XS-F6922/F6932/F6942
SERVICE MANUAL
Ver 1.0 2002.01
XS-F6922
SPECIFICATIONS
XS-F6942
XS-F6932
Dimensions
XS-F6942
182
30
XS-F6932
182
30
XS-F6922
182
30
Sony Corporation
9-873-490-01
2002A0500-1
e Vehicle Company
C 2002.1
Published by Sony Engineering Corporation
XS-F6922
Design and specifications are subject to change without notice.
Unit: mm
146
5.5
9.5
118
166
19
80
146
5.5
9.5
118
80
166
19
146
5.5
9.5
118
80
166
18
XS-F6932
PARTS LIST
Ref. No. Part No.
1-825-072-11 SPEAKER (6inch X 9inch.4 WAY) (L) (F6942)
1-825-072-21 SPEAKER (6inch X 9inch.4 WAY) (R) (F6942)
1-825-073-11 SPEAKER (6inch X 9inch.3 WAY) (L) (F6932)
1-825-073-21 SPEAKER (6inch X 9inch.3 WAY) (R) (F6932)
1-825-075-11 SPEAKER (6inch X 9inch.2 WAY) (L) (F6922)
1-825-075-21 SPEAKER (6inch X 9inch.2 WAY) (R) (F6922)
3-240-019-11 MANUAL, INSTRUCTION (ENGLISH, SPANISH,
1
3-240-018-01 PAPER PATTERN
2
X-3381-764-1 GRILLE ASSY
3
1-574-318-71 CORD (WITH TERMINAL) (L) (WHITE)
3
1-574-318-81 CORD (WITH TERMINAL) (R) (GRAY)
4
A-3254-779-A SCREW ASSY
1
PAPER PATTERN
1
3
SPEAKER CODE
2
AEP Model
XS-F6942
Description
SWEDISH, PORTUGUESE, FRENCH, GERMAN,
DUTCH, ITALIAN, RUSSIAN, POLISH, GREEK)
2
GRILLE
2
NET
GRILLE ASSY
4
+BVTP 4
30
SPEED NUT
8
SCREW ASSY
2-WAY SPEAKER
XS-F6922
3-WAY SPEAKER
XS-F6932
4-WAY SPEAKER
XS-F6942
Remark
2
8
