AX-ADCT4
INSTALLATION INSTRUCTIONS
A 4 Channel Adjustable, Line Output Converter (LOC) with Built-in Amplifi er Remote
Generator
The AX-ADCT4 is designed to convert 4 channels of speaker level audio into 4 channels
of line level audio that can be used by OEM amplifi ers. It can also be used with OEM
radios to add aftermarket amplifi ers. This device will also detect the presence of an audio
signal and then generate a +12V output (verifi ed by an illuminated LED) that can be used
to turn-on an aftermarket amplifi er.
Features & Specifi cations: The AX-ADCT4 is able to handle 80 watts per channel contin-
uous input without over heating. The input circuitry is designed to correct the crossover
distortion commonly found on standard LOCs while providing a high to low level step
down of 6:1. Output audio level is infi nitely adjustable using the onboard, high quality
potentiometers. The remote output or amplifi er trigger is rated at 500mA (+12V) and will
easily handle an outboard relay if additional current is needed. The remote output will
trigger instantaneously when the AX-ADCT4 detects a DC voltage on the white, left +
audio input wire above 5V or a very low audio signal. It will shut off 60 seconds after no
signal is detected.
Installation: The AX-ADCT4 should be installed on a stereo's speaker output wires or
the output wires on an OEM amplifi er of up to 80 watts per channel. These wires can be
found behind the stereo in the dash, on the output of an OEM amplifi er, or on the input
terminals on the OEM speakers. Please refer to the wiring diagram for the input connec-
tion details.
