2kW Studio Fresnel
P.O. Box 2210 • Tualatin, Oregon 97062 Phone: (503) 404-5500 • Fax: (503) 404-5600
Features
• High intensity spot with a smooth, even flood field
• Pole-operated versions provide maximum flexibility
for studio lighting applications
• State-of-the-art ventilation system guarantees cooler
unit operations with extended lamp and gel life
• All operating controls thermally insulated for cool
handling operations
• Torlon‚ insulators provide smooth focusing operation
• Lightweight, rugged construction
• Split diamond design for extreme reliability
Dimensional Data
A
B
C
Weight
Copyright © 1994, 2001, Leviton Mfg. Co. Inc.
Manual 1-0085
Pole-Op 1-1085
............................
– in. [cm] lbs.[kg]
17.25 [43.85]
18.00 [45.72]
16.25 [41.27]
31.00 [14.00]
Advertisement
Table of Contents
Related Manuals for Leviton 1-0085
Summary of Contents for Leviton 1-0085
- Page 1 • Split diamond design for extreme reliability Dimensional Data – in. [cm] lbs.[kg] 17.25 [43.85] 18.00 [45.72] 16.25 [41.27] Weight 31.00 [14.00] P.O. Box 2210 • Tualatin, Oregon 97062 Phone: (503) 404-5500 • Fax: (503) 404-5600 Copyright © 1994, 2001, Leviton Mfg. Co. Inc.
-
Page 2: Specifications
• For field diameter at any distance, multiply that distance by .265 for spot and 1.32 for flood Beam Candlepower Spot 366,000 Flood 39,500 P.O. Box 2210 • Tualatin, Oregon 97062 Phone: (503) 404-5500 • Fax: (503) 404-5600 Copyright © 1994, 2001, Leviton Mfg. Co. Inc. Literature # 28-MKCTN-000...
