Infinity Model Twelve Service Manual page 14

M o d e l T w e l v e
Part Number Description
MAIN/POWER SUPPY PCB
199-15002005-e ZENER DIODE 20V 1/2W 52mm (RoHS)
109-1tsc103j0-e THERMISTOR TSC05103J(RoHS)
190-16lm324n-e
I.C. LM324N(RoHS) DUAL OP-AMP
192-991d669a-e TRANSISTOR HI-SINCERITY HSD669A(RoHS) NPN
192-992b649t-e TRANSISTOR HSB649T(RoHS)
197-00db103g-e DIODE 1A 200V DF02M DB103G(RoHS) BRIDGE
197-00kbu1003-e
DIODE 10A 200V BRIDGE
197-101n4002-e
DIODE 1N4002 (RoHS)
Miscellaneous
171-udhss124d-e
RELAY 5A 24V UDH-SS124D(RoHS)
175-1c02p01-e
WIRE CONNECTOR&BASE 2PIN PITCH=2.5mm(RoHS)
175-1c06v01-e WIRE CONNECTOR&BASE 6 PIN PITCH=2.5mm(RoHS)
175-1d02v01-e WIRE CONNECTOR&BASE 2PIN PITCH=3.96mm(RoHS)
175-1d05v01-e WIRE CONNECTOR&BASE 5PIN 3.96mm(RoHS)
PREAMP PCB
Resistors
110-14152j26-e
CARBON RESISTOR 1.5K 1/4W ±5% CF 26mm (RoHS)
110-16101j26-e CARBON RESISTOR 100Ω 1/6W ±5% CF 26mm (RoHS)
110-16102j26-e CARBON RESISTOR 1K 1/6W ±5% CF 26mm (RoHS)
110-16103j26-e CARBON RESISTOR 10K 1/6W ±5% CF 26mm (RoHS)
110-16105j26-e CARBON RESISTOR 1M 1/6W ±5% CF 26mm (RoHS)
110-16151j26-e
CARBON RESISTOR 150Ω 1/6W ±5% CF 26mm (RoHS)
110-16183j26-e CARBON RESISTOR 18K 1/6W ±5% CF 26mm (RoHS)
110-16203j26-e CARBON RESISTOR 20K 1/6W ±5% CF 26mm (RoHS)
110-16221j26-e CARBON RESISTOR 220Ω 1/6W ±5% CF 26mm (RoHS)
110-16223j26-e
CARBON RESISTOR 22K 1/6W ±5% CF 26mm (RoHS)
110-16274j26-e
CARBON RESISTOR 270K 1/6W ±5% CF 26mm (RoHS)
110-16331j26-e CARBON RESISTOR 330Ω 1/6W ±5% CF 26mm (RoHS)
110-16432j26-e CARBON RESISTOR 4.3K 1/6W ±5% CF 26mm (RoHS)
110-16472j26-e CARBON RESISTOR 4.7K 1/6W ±5% CF 26mm (RoHS)
110-16473j26-e
CARBON RESISTOR 47K 1/6W ±5% CF 26mm (RoHS)
110-16474j26-e
CARBON RESISTOR 470K 1/6W ±5% CF 26mm (RoHS)
110-164r7j26-e CARBON RESISTOR 4.7Ω 1/6W ±5% CF 26mm (RoHS)
110-16621j26-e CARBON RESISTOR 620Ω 1/6W ±5% CF 26mm (RoHS)
116-161001f26-e MTL FILM RESISTOR 1K 1/6W ±1% MF26mm (RoHS)
116-161002f26-e
MTL FILM RESISTOR 10K 1/6W ±1% MF 26mm (RoHS)
116-161504f26-e MTL FILM RESISTOR 1.5M 1/6W ±1% MF 26mm (RoHS)
116-161693f26-e MTL FILM RESISTOR 169K 1/6W ±1% MF 26mm (RoHS)
116-162001f26-e MTL FILM RESISTOR 2.00K 1/6W ±1% MF 26mm (RoHS)
116-162052f26-e MTL FILM RESISTOR 20.5K 1/6W ±1% MF 26mm (RoHS)
116-162212f26-e
MTL FILM RESISTOR 22.1K 1/6W ±1% MF 26mm (RoHS)
116-162262f26-e MTL FILM RESISTOR 22.6K 1/6W ±1% MF 26mm (RoHS)
116-163322f26-e MTL FILM RESISTOR 33.2K 1/6W ±1% MF 26mm (RoHS)
116-163923f26-e MTL FILM RESISTOR 392K 1/6W ±1% MF 26mm (RoHS)
116-164320f26-e MTL FILM RESISTOR 432Ω 1/6W ±1% MF 26mm (RoHS)
116-164421f26-e
MTL FILM RESISTOR 4.42K 1/6W ±1% MF 26mm (RoHS)
116-164751f26-e MTL FILM RESISTOR4.75K 1/6W MF 26mm (RoHS)
116-164752f26-e MTL FILM RESISTOR 47.5K 1/6W ±1% MF 26mm (RoHS)
PNP
13
Q'ty Reference Designator
1 D129
1 R237
1 U107
1 Q116
1 Q118
1 D124
1 D123
1 D114
1 K101
1 P108
1 P107
1 P112
1 P113
1 R150
4 R112,R113,R151,R152
1 R140
7 R263,R118,R133,R136,R146,R149,R199
2 R145,R181
1 R139
1 R147
1 R200
2 R119,R120
2 R141,R148
1 R138
2 R284,R285
1 R254
1 R144
1 R137
1 R143
1 R153
2 R287,R288
1 R194
3 R130,R131,R132
1 R142
1 R195
1 R202
2 R197,R198
3 R193,R204,R206
4 R209,R231,R232,R296
2 R220,R225
1 R201
1 R265
2 R205,R207
2 R109,R110
2 R121,R122
