Axxess AX-MLOC725 Installation Instructions

The Line Output Converter
or the output wires on an OEM amplifier of up to 150 watts per channel. These wires
can be found behind the stereo in the dash, on the outside of an OEM amplifier, or on the
input terminals on the OEM speakers.

Wire color and function

The audio input wire colors are an EIA standard for car stereo applications as follows:
Yellow = battery +12v input
Black = ground input
Blue = remote +12v output the above power wires can be connected directly
to the amplifier being added
White = left front (+) input
White/Black = left front (-) input
Gray = right front (+) input
Gray/Black = right front (-) input
Black/White = reference ground (-) (reference ground optional if noise is present)
Note: Be sure that all audio input connections are polarized or in phase with each other.
That is, the positive output wires from the audio source need to be connected to the
corresponding positive input wires of the LOC. The same goes for the negative audio
wires. Failure to do this will result in poor bass response and low quality audio.
(Continued on other side)
INSTAX-MLOC725
AX-MLOC725
Installation Instructions
(LOC) should be installed on a stereo's speaker output wires
