Sanyo DP42848 Service Manual

Remote control digital color television
Hide thumbs

Advertisement

SERVICE MANUAL
Servicing should be performed by only trained and qualified service personnel.
Contents
SAFETY INSTRUCTIONS. . . . . . . . . . . . . . . . . . . . . . . . . 2
SERVICE ADJUSTMENTS . . . . . . . . . . . . . . . . . . . . . . . . 3
ON-SCREEN SERVICE MENU . . . . . . . . . . . . . . . . . . . . . 4
POWER FAILURE CIRCUIT . . . . . . . . . . . . . . . . . . . . . . . 5
MECHANICAL DISASSEMBLY. . . . . . . . . . . . . . . . . . . 6-8
CHASSIS ELECTRICAL PARTS LIST . . . . . . . . . . . . . 9-24
CABINET PARTS LIST . . . . . . . . . . . . . . . . . . . . . . . . . . 25
BLOCK DIAGRAM POWER LINES. . . . . . . . . . . . . . . . . 29
BLOCK DIAGRAM SIGNAL LINES . . . . . . . . . . . . . . . . 30
IC BLOCK DIAGRAMS . . . . . . . . . . . . . . . . . . . . . . . 31-38
TROUBLESHOOTING FLOW CHARTS . . . . . . . . . . 39-41
CONTROL PORT FUNCTIONS . . . . . . . . . . . . . . . . . 42-43
SIGNAL FLOW CHARTS . . . . . . . . . . . . . . . . . . . . . . 44-51
SCHEMATIC NOTES . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
SCHEMATIC DIAGRAMS . . . . . . . . . . . . . . . . . . . . . 56-57
DP42848, N4VJ, PRODUCT CODE 113015308
Remote Control Digital
Color Television
FILE NO.
DP42848
ORIGINAL VERSION
Chassis No. P42848-00
NOTE: Match the Chassis No. on
the unit's back cover with
the Chassis No. in the
Service Manual.
If the Original Version
Service Manual Chassis
No. does not match the
unit's, additional Service
Literature is required. You
must refer to "Notices" to
the Original Service Manual
prior to servicing the unit.

Specifications

POWER RATING . . . . . . . . . . . . . . . . . . . . . . . . . 120VAC
ANTENNA INPUT IMPEDANCE. . . . . . . . . . . . . . . . . 75Ω
RECEIVING CHANNEL . . . . . . . . . . . . . . . . . 2 - 13 (VHF),
REMOTE READY. . . . . . . . . 32 KEY REMOTE CONTROL
SOUND OUTPUT. . . . . . . . . . . . . . . . . . . . . . . . 5.0 W/CH
INTERMEDIATE FREQUENCY
PICTURE IF CARRIER . . . . . . . . . . . . . . . . . . 45.75MHz
SOUND IF CARRIER . . . . . . . . . . . . . . . . . . . 41.25MHz
COLOR SUB CARRIER . . . . . . . . . . . . . . . . . 42.17MHz
CABINET DIMENSIONS
WIDTH . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1049mm
HEIGHT. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 754.4mm
DEPTH INCLUDING BASE . . . . . . . . . . . . . . . 259.1mm
REFERENCE No.
(U.S.A.)
(CANADA)
240W (AVG.)
UHF/VHF/CATV
DIGITAL
14 - 69 (UHF),
01, 14-94, 95-135 (CATV)
1-135 (DIGITAL)
SM
780152
