System Connections

(North American Model Only)
Connections
Ai-NET
EQ/DIV
*
• Set the system switch to "NORM" when only a changer is connected (when the Ai-NET compatible equalizer is not used).
* The label is attached on the button of the unit.
NORM
SPEAKER
LEFT
FRONT
(White)
Front left
(Yellow)
To Video Input terminal
(White)
To Audio Input terminals
(Red)
(Yellow)
To Video output terminal
(White)
(Red)
To Audio output terminals
REMOTE OUT
To remote input lead
(White/Brown)
REMOTE IN
To remote output lead
(White/Brown)
REVERSE
To plus side of the back
(Orange/White)
lamp signal lead of the car
M.CONT
To monitor control lead
(White/Pink)
Amplifier
Amplifier
Amplifier
CD Changer
(Sold Separately)
REMOTE
TURN-ON
To amplifier or
(Blue/White)
equalizer
POWER ANT
To power antenna
(Blue)
AUDIO INTERRUPT IN
To vehicle phone
(Pink/Black)
PARKING BRAKE
To the parking brake
(Yellow/Blue)
signal lead
FOOT BRAKE
To the foot brake cord
(Yellow/Black)
or brake lamp cord
IGNITION
(Red)
Ignition key
BATTERY
(Yellow)
GND
(Black)
SPEAKER SPEAKER
LEFT RIGHT
(Violet/
(White/ (Green)
REAR REAR
Black)
Black)
(Green/
(Violet)
Black)
Speakers
Rear left Rear right
- 5 -
IVA-W200/IVA-W200E
Antenna
(R, L)
(R, L)
Rear Left
Rear Right
Front Left
Front Right
Subwoofers
To iPod
Battery
SPEAKER
RIGHT
FRONT (Gray)
(Gray/
Black)
Front right
