2. In-line Connection
The Phazer can be connected between line-level devices, such as
between a mic pre-amp and a recorder. An example would be a ste-
reo microphone setup where one mic is patched direct and the other
is passed through the Phazer. The Phazer is placed "in-line" between
the second mic preamp and the recorder.
Microphones
SETTING UP THE PHAZER
1. Set all panel switches to the outward position (LED off).
2. Set the SHIFT control fully counter-clockwise. Set the CUT-OFF
control fully clockwise.
3. Insert the Phazer into the microphone or direct box channel you
would like to phase align. Keep in mind that the Phazer should be
processing the signal that arrives at the mixing console fi rst. This
would be the signal from the closest of the two mics, or a direct box
since electricity travels faster than sound waves.
4. Activate the Phazer by connecting the power supply and depress-
ing the POWER switch. The LED will illuminate.
5. Turn your audio system on and test your connections at a low
volume level. If no sound is heard turn your equipment off and
check the connections. If all is well turn the level up to a comfort-
able listening level. If you hear hum or buzz, try depressing the
GROUND LIFT switch. You are ready to start using the Phazer.
Radial Engineering
Preamps
SHIFT
0º
180º
Distant Mic
Close Mic or DI Box
5
Phazer
CUT-OFF
3kHz 38kHz
300Hz 3.8kHz
Phazer & Phazer-Bank
Recorder
Insert Phazer
on close mic
or direct box
