LevelOne HVE-9002 Brochure & Specs

What is HDMI?
The High-Definition Multimedia Interface (HDMI) is a
revolutionary technology that allows viewers to
experience the highest quality digital images available. It
is able to deliver top-quality video as well as audio over a
single cable.
Introducing the HDSpider™ Series from LevelOne
The HDSpider™ Series is a collection of HDMI Cat.5 senders
and receivers, offering a full range of HDMI extender
solutions. Choose from our 5 different HDSpider extenders
to build a flexible network to send your high-quality HDMI
signals to greater distances, and at a reduced cost.
What does a Cat.5 sender + 1 HDMI Out do?
This compact device is deployed at the HD source,
generally connected to an HD player, PS3, or Xbox 360.
HVE-9002 accepts the HD signal from the HDMI source and
then uses Cat.5 cable to send the HDMI signal to the
receiver. This allows for a cost-effective long range HDMI
solution, up to 60 meters with Cat.5 cable as the signal
carrier. HVE-9002 also includes a local HDMI port which
allows for an additional monitor to be placed next to the
device. This is especially useful for deploying an HDMI
network that has requires many different displays in one
area. HVE-9002 also supports full 1080p resolution and has
an audio out port.
Surround sound: HVE-9002 also supports 7.1 multichannel
stereo surround sound, providing an easy way to extend
the high-quality video of HDMI with the superior 7.1
capabilities of Dolby Digital Plus.
To see this device in action, please see the diagram
below.
Installation Diagram
Digital Data Communications GmbH.
Zeche-Norm St. 25, 44319, Dortmund, Germany
All mentioned brand names are registered trademarks and property of their owners.
Technical specifications are subject to change without notice.
© 2008 All Rights Reserved
HDSpider™ HDMI Cat.5 Sender
+ 1 HDMI Out
HVE-9002
Related Products
HDSpider™ HDMI Cat.5 Receiver
(Long)
HVE-9000
HDSpider™ HDMI Cat.5
Sender (Cascadable)
HVE-9003
