Bradford White M-1-20L6DS Specification

Energy Saver Electric Water Heater
Photo is of
M-1-20L6DS
Copper Screw Type Immersion Element
(Incoloy type immersion element available upon request)
MANUFACTURED UNDER ONE OR MORE OF THE FOLLOWING U.S. PATENTS: 5,954,492; 5,761,379; 5,943,984; 5,081,696; 5,988,117; 6,142,216; 5,199,385; 5,574,822; 5,372,185; 5,485,879; 5,277,171;
(B1)5,341,770; 5,660,165; 5,596,952; 5,682,666; 4,904,428; 5,023,031; 5,000,893; 4,669,448; 4,829,983; 4,808,356; 5,115,767; 5,092,519; 5,052,346; 4,416,222; 4,628,184; 4,861,968; 4,672,919; Re. 34,534;
7,270,087 B2. OTHER U.S. AND FOREIGN PATENT APPLICATIONS PENDING. CURRENT CANADIAN PATENTS: 1,272,914; 1,280,043; 1,289,832; 2, 0 45,862; 2,112,515; 2,108,186; 2,107,012; 2,092,105; 2,409,271.
Vitraglas and Hydrojet are registered trademarks of Bradford White
® ®
Residential Lowboy
The Lowboy Electric Models Feature:
DOE—All residential storage models above 20 gallon capacity meet or
exceed efficiency requirements of the Department of Energy, ASHRAE
Standard 90.1 b (current standard) and the National Appliance Energy
Conservation Act of 1987 recent amendment effective January 20, 2004
which supercedes all state and local efficiency requirements.
Applications—Standing at a height of less than 33", Lowboy models are ideal
for installations where space is at a premium and are perfect for tight
installations such as a closet or under a counter.
Fully Automatic Controls—Fast acting surface-mount thermostats for
automatic temperature control. Factory installed sensitive manual reset energy
cut-off for safety to prevent overheating.
Direct Heat Transfer With Immersed Elements—Transfers heat directly
and efficiently to the water. Screw-in style.
Factory Installed Hydrojet
sediment reducing device helps prevent sediment build up in tank. Increases
first hour delivery of hot water while minimizing temperature build up in tank.
Vitraglas
®
engineered formula that provides superior protection from the highly corrosive
effects of hot water. This formula (Vitraglas
firing at a temperature of over 1600º F.
2" Non-CFC Foam Insulation—Covers the sides and top of the tank,
reducing the amount of heat loss. This results in less energy consumption,
improved operation efficiencies and jacket rigidity.
Water Connections—3⁄4" NPT factory installed true dielectric fittings extend
water heater life and eases installation.
Factory Installed Heat Traps—Design incorporates a flexible disk that
reduces heat loss in piping and eliminates the potential for noise generation.
Protective Magnesium Anode Rod—Provides added protection against
corrosion for long trouble-free service.
Simultaneous and Non-Simultaneous Operation Available—
Simultaneous operation indicates when both elements (if equipped) are being
heated at the same time. Non-Simultaneous operation indicates when one
element is being heated at a time.
Voltages Available—120V, 208V, 240V, 277V, 480V.
Single Phase or Three Phase Operation Available—277V may only be
wired for single phase operation.
T&P Relief Valve Included—Side T&P is standard. Optional top T&P
location is available.
Low Restriction Brass Drain Valve—Durable tamper proof design.
Design evaluated by ETL in accordance with Part 280.707(d) of HUD
Mobile Home Construction and Safety Standards for Energy Efficiency.
6 or 10-Year Limited Tank Warranties / 6 or 10-Year Limited Warranty on Component Parts.
For more information on warranty, please visit www.bradfordwhite.com
For products installed in USA, Canada and Puerto Rico. Some states do not allow limitations on warranties. See complete
copy of the warranty included with the heater.
Corporation.
®
Total Performance System—Cold water inlet
®
Lining—Bradford White tanks are lined with an exclusively
) is fused to the steel surface by
®
203-B-1212
