APART PR1000R Brochure & Specs

PROFESSIONAL RDS AM/FM TUNER
The PR1000R is a professional AM/FM RDS tuner. The unit has a brushed aluminum front, and is
loaded with professional features. It is easy to integrate in rack mounted professional audio
distribution systems, stereo HiFi systems, multi-room audio systems and computer controlled audio
systems. The RDS information is available via the serial port.
This tuner can be controlled by RS232 and infrared, and comes with an IR handheld remote and FM
antenna . For professional use, removable 19-inch rack ears are included.
The PR100R has an output attenuator on the rear panel, and galvanically separated antenna and RS-
232 connectors. The RDS function offers information about program type, song name identification
and radio station identification.
The PR100R is highly recommended for use with Concept1. It has an attractive clear dot matrix gas
display, a very low power consumption and it is designed for 24/7 reliability. Best of all : this unit will
convince your customers to choose a professional system and avoid cheap, unreliable consumer HiFi
sets !

TECHNICAL SPECIFICATIONS

FM tuning range
Presets
AM tuning range
FM sensitivity (26 dB S/N) @ 75 ohm unbalanced
AM sensitivity (26 dB S/N)
FM channel selectivity (200 kHz)
FM channel selectivity (400 kHz)
Audio S/N ratio FM
Audio bandwidth ± 1.5 dB
THD
Stereo separation
Power supply
Power consumption
Power consumption standby mode
Rack ears
WWW.APART-AUDIO.COM
APart PR1000R
87.5 - 108 MHz
40
522 - 1611 kHz
1.1 µV
38 µV
50 dB
70 dB
> 78 dB
30 - 15 kHz
<0.1%
>50 dB @ 1 kHz
230 VAC/50 Hz
max 10 VA
1 watt
included - removable
