Sony HCD-GTX888 Service Manual page 104

HCD-GTX777/GTX787/GTX888
Ver. 1.1
TC TRANS USB R
Ref. No. Part No. Description
R404 1-216-841-11 METAL CHIP
R405 1-216-841-11 METAL CHIP
R406 1-216-841-11 METAL CHIP
R407 1-218-867-11 METAL CHIP
R408 1-216-867-11 METAL CHIP
R409 1-216-845-11 METAL CHIP
R411 1-216-854-11 METAL CHIP
R412 1-216-854-11 METAL CHIP
R413 1-216-853-11 METAL CHIP
R414 1-216-853-11 METAL CHIP
R423 1-216-845-11 METAL CHIP
R424 1-216-845-11 METAL CHIP
R427 1-216-797-11 METAL CHIP
R428 1-216-797-11 METAL CHIP
R429 1-216-833-11 METAL CHIP
R430 1-216-833-11 METAL CHIP
R431 1-216-821-11 METAL CHIP
R432 1-216-821-11 METAL CHIP
R433 1-216-841-11 METAL CHIP
R434 1-216-841-11 METAL CHIP
R435 1-216-833-11 METAL CHIP
R436 1-216-833-11 METAL CHIP
R437 1-216-825-11 METAL CHIP
R438 1-216-825-11 METAL CHIP
R439 1-216-864-11 SHORT CHIP
R440 1-216-833-11 METAL CHIP
R442 1-216-841-11 METAL CHIP
R443 1-216-845-11 METAL CHIP
R444 1-216-833-11 METAL CHIP
R449 1-216-801-11 METAL CHIP
R450 1-216-801-11 METAL CHIP
R451 1-216-833-11 METAL CHIP
R452 1-216-841-11 METAL CHIP
R453 1-216-829-11 METAL CHIP
R454 1-216-829-11 METAL CHIP
R455 1-216-797-11 METAL CHIP
R456 1-216-801-11 METAL CHIP
R457 1-216-837-11 METAL CHIP
R458 1-216-793-11 METAL CHIP
R459 1-216-864-11 SHORT CHIP
R461 1-216-864-11 SHORT CHIP
R462 1-216-864-11 SHORT CHIP
R463 1-216-833-11 METAL CHIP
R464 1-216-833-11 METAL CHIP
R481 1-216-833-11 METAL CHIP
R482 1-216-841-11 METAL CHIP
R483 1-216-841-11 METAL CHIP
R484 1-216-825-11 METAL CHIP
R487 1-216-864-11 SHORT CHIP
< TRANSFORMER >
T001 1-443-760-11 TRANSFORMER, BIAS OSCILLATION
**********************************************************************************************
104
Remark
47K 5% 1/10W
47K 5% 1/10W
47K 5% 1/10W
6.8K 5% 1/10W
6.8K 5% 1/10W
100K 5% 1/10W
560K 5% 1/10W
560K 5% 1/10W
470K 5% 1/10W
470K 5% 1/10W
100K 5% 1/10W
100K 5% 1/10W * CN1294
10 5% 1/10W * CN1296
10 5% 1/10W
10K 5% 1/10W
10K 5% 1/10W
1K 5% 1/10W
1K 5% 1/10W
47K 5% 1/10W
47K 5% 1/10W
10K 5% 1/10W
10K 5% 1/10W
2.2K 5% 1/10W
2.2K 5% 1/10W
0
10K 5% 1/10W
47K 5% 1/10W
100K 5% 1/10W
10K 5% 1/10W
22 5% 1/10W
22 5% 1/10W
10K 5% 1/10W
47K 5% 1/10W
4.7K 5% 1/10W
4.7K 5% 1/10W
10 5% 1/10W
22 5% 1/10W
22K 5% 1/10W
4.7 5% 1/10W
0
0
0
10K 5% 1/10W
***********************************************************************************************
10K 5% 1/10W
10K 5% 1/10W
47K 5% 1/10W
47K 5% 1/10W
2.2K 5% 1/10W
0
Ref. No. Part No. Description
TRANS BOARD
******************
< CAPACITOR >
C1291 1-126-964-11 ELECT
C1292 1-128-576-11 ELECT
C1293 1-126-952-11 ELECT
C1294 1-126-943-11 ELECT
C1295 1-126-943-11 ELECT
< CONNECTOR >
1-564-520-11 PLUG, CONNECTOR 5P
1-564-521-11 PLUG, CONNECTOR 6P
< DIODE >
D1291 6-501-796-01 DIODE MAZ8330GMLSO
D1292 6-500-522-21 DIODE 10EDB40-TB3
D1294 6-500-522-21 DIODE 10EDB40-TB3
D1295 6-500-522-21 DIODE 10EDB40-TB3
D1296 6-500-848-01 DIODE MC2840-T112-1
< FUSE HOLDER >
FH1240 1-533-217-41 HOLDER, FUSE
FH1242 1-533-217-41 HOLDER, FUSE
FH1250 1-533-217-41 HOLDER, FUSE
FH1252 1-533-217-41 HOLDER, FUSE
FH1260 1-533-217-41 HOLDER, FUSE
FH1262 1-533-217-41 HOLDER, FUSE
FH1270 1-533-217-41 HOLDER, FUSE
FH1272 1-533-217-41 HOLDER, FUSE
FH1280 1-533-217-41 HOLDER, FUSE
FH1282 1-533-217-41 HOLDER, FUSE
FH1283 1-533-217-41 HOLDER, FUSE (GTX777:MX)
FH1284 1-533-217-41 HOLDER, FUSE (GTX777:MX)
< TRANSISTOR >
Q1291 8-729-032-94 TRANSISTOR
< RESISTOR >
R1292 1-219-124-11 FUSIBLE
R1293 1-216-821-11 METAL CHIP
R1294 1-216-832-11 METAL CHIP
R1295 1-216-832-11 METAL CHIP
A-1234-821-A USB R BOARD, COMPLETE (MX)
A-1512-478-A USB R BOARD, COMPLETE (EXCEPT MX)
******************************
< CAPACITOR >
C901 1-107-826-11 CERAMIC CHIP 0.1uF
C902 1-124-779-00 ELECT CHIP
C903 1-124-779-00 ELECT CHIP
C904 1-124-779-00 ELECT CHIP
C905 1-107-826-11 CERAMIC CHIP 0.1uF
C906 1-107-826-11 CERAMIC CHIP 0.1uF
C907 1-107-826-11 CERAMIC CHIP 0.1uF
C908 1-107-826-11 CERAMIC CHIP 0.1uF
C909 1-162-919-11 CERAMIC CHIP 22PF
C910 1-162-919-11 CERAMIC CHIP 22PF
C912 1-162-915-11 CERAMIC CHIP 10PF
Remark
10uF 20% 50V
100uF 20% 63V
1000uF 20% 35V
2200uF 20% 25V
2200uF 20% 25V
2SD1859TV2Q
0.68 5% 1/4W
1K 5% 1/10W
8.2K 5% 1/10W
8.2K 5% 1/10W
10% 16V
10uF 20% 16V
10uF 20% 16V
10uF 20% 16V
10% 16V
10% 16V
10% 16V
10% 16V
5% 50V
5% 50V
0.5PF 50V
