Packing And Accessories - Sharp R-320CD Service Manual

REF. NO. PART NO.
6- 8 TINSEA792WRR0
6- 8 TINSEA792WRR0
6- 8 TINSEA792WRR0
6- 8 TINSEA793WRR0
6- 8 TINSEA793WRR0
6- 9 TCAUAA240WRR0
6-10 TCADCA685WRR0
6-10 TCADCA685WRR0
7- 1 XHPSD40P08K00
7- 2 XHPSD30P06000
7- 3 XHTSD40P08RV0
7- 4 XHTSD40P12RV0
7- 5 XOTSD40P12RV0
7- 6 XOTSD40P12000
7- 7 XOTSF40P08000
7- 7 XOTSF40P08000
7- 7 XOTSE40P08000
7- 7 XOTSE40P08000
7- 7 XOTSE40P08000
7- 8 LX-CZA070WRE0
To have your order filled promptly and correctly, please furnish the following information.
Order Parts from the authorized SHARP parts Distributor for your area.
Defective parts requiring return should be returned as indicated in the Service Policy.

PACKING AND ACCESSORIES

INTO THE
OVEN CAVITY
Instruction book [R-320CD]
Instruction book [R-320CK]
Instruction book [R-320CW]
Instruction book [R-330CK]
Instruction book [R-330CW]
Screw caution
Recipe sheet [R-330CK]
Recipe sheet [R-330CW]
SCREWS,NUTS AND WASHERS
Screw : 4mm x 8mm
Screw : 3mm x 6mm
Screw : 4mm x 8mm
Screw : 4mm x 12mm
Screw : 4mm x 12mm
Screw : 4mm x 12mm
Screw : 4mm x 8mm [R-320CK]
Screw : 4mm x 8mm [R-330CK]
Screw : 4mm x 8mm [R-320CD]
Screw : 4mm x 8mm [R-320CW]
Screw : 4mm x 8mm [R-330CW]
Special screw (Torx tamper proof screw)
HOW TO ORDER REPLACEMENT PARTS
1. MODEL NUMBER
3. PART NO.
DOOR PROTECTION SHEET
SPADPA204WRE0
6- 8 INSTRUCTION BOOK
& PRINTING MATTER
6-10 RECIPE SHEET
(for R-330CK/CW)
6- 2 TURNTABLE TRAY
6- 1 TURNTABLE SUPPORT
TRAY PACK
SPADFA451WRE0
Not replaceable items.
43
DESCRIPTION
2. REF. NO.
4. DESCRIPTION
R-320CD/CK/CW
R-330CK/CW
Q'TY CODE
1 AE
1 AE
1 AE
1 AK
1 AK
1 AC
1 AE
1 AE
9 AA
3 AA
2 AA
1 AA
6 AA
15 AA
1 AA
1 AA
1 AA
1 AA
1 AA
2 AC
TOP PAD ASSEMBLY
FPADBA395WRK0
PLASTIC BAG
SSAKHA034WRE0
BOTTOM PAD ASSEMBLY
FPADBA396WRK0
PACKING CASE
SPAKCD233WRE0 [R-320CD]
SPAKCD205WRE0 [R-320CK]
SPAKCD207WRE0 [R-320CW]
SPAKCD206WRE0 [R-330CK]
SPAKCD208WRE0 [R-330CW]
