SERVICE MANUAL
Ver. 1.3 2005. 11
• The tuner and CD sections have no adjustments.
AUDIO POWER SPECIFICATIONS (US Model)
POWER OUTPUT AND TOTAL HARMONIC DISTORTION
23.2 watts per channel minimum continuous average power into
4 ohms, 4 channels driven from 20 Hz to 20 kHz with no more
than 5% total harmonic distortion.
CD player section
Signal-to-noise ratio
120 dB
Frequency response
10 – 20,000 Hz
Wow and flutter
Below measurable limit
Tuner section
FM
Tuning range
US, Canadian Model:
87.5 – 107.9 MHz
E model:
FM tuning interval:
50 kHz/200 kHz
switchable
87.5 – 108 MHz (at 50 kHz step)
87.5 – 107.9 MHz (at 200 kHz step)
East European Model:
FM1/FM2: 87.5 – 108.0 MHz (at 50 kHz step)
FM3: 65 – 74 MHz (at 30 kHz step)
Antenna terminal
External antenna connector
Intermediate frequency 10.7 MHz/450 kHz
Usable sensitivity
9 dBf
Selectivity
75 dB at 400 kHz
Signal-to-noise ratio
67 dB (stereo),
69 dB (mono)
Harmonic distortion at 1 kHz
0.5% (stereo),
0.3% (mono)
Separation
35 dB at 1 kHz
Frequency response
30 – 15,000 Hz
Sony Corporation
9-879-323-04
2005K04-1
eVehicle Division
© 2005. 11
Published by Sony Engineering Corporation
CDX-S2210/S2210S/S2210X/
Photo: CDX-S2250EE
SPECIFICATIONS
AM
Tuning range
Antenna terminal
Intermediate frequency 10.7 MHz/450 kHz
Sensitivity
Power amplifier section
Outputs
Speaker impedance
Maximum power output Except East European model:
General
Outputs
Inputs
FM/AM COMPACT DISC PLAYER
S2250EE/SW330
Canadian Model
East European Model
Model Name Using Similar Mechanism
CD Drive Mechanism Type
Optical Pick-up Name
US, Canadian Model:
530 – 1,710 kHz
E Model:
AM tuning interval:
9 kHz/10 kHz switchable
531 – 1,602 kHz (at 9 kHz step)
530 – 1,710 kHz (at 10 kHz step)
East European Model:
531 – 1,602 kHz
External antenna connector
30 µV
Speaker outputs
(sure seal connectors)
4 – 8 ohms
52 W × 4 (at 4 ohms)
East European model:
50 W × 4 (at 4 ohms)
Audio outputs terminal (sub/rear switchable)
Power antenna relay control terminal
Power amplifier control terminal
Antenna input terminal
Remote controller input terminal (CDX-S2210C only)
US Model
CDX-S2210/SW330
CDX-S2210
E Model
CDX-S2210S/S2210X
CDX-S2250EE
NEW
MG-611TA-186//K
KSS1000E
– Continued on next page –
