Icom IC-A23 Service Manual page 26

SECTION 9 BOARD LAYOUTS
9 - 1 LOGIC UNIT
• TOP VIEW
UP
9 - 1
SQL CLR
DOWN
PWR 3
2
1
MICROPHONE
The combination of this page and the next page shows
the unit layout in the same configuration as the actual
P.C. Board.
ANL BANK F
6 9 MR
5 8 0
4 7 ENT
