Sony XS-F6932SL Service Manual

3-way speaker.
Hide thumbs


Advertisement

SERVICE MANUAL
Ver 1.0 2002.01
SPECIFICATIONS
Design and specifications are subject to change without notice.
Dimensions
182
30
Sony Corporation
9-873-491-01
2002A0500-1
e Vehicle Company
C 2002.1
Published by Sony Engineering Corporation
Unit: mm
146
5.5
9.5
118
19
80
166
XS-F6932SL
PARTS LIST
Ref. No. Part No.
Description
1-825-074-11 SPEAKER (6inch X 9inch.3 WAY) (L)
1-825-074-21 SPEAKER (6inch X 9inch.3 WAY) (R)
3-240-094-11 MANUAL, INSTRUCTION (ENGLISH)
1
3-240-018-01 PAPER PATTERN
2
X-3381-765-1 GRILLE ASSY
3
1-574-318-71 CORD (WITH TERMINAL) (L) (WHITE)
3
1-574-318-81 CORD (WITH TERMINAL) (R) (GRAY)
4
A-3254-779-A SCREW ASSY
1
2
PAPER PATTERN
1
3
4
SPEAKER CODE
2
UK Model
Remark
GRILLE
NET
2
2
GRILLE ASSY
+BVTP4
30
SPEED NUT
8
SCREW ASSY
3-WAY SPEAKER
8
