Page 1
COMPONENTS IDENTIFIED BY MARK ON THE SCHEMATIC DIAGRAM AND IN THE PARTS LIST ARE CRITICAL FOR RISK OF FIRE AND ELECTRIC SHOCK. REPLACE THESE COMPONENTS WITH ONKYO PARTS WHOSE PART NUMBERS APPEAR AS SHOWN IN THIS MANUAL. MAKE LEAKAGE-CURRENT OR RESISTANCE...
TX-NR900/E SPECIFICATIONS AMPLIFIER SECTION TUNER SECTION Continuous average power output (FTC) All channels: 110 W per channel min. RMS at 8 Tuning range , 2 channels driven from 20 Hz to USA & Canadian models: 87.50 –108.00 MHz (100-kHz steps) 20 kHz with no more than 0.08% Other models: 87.50 –108.00 MHz (50-kHz steps)
Page 3
TX-NR900/E SERVICE PROCEDURES 1. Replacing the fuses 4. Memory Preservation This unit does not require memory preservation batteries. A This symbol located near the fuses indicates built-in memory power back-up system preserves the contents that the fuse used is fast operating type. For continued of the memory during power failures and even when the unit is protection against fire hazard, replace with same type fuse.
Page 6
TX-NR900/E BLOCK DIAGRAM 11dB MUTE MULTI CHANNEL INPUT 11dB HEADPHONE MUTE HPEN MASTER VOLU ME TONE PREOUT NJU7306G LEFT Power Amplifier BOOST +29dB MUTE SL->L C->L SW ->L MC R TC94A07F BYPASS FRONT SPEAKERS RIGHT RIGHT +29dB MUTE SR->R C->R SW ->R LEFT BYPASS...
TX-NR900/E SCHEMATIC DIAGRM 8 Power Supply Section T H I S S Y M B O L L O C A T E D N E A R T H E F U S E I N D I C A T E S T H A T T H E F U S E U S E D I S S L O W O P E R A T I N G T Y P E C922 NAPS-7691...
Page 57
TX-NR900/E PRINTED CIRCUIT BOARD VIEW 10-3 P800A R2903 R2902 P7004A P7003A D2903 D2902 Q2906 Q2904 Q2902 Q2907 Q2905 Q2903 P4011A P4010A P4020A R2914 R2916 C2924 R2918 R2917 R2915 R2919 C2917 C2918 MAIN CONNECTOR P3011A P3010A PC BOARD(NAAR-7728) CHIP PARTS SIDE PC BOARD VIEW Q2908 P3211A...
Page 58
TX-NR900/E PRINTED CIRCUIT BOARD VIEW 10-2 C2906 NCAR-7728 25137728B P7201B P7002A R2912 R2913 P9502B WHITE SIDE WIRE P4012A P4012A P4011A LOCK MAIN CONNECTOR PC BOARD(NAAR-7728) CHIP PARTS SIDE PC BOARD VIEW NCETC-7733 25137733 Q231 Q232 R234 D201 R202 Q2922 C201 C207 Q202 Q221...
Page 59
TX-NR900/E PRINTED CIRCUIT BOARD VIEW 10-1 C2906 NCAR-7728 25137728B P7201B P7002A P7003A R2912 R2913 P9502B WHITE SIDE WIRE P4012A P4012A P4011A LOCK MAIN CONNECTOR PC BOARD(NAAR-7728) COMPONENT PARTS SIDE PC BOARD VIEW NCETC-7733 25137733 Q231 Q232 R234 D201 R202 Q2922 C201 C207 Q202...
Page 60
TX-NR900/E PRINTED CIRCUIT BOARD VIEW FROM COMPONENT SIDE 11-2 Soldering side NET-TUNE CIRCUIT PC BOARD(NADG-7662)
Page 61
TX-NR900/E PRINTED CIRCUIT BOARD VIEW FROM COMPONENT SIDE 11-1 Component side NET-TUNE CIRCUIT PC BOARD(NADG-7662)
Page 62
TX-NR900/E ADJUSTMENT AND CONFIRMATION PROCEDURES 3 Test Mode 1. Turn POWER button on. 2. Press and hold down CD button, then press DISPLAY and STANDBY/ON buttons. 3. After "TEST " on the FL tube is displayed, press CD button to set the unit to the test mode of FL tube. Note: VIDEO 1:TEST-1 VIDEO 2 :TEST-2 VIDEO 3 :TEST-3 VIDEO 4:TEST-4 Test mode of FL tube...
Page 63
TX-NR900/E ADJUSTMENT AND CONFIRMATION PROCEDURES 2 3. Confirmation of Current detection circuit Set the unit to "TEST-1-00". Connect the differentiating circuit and apply the 200Hz square signal to MULTI CHANNEL INPUT terminal. of each channel. Adjust the attenuator or Volume so that the output level becomes 35V p-p. Confirm that the speaker relay does not turn OFF when a 3.0 ohm load is connected.
Page 64
TX-NR900/E ADJUSTMENT AND CONFIRMATION PROCEDURES 1 Idling current adjustment Before Idling current adjustment, turn the trimming resistors R6040 to R6046 to counter-clockwise. Connect the DC voltmeter at the sockets P6080 to P6086. After turn POWER to ON, adjust the trimming resistors R6040, R6041 and R6042 so that the reading of voltmeter becomes 11 mV.
Page 65
REF. NO. PART NO. DESCRIPTION 27111236B Front bracket <B> 27111237B Front bracket <S> 27111238B Front bracket <G> 27191153B Holder. Jack 838430088 3TTB+8B(BC),Self-tapping screw 838130088 3TTB+8B,Self-tapping screw 28325948 Knob, pure <B> 28325949 Knob, pure <S/G> 28141447 Cushion 28191936 Clear plate 28133385 Back plate <B>...
TX-NR900/E Note: <D>: 120V model only <GT>: 220-230 V model only PRINTED CIRCUIT BOARD-PARTS LIST 2 <P>: European model only <A>: Australian model only <T>: Worldwide model only <R>: Chinese model only <O>: Except 120V model F/C ch. driver circuit PC board (NAAF-7690-1A/1B/1C/1D/1E/1F) Primary circuit PC board (NAPS-7691-1A/1B/1C/1D/1E/1F) CIRCUIT NO.
Page 73
TX-NR900/E Note: <D>: 120V model only <GT>: 220-230 V model only PRINTED CIRCUIT BOARD-PARTS LIST 3 <P>: European model only <A>: Australian model only <T>: Worldwide model only <R>: Chinese model only Bias selector relay PC board (NAPS-7692-1A/1B/1C/1D/1E/1F) <O>: Except 120V model CIRCUIT NO.
Page 74
TX-NR900/E CAUTION: Replacement for transistor of mark *, if necessary PRINTED CIRCUIT BOARD-PARTS LIST 4 must be made from the same beta group (H ) as the original type. CIRCUIT NO. PART NO. DESCRIPTION CIRCUIT NO. PART NO. DESCRIPTION Transistors Diodes D6701,D6702 223163,...
Page 75
TX-NR900/E PRINTED CIRCUIT BOARD-PARTS LIST 5 Note: <D>: 120V model only <P>: European model only CIRCUIT NO. PART NO. DESCRIPTION CIRCUIT NO. PART NO. DESCRIPTION <T>: Worldwide model only Plugs Sockets <O>: Except 120V model P6080~P6086 25055038 NPLG-2P29 P6003A~P6006A 25052287 NSCT-4P2184 <GT>: 220-230 V model only P6931...
Page 76
TX-NR900/E PRINTED CIRCUIT BOARD-PARTS LIST 6 NOTE: THE COMPONENTS IDENTIFIED BY MARK ! ARE CRITICAL FOR RISK OF FIRE AND ELECTRIC SHOCK. REPLACE ONLY WITH PART NUMBER SPECIFIED. CIRCUIT NO. PART NO. DESCRIPTION Fuse holders CIRCUIT NO. PART NO. DESCRIPTION F9501A,F9501B 25052133 NSCT-1P2031 Capacitors...
Page 77
TX-NR900/E PRINTED CIRCUIT BOARD-PARTS LIST 7 CIRCUIT NO. PART NO. DESCRIPTION CIRCUIT NO. PART NO. DESCRIPTION Transistors Capacitors C3120,C3121 354742219 or 220uF,16V, Elect. or Q2909 2216175R2 or KTC3875-GR or 394642217 220uF,16V, Elect. 2213145R2 2SC2712-GR C3122,C3123 354744709 or 47uF,16V, Elect. or Q2931 2212855 or 2SB1068-U or...
Page 78
TX-NR900/E PRINTED CIRCUIT BOARD-PARTS LIST 8 Composite video PC board (NAVD-7729-1A/1B/1C) S video PC board (NAVD-7730-1A/1B/1C) CIRCUIT NO. PART NO. DESCRIPTION CIRCUIT NO. PART NO. DESCRIPTION Q2001 22241848R2 LC74761M-9845 Q2451 22241849R2 MM1512 Q2010 22241619R2 TC9273F-004 Q2501,Q2511 222740515R2 74HC4051AF Q2101,Q2201 222740515R2 74HC4051AF Q2502,Q2602 22241443R2...
Page 79
TX-NR900/E Note: <D>: 120V model only <GT>: 220-230 V model only PRINTED CIRCUIT BOARD-PARTS LIST 9 <P>: European model only <A>: Australian model only <T>: Worldwide model only <R>: Chinese model only <O>: Except 120V model RS232 terminal PC board (NAETC-7733-1A/1B/1C) CIRCUIT NO.
Page 80
TX-NR900/E PRINTED CIRCUIT BOARD-PARTS LIST 10 Front video terminal PC board (NAETC-7741-1A/1B/1C/1D) CIRCUIT NO. PART NO. DESCRIPTION Terminal P2510 25045678 NPJ-3PDB475 Sockets P2506B 2009990575UL NSAS-10P0784 P2508 25051569 NSCT-4P1356 P3220B 2009990420 NSAS-6P0564 Front optical terminal PC board (NAETC-7742-1A/1B/1C/1D) CIRCUIT NO. PART NO. DESCRIPTION Photo coupler U2501...
