contact a qualified electrician and have it replaced with a properly
grounded three-pronged wall receptacle or have a grounding adapter
properly grounded and polarized. If the extension cord must be used, it
should be a 3-wire, 15 amp. or higher rated cord. Do not drape over a
countertop or table where it can be pulled on by children or tripped over
accidentally.
CAUTION: DO NOT UNDER ANY CIRCUMSTANCES CUT OR RE-
MOVE THE ROUND GROUNDING PRONG FROM THIS
PLUG.
1. Door open handle.
Pull to open door.
2. Door latches.
The oven will not operate unless the
door is securely closed.
3. Removable turntable support.
4. Removable turntable.
The turntable will rotate clockwise or
counterclockwise.
5. Oven lamp.
It will light when oven is operating or
door is opened.
6. Oven door with see-through window.
7. Ventilation openings. (Rear)
8. Auto-Touch control panel.
9. Time display: Digital display, 99
minutes 99 seconds.
NOTE:
The directed features are disabled after
one minute when the oven is not in use.
These features are automatically enabled
when the door is opened and closed or the
STOP/ CLEAR pad is pressed.

OVEN DIAGRAM

6
5
10
2
1
10. Coupling.
11. Wave guide cover.
12. Power supply cord
See note
5
3-Pronged Plug
Grounding Pin
3-Pronged Receptacle
9
12
8
11
TOUCH CONTROL PANEL
R -320DK
R -320DQ
R-320DW
Grounded
Receptacle Box
7
4
3
See note
See note
