SERVICE MANUAL
Sec. 1: Main Section
I Specifications
I Preparation for Servicing
I Adjustment Procedures
I Schematic Diagrams
I CBA's
13" COLOR TV/VCR COMBINATION
Sec. 2: Deck Mechanism Section
I Standard Maintenance
I Alignment for Mechanism
I Disassembly/Assembly of Mechanism
SSC132
Sec. 3: Exploded views
and Parts List Section
I Exploded views
I Parts List
