HCD-GNX700/GNX800
SERVICE MANUAL
Ver.1.0 2006.02
• HCD-GNX700/GNX800 is the Amplifier,
CD player, tape deck and tuner
section in MHC-GNX700/GNX800.
Amplifier section
HCD-GNX800
The following are measured at
Front/Surround speaker
DIN power output (rated)
Continuous RMS power output (reference)
Subwoofer
Continuous RMS power output (reference)
HCD-GNX700
The following are measured at AC 120, 220, 240 V, 50/60 Hz
Front speaker
DIN power output (rated)
Continuous RMS power output (reference)
Sony Corporation
9-887-068-01
Home Audio Division
2006B02-1
Published by Sony Techno Create Corporation
© 2006.02
CD
Section
TAPE
Section
SPECIFICATIONS
AC 120, 220, 240 V, 50/60 Hz
180 + 180 watts
(6 ohms at 1 kHz, DIN)
225 + 225 watts
(6 ohms at 1 kHz, 10% THD)
200 watts
(8 ohms at 100 Hz, 10% THD)
170 + 170 watts
(6 ohms at 1 kHz, DIN)
220 + 220 watts
(6 ohms at 1 kHz, 10% THD)
Photo: HCD-GNX800
Model Name Using Similar Mechanism
CD Mechanism Type
Base Unit Name
Optical Pick-up Name
Model Name Using Similar Mechanism
Tape Transport Mechanism Type
Subwoofer
Continuous RMS power output (reference)
Inputs
VIDEO/MD (AUDIO) IN (phono jacks):
TV (AUDIO) IN (phono jack):
MIC (phone jack):
Outputs
PHONES (stereo mini jack):
FRONT SPEAKER/SURROUND SPEAKER/
SUBWOOFER OUT:
MiNi Hi-Fi COMPONENT SYSTEM
E Model
HCD-GNX700/GNX800
Australian Model
HCD-GNX800
HCD-GN880
CDM74KF-F1BD81A
BU-F1BD81A
KSM-215DCP/C2NP
HCD-GNX80
CWN42FF601
160 watts
(8 ohms at 100 Hz, 10% THD)
voltage 250/450 mV,
impedance 47 kiloohms
voltage 250 mV,
impedance 47 kiloohms
sensitivity 1 mV,
impedance 10 kiloohms
accepts headphones of 8 ohms or more
Use only the supplied speaker
– Continued on next page –
