IVA-W200/IVA-W200E
RGB Cable (Included with NVE-N852A/NVE-N872A,
not included with NVE-N871A)
Remote IN/OUT Connector
RGB Input Terminal
Connect this to the RGB output terminal of the Navigation
System.
System Switch
When connecting an equalizer or divider using Ai-NET
feature, place this switch in the EQ/DIV position. When no
device is connected, leave the switch in the NORM position.
• Be sure to turn the power off to the unit before changing the
switch position.
Digital Output Terminal
Ai-NET Connector
Connect this to the output or input connector of other
product equipped with Ai-NET.
AUX Video Input Terminal
Connect the video output lead of a DVD video player or
DVD changer to this terminal.
RCA Extension Cable (Included with DVD video
player)
Ai-NET Cable (Included with DVD video player)
Fiber Optic Cable (Sold Separately)
Ai-NET Cable (Included with Audio Processor)
Ai-NET Cable (Included with CD Changer)
Remote Control Output Lead (White/Brown)
Connect this lead to the remote control input lead. This lead
outputs the controlling signals from the remote control.
To Ai-NET Connector (Gray)
To Ai-NET Connector (Black)
