Radial Engineering Phazer Owner's Manual page 9

True to the Music
USING THE PHASE SECTION (continued)
The following diagrams plot the phase response at different posi-
tions of the SHIFT control. The gentle curve displaying phase shift
increases (in degrees) as the control is turned. Radial's unique phase
curves and class-A analog electronics combine to make the Phazer
sound musical.
+150
+100
+50
0
-50
-100
-150
-200
-250
-300
-350
20 50
+150
+100
+50
0
-50
-100
-150
-200
-250
-300
-350
20 50
+150
+100
+50
0
-50
-100
-150
-200
-250
-300
-350
20 50
+150
+100
+50
0
-50
-100
-150
-200
-250
-300
-350
20 50
Radial Engineering
100 200 500 1k
FREQUENCY (Hz)
100 200 500 1k
FREQUENCY (Hz)
100 200 500 1k
FREQUENCY (Hz)
100 200 500 1k
FREQUENCY (Hz)
0°
Bypass - zero phase shift,
response is linear.
180°
2k 5k 10k 20k
2k 5k 10k 20k
2k 5k 10k 20k
2k 5k 10k 20k
Phazer & Phazer-Bank
7
SHIFT
0º
180º
At this setting 200Hz is
shifted by just one or two
degrees while 20kHz is
shifted 180°.
SHIFT
0º
180º
At this setting 200Hz is
shifted by 100° while
everything above 2kHz
is shifted 180°.
SHIFT
0º
180º
Near maximum setting
200Hz reaches 180°.
