960U/H960U(B)/H961U...
  • Page 34 VC-A560U(A)/A560U/A560U(B) VC-H960U/H960U(B)/H961U...
  • Page 35 VC-A560U(A)/A560U/A560U(B) VC-H960U/H960U(B)/H961U...
  • Page 36 VC-A560U(A)/A560U/A560U(B) VC-H960U/H960U(B)/H961U...
  • Page 37 VC-A560U(A)/A560U/A560U(B) VC-H960U/H960U(B)/H961U...
  • Page 38 VC-A560U(A)/A560U/A560U(B) VC-H960U/H960U(B)/H961U...
  • Page 39 VC-A560U(A)/A560U/A560U(B) VC-H960U/H960U(B)/H961U...
  • Page 40 VC-A560U(A)/A560U/A560U(B) VC-H960U/H960U(B)/H961U...
  • Page 41 VC-A560U(A)/A560U/A560U(B) VC-H960U/H960U(B)/H961U...
  • Page 42 VC-A560U(A)/A560U/A560U(B) VC-H960U/H960U(B)/H961U...
  • Page 43 VC-A560U(A)/A560U/A560U(B) VC-H960U/H960U(B)/H961U...
  • Page 44 VC-A560U(A)/A560U/A560U(B) VC-H960U/H960U(B)/H961U...
  • Page 45 VC-A560U(A)/A560U/A560U(B) VC-H960U/H960U(B)/H961U...
  • Page 46 VC-A560U(A)/A560U/A560U(B) VC-H960U/H960U(B)/H961U...
  • Page 47 VC-A560U(A)/A560U/A560U(B) VC-H960U/H960U(B)/H961U...
  • Page 48 VC-A560U(A)/A560U/A560U(B) VC-H960U/H960U(B)/H961U...
  • Page 49 VC-A560U(A)/A560U/A560U(B) VC-H960U/H960U(B)/H961U - M E M O -...

  • Page 50: Block Diagram

    VC-A560U(A)/A560U/A560U(B) VC-A560U(A)/A560U/A560U(B) VC-H960U/H960U(B)/H961U VC-H960U/H960U(B)/H961U 8. BLOCK DIAGRAM SYSTEM SERVO BLOCK DIAGRAM 50~51...
  • Page 51 VC-A560U(A)/A560U/A560U(B) VC-A560U(A)/A560U/A560U(B) VC-H960U/H960U(B)/H961U VC-H960U/H960U(B)/H961U SIGNAL FLOW BLOCK DIAGRAM(VC-A560U(A)/A560U/A560U(B)) 52~53...
  • Page 52 VC-A560U(A)/A560U/A560U(B) VC-A560U(A)/A560U/A560U(B) VC-H960U/H960U(B)/H961U VC-H960U/H960U(B)/H961U SIGNAL FLOW BLOCK DIAGRAM(VC-H960U/H960U(B)/H961U) 54~55...
  • Page 53 VC-A560U(A)/A560U/A560U(B) VC-H960U/H960U(B)/H961U POWER CIRCUIT BLOCK DIAGRAM...

  • Page 54: Schematic Diagram

    VC-A560U(A)/A560U/A560U(B) VC-H960U/H960U(B)/H961U SCHEMATIC DIAGRAM • The indicated voltages in the following diagram IMPORTANT SAFETY NOTICE: are measured with an SSVM, upon receiving color bars (400 Hz sound signal) in either the PARTS MARKED WITH " å " ( ) ARE record mode or the play mode voltage is indi- IMPORTANT FOR MAINTAINING THE SAFETY cated as follows.

  • Page 55: Schematic Diagram And Pwb Foil Pattern

    VC-A560U(A)/A560U/A560U(B) VC-A560U(A)/A560U/A560U(B) VC-H960U/H960U(B)/H961U VC-H960U/H960U(B)/H961U 9. SCHEMATIC DIAGRAM AND PWB FOIL PATTERN MAIN CIRCUIT(1) * VOLTAGE MEASUREMENT MODE PB ..Parentheses ( REC ..Without Parentheses 58~59...
  • Page 56 VC-A560U(A)/A560U/A560U(B) VC-A560U(A)/A560U/A560U(B) VC-H960U/H960U(B)/H961U VC-H960U/H960U(B)/H961U MAIN CIRCUIT(2) * VOLTAGE MEASUREMENT MODE PB ..Parentheses ( REC ..Without Parentheses 60~61...
  • Page 57 VC-A560U(A)/A560U/A560U(B) VC-A560U(A)/A560U/A560U(B) VC-H960U/H960U(B)/H961U VC-H960U/H960U(B)/H961U MAIN CIRCUIT(3) * VOLTAGE MEASUREMENT MODE PB ..Parentheses ( REC ..Without Parentheses 62~63...
  • Page 58 VC-A560U(A)/A560U/A560U(B) VC-A560U(A)/A560U/A560U(B) VC-H960U/H960U(B)/H961U VC-H960U/H960U(B)/H961U MAIN CIRCUIT(4) * VOLTAGE MEASUREMENT MODE PB ..Parentheses ( REC ..Without Parentheses 64~65...
  • Page 59 VC-A560U(A)/A560U/A560U(B) VC-H960U/H960U(B)/H961U OPERATION CIRCUIT * VOLTAGE MEASUREMENT MODE PB ..Parentheses ( REC ..Without Parentheses...
  • Page 60 VC-A560U(A)/A560U/A560U(B) VC-H960U/H960U(B)/H961U PWB FOIL PATTERN OPERATION PWB...
  • Page 61 VC-A560U(A)/A560U/A560U(B) VC-A560U(A)/A560U/A560U(B) VC-H960U/H960U(B)/H961U VC-H960U/H960U(B)/H961U MAIN PWB 68~69...
  • Page 62 VC-A560U(A)/A560U/A560U(B) VC-H960U/H960U(B)/H961U - M E M O -...

  • Page 63: Replacement Parts List

    Pour que votre commande soit rapidement et correctement remplie, 3. PART NO. 4. DESCRIPTION veuillez fournir les renseignements suivants. in USA : Contact your nearest SHARP Parts Distributor to order. 1. NUMERO DU MODELE 2. NO. DE REF For location of SHARP Parts Distributor, Please Call Toll-free;...
  • Page 64 VC-A560U(A)/A560U/A560U(B) VC-H960U/H960U(B)/H961U Ref. No. Part No. Description Code Ref. No. Part No. Description Code å L934 TRANSISTORS RCiLP0147GEZZ Coil, CiLP0147GE Q251 VS2SA1530ARS1 V 2SA1530AR TRANSFORMERS Q602 VS2SC3203Y/-1 V 2SC3203Y Q603 VS2SC3052EF-1 V 2SC3052EF T601 RTRNH0098GEZZ J OSC. Transformer Q604 VSKRA103S//-1 V KRA103S (VC-A560U/A560U(A)/ Q605...
  • Page 65 VC-A560U(A)/A560U/A560U(B) VC-H960U/H960U(B)/H961U Ref. No. Part No. Description Code Ref. No. Part No. Description Code C221 VCEA9M1CW106M V 10 16V Electrolytic C622 VCKYCY1HB222K V 2200p 50V Ceramic C223 VCKYCY1CF104Z V 0.1 16V Ceramic (VC-A560U/A560U(A)/ C227 VCKYCY1CF104Z V 0.1 16V Ceramic A560U(B)) C252 VCEA0A0JW337M V 330 6.3V Electrolytic...
  • Page 66 VC-A560U(A)/A560U/A560U(B) VC-H960U/H960U(B)/H961U Ref. No. Part No. Description Code Ref. No. Part No. Description Code C9335 VCEA9M1HW104M V 0.1 50V Electrolytic C685 VCCCCY1HH560J V 56p 50V Ceramic C9336 VCEA9M1HW104M V 0.1 50V Electrolytic (VC-H960U/H960U(B)/ H961U) RESISTORS C702 VCEA9M0JW476M V 47 6.3V Electrolytic C703 VCKYCY1CF104Z V 0.1 16V Ceramic...
  • Page 67 VC-A560U(A)/A560U/A560U(B) VC-H960U/H960U(B)/H961U Ref. No. Part No. Description Code Ref. No. Part No. Description Code R668 VRS-CY1JF223J V 22k 1/16W Metal Oxide R502 VRS-CY1JF273J V 27k 1/16W Metal Oxide (VC-H960U/H960U(B)/ R504 VRS-CY1JF000J 1/16W Metal Oxide H961U) R601 VRS-CY1JF103J V 10k 1/16W Metal Oxide R671 VRS-CY1JF103J V 10k 1/16W Metal Oxide...
  • Page 68 VC-A560U(A)/A560U/A560U(B) VC-H960U/H960U(B)/H961U Ref. No. Part No. Description Code Ref. No. Part No. Description Code R756 VRS-CY1JF103J V 10k 1/16W Metal Oxide MISCELLANEOUS PARTS R769 VRS-CY1JF1R0J 1/16W Metal Oxide å ACC901 QACCDA005WJZZ V AC Cord R770 VRS-CY1JF1R0J 1/16W Metal Oxide å F901 QFS-B3025CEZZ V Fuse, 3.0A/125V R771...
  • Page 69 VC-A560U(A)/A560U/A560U(B) VC-H960U/H960U(B)/H961U Ref. No. Part No. Description Code Ref. No. Part No. Description Code MSPRD0214AJFJ V Supply Load Double MECHANISM CHASSIS PARTS Action Spring (VC-A560U/A560U(B)/ H960U/H960U(B)/H961U) LBNDK1021AJZZ V Tension Band Ass’y (VC-A560U/A560U(B)/ MSPRT0439AJFJ V Pinch Double Action spring Springing(VC-A560U/A560U(B)/ H960U/H960U(B)/H961U) LBOSZ1022AJZZ V Tension Arm Boss H960U/H960U(B)/H961U)
  • Page 70 VC-A560U(A)/A560U/A560U(B) VC-H960U/H960U(B)/H961U Ref. No. Part No. Description Code Ref. No. Part No. Description Code RMOTNA001WJZZ V Capstan Motor LX-WZ1041GE00 J CW2.6-6-0.5 ARM (VC-A560U/A560U(B)/ (VC-A560U/A560U(B)/ H960U/H960U(B)/H961U) H960U/H960U(B)/H961U) RMOTP1139GEZZ J Drum Drive Motor LX-WZ1098GE00 J CW2.6-4.7-0.5 (VC-A560U/A560U(B)/ (VC-A560U/A560U(B)/ H960U/H960U(B)/H961U) H960U/H960U(B)/H961U) DDRMW0042TEX1 V Upper and Lower Drum XBPSD26P06000 V Azimuth Adjusting Screw Ass'y(VC-A560U/A560U(B))
  • Page 71 VC-A560U(A)/A560U/A560U(B) VC-H960U/H960U(B)/H961U Ref. No. Part No. Description Code Ref. No. Part No. Description Code JBTN-3159AJSB V Button, PLAY/STOP CABINET PARTS (VC-H961U) JBTN-3163AJSA V Button, PLAY/STOP (VC-A560U/A560U(A)/ GCABA3169AJSM V Top Cabinet A560U(B)/H960U/ GCABB1253AJKB V Main Frame H960U(B)) GCOVA2213AJKZ V Antenna Terminal Cover JBTN-3162AJSB V Button, FF/REW (VC-H960U/H960U(B)/...

  • Page 72: Exploded View Of Mechanical Parts

    VC-A560U(A)/A560U/A560U(B) VC-H960U/H960U(B)/H961U 11. EXPLODED VIEW OF MECHANICAL PARTS Ref. No. Part No. Description Code Ref. No. Part No. Description Code MECHANISM CHASSIS PARTS...
  • Page 73 VC-A560U(A)/A560U/A560U(B) VC-H960U/H960U(B)/H961U Ref. No. Part No. Description Code Ref. No. Part No. Description Code CASSETTE HOUSING CONTROL PARTS...
  • Page 74 VC-A560U(A)/A560U/A560U(B) VC-H960U/H960U(B)/H961U Ref. No. Part No. Description Code Ref. No. Part No. Description Code CABINET PARTS VC-H960U VC-H960U(B) VC-H961U VC-A560U(A) VC-A560U VC-A560U(B) VC-H961U only...
  • Page 75 VC-A560U(A)/A560U/A560U(B) VC-H960U/H960U(B)/H961U Ref. No. Part No. Description Code FRONT PANEL PARTS(VC-A560U/H960U) Ref. No. Part No. Description Code 500-7 500-3 500-10 500-12 500-2 500-11 500-1 500-6 PRECAUTION ON FRONT PANEL SET-UP Cassette cover Front panel Cassette housing Cassette cover open lever Cassette cover Cassette cover Cassette cover...
  • Page 76 VC-A560U(A)/A560U/A560U(B) VC-H960U/H960U(B)/H961U FRONT PANEL PARTS(VC-H961U) Ref. No. Part No. Description Code Ref. No. Part No. Description Code 500-7 500-3 500-1 500-2 500-11 500-6 500-4 PRECAUTION ON FRONT PANEL SET-UP Cassette cover Front panel Cassette housing Cassette cover open lever Cassette cover Cassette cover Cassette cover open lever...

  • Page 77: Packing Of The Set

    VC-A560U(A)/A560U/A560U(B) VC-H960U/H960U(B)/H961U Ref. No. Part No. Description Code Ref. No. Part No. Description Code 12. PACKING OF THE SET Setting position of the Knobs RF conv. CH. preset at "3" channel Accessories TiNS-4084AJZZ Instruction Book (VC-A560U/A560U(B)/H960U/ H960U(B) TiNS-4084EJZZ Instruction Book (VC-A560U(A)) TiNS-4087AJZZ Instruction Book...
  • Page 78 Part No. Description Code © COPYRIGHT 2002 BY SHARP CORPORATION ALL RIGHTS RESERVED. No part of this publication may be reproduced, stored in a retrieval system, or transmitted in any form or by any means, electronic, mechanical, photocopying, recording, or otherwise, without prior written permission of the publisher.

This manual is also suitable for:

Vc-h960ubVc-h961uVc-a560uVc-a560ubVc-h960u

Table of Contents
