Epson PowerLite Home Cinema 3010 Brochure & Specs

PowerLite Home Cinema 3010
®
Home Theater Projector
Product Name
PowerLite Home Cinema 3010
Genuine EPSON Lamp
Replacement Air Filter
3D Glasses
Specifications
Projection System
EPSON 3LCD, 3-chip technology
Projection Method
Front / Rear / Ceiling mount
Product Color
White and Gray
Driving Method
EPSON Poly-silicon TFT Active Matrix,
0.61-inch wide panel with MLA
Projected Output
HD, 2D, 3D, 1080p
Pixel Number
2,073,600 dots (1920 x 1080) x 3
Color Light Output
1
2200 lumens
White Light Output
1
2200 lumens (ISO 21118 Standard)
Aspect Ratio
Native 16:9 widescreen (4:3 resize)
Compatible with 4:3 and 2.35:1 video formats
with Normal, Full or Zoom Modes
Native Resolution
1080p (1920 x 1080)
Resize
16:10, 4:3
Lamp Type
E-TORL 230 W UHE
Lamp Life
3
Up to 5000 hours (ECO mode)
Up to 4000 hours (Normal mode)
Throw Ratio Range
1.32 – 2.15
Size (projected distance)
30" – 300"
Keystone Correction
Vertical: ± 30 degrees (Auto)
Horozontal: ± 30 degrees (Slide bar)
Contrast Ratio
Up to 40,000:1
Color Reproduction
Full-color (1.07 billion colors)
Color Processing
Full 10 bit (Digital only)
1 Color and white light output will vary depending on mode selected. White light output measured using ISO 21118 standard.
2 Data source: ProjectorCentral.com Jan. 2011. Average of 1038 shipping models for which manufacturers provided lumens and total power data, all resolutions and brightness levels.
3 Lamp life will vary depending upon mode selected, environmental conditions and usage. Lamp brightness decreases over time.
4 See our website for convenient and reasonable recycling options at www.epson.com/recycle
5 SmartWay is an innovative partnership of the U.S. Environmental Protection Agency that reduces greenhouse gases and other air pollutants and improves fuel efficiency.
6 The Split Screen feature can only use one digital input source at a time. The other source must be an analog source (PC/Component or Composite video). However, two different analog input sources
can be used at the same time.
7 Overnight shipping not available in all areas. Epson Value Series has a two-business-day exchange program. Road Service orders must be in by 3 p.m. Eastern Time for two-business-day delivery.
Epson America, Inc.
3840 Kilroy Airport Way, Long Beach, CA 90806
EPSON, E-TORL and PowerLite are registered trademarks, EPSON Exceed Your Vision is a registered logomark and Better Products for a Better Future and C
Corporation. Mac ia a trademark of Apple Inc., registered in the U.S. and other countries. SmartWay is a service mark of the U.S. Environmental Protection Agency. All other product and brand names
are trademarks and/or registered trademarks of their respective companies. EPSON disclaims any and all rights in these marks. Copyright 2011 Epson America, Inc. CPD-35460 10/11
Product Code UPC
V11H421020 0 10343 88508 0
V13H010L68 0 10343 88652 0
V13H134A38 0 10343 88654 4
V12H483001 0 10343 88657 5

Projection Lens

Type
Manual Focus / Manual Zoom
F-number 1.51 – 1.99
Focal Length
18.2 – 29.2 mm, widescreen image size
(projected distance): 100" diagonal
(wide: 9.7' – tele: 15.7')
Zoom Ratio Manual 1.6
Other
Display Performance
1920 x 1080 native 1080p; HD, 2D, 3D
Color Modes
2D: Dynamic, Living room, Natural, Cinema, Auto
3D: 3D Dynamic, 3D Cinema
Input Signal
DVD region code 1
Composite: NTSC / NTSC4.43 / PAL / M-PAL /
N-PAL / PAL60 / SECAM
Component: 480i / 576i / 480p / 576p / 720p /
1080i / 1080p
HDMI: TMDS
HD-DVD and Blu-ray (external source only)
®
Terminal Inputs
RCA (video) x 1
RCA (component) x 3
RCA (audio) L/R x 1
USB Type A x 1
VGA D-sub 15 pin (computer input) x 1
USB Type A
USB Type B (service only)
HDMI x 2
RS-232c x 1
Terminal Outputs
RJ-45 (external 3D emitter)
Video Compatibility
2D: WXGA, SXGA, XGA, SVGA, VGA;
3D: 720p, 1080i, 1080p
Computer Compatibility
PC, Mac
®
Speakers
Two integrated 10 W stereo speakers
Audio
DTS Digital Surround and Dolby Digital
®
Media Format
16:9
Operating Temperature
5 °C to 35 °C <41 °F to 95 °F>
Power Supply Voltage
100-240 V AC +/- 10% , 50/60 Hz
Epson Canada Limited
185 Renfrew Drive, Markham, Ontario L3R 6G3
Component
Audio L/R
HMDI 1 & 2
Rear IR Port
External 3D IR
Two –10 W Speakers
Other (continued)
Power Consumption
100 – 240 V AC 50/60 Hz 3.7 – 1.7 A
Fan Noise 24 – 32 dB
Security Kensington Security Lock port
Dimensions (W x D x H)
Including feet 16.6" x 14.4" x 5.5"
Excluding feet 16.6" x 14.4" x 5.4"
Weight 13.3 lb
Remote Control
Features
Front and rear directional
Operating Angle
± 30 degrees
Operating Distance
32 feet (10 meters)
Parental Controls
Power Button Lock
Hinders projector from being turned on without
parental supervision
Whats in the Box
PowerLite Home Cinema 3010 projector,
two pairs of EPSON active shutter 3D glasses,
power cord, two HDMI cable clamps, remote
control with AA batteries, CD ROM with users
guide link
www.epson.com
www.epson.ca
Computer 1
Video
RS-232c
Power
USB
Kensington Security
®
Lock Port

Optional Accessories

Genuine EPSON lamp V13H010L68
Replacement air filter V13H134A38
3D glasses V12H483001
External 3D IR emitter V12H484001
Projector ceiling mount CHF1000
Remote control 1557492
PixiePlus control system for
EPSON projectors ELPSP10
Belkin Pro Series VGA / SVGA
cable – 6 ft F3H982-06
Belkin Pro Series VGA / SVGA
cable – 10 ft F3H982-10
Belkin Pro Series VGA / SVGA
cable – 25 ft F3H982-25
Belkin PureAV HDMI audio video
cable – 3 ft AV22300-03
Belkin PureAV HDMI audio video
cable – 6 ft AV22300-06
Belkin PureAV HDMI audio video
cable – 12 ft AV22300-12
Kensington Security Lock ELPSL01
Repair/Exchange 1-year
extended service plan EPPSNVHTRB1
Repair/Exchange 2-year
extended service plan EPPSNVHTRB2
Packaging Specifications
Projector
19.8" x 17.3" x 12.2" (W x D x H)
Weight 18.75 lb
Genuine EPSON Lamp
5.5" x 5.1" x 5.6" (W x D x H)
Weight 0.70 lb
Air Filter
6.0" x 3.3" x 1.7" (W x D x H)
Weight 0.10 lb
Ceiling Mount
13.0" x 13.4" x 4.3" (W x D x H)
Weight 6.40 lb
3D Glasses
3.0" x 8.8" x 3.2" (W x D x H)
Weight 0.30 lb
3D Emitter
3.0" x 5.8" x 2.5" (W x D x H)
Weight 0.40 lb
Fine are trademarks of Seiko Epson
