  • Page 1 DES-2108 8-port 10/100 Fast Ethernet Switch User’s Guide 2007/6/13...
  • Page 2 CE Mark Warning This is a Class B product. In a domestic environment, this product may cause radio interference in which case the user may be required to take adequate measures. Warnung! Dies ist ein Produkt der Klasse B. Im Wohnbereich kann dieses Produkt Funkstoerungen verursachen.

  • Page 3: Table Of Contents

    ABLE OF ONTENTS About This Guide ................1 Terms Overview of this User’s Guide 1 Introduction..................2 Fast Ethernet Technology Switching Technology Switch Description Features Ports Unpacking and Setup ................6 Unpacking 6 Setup Mounting the Switch on a Wall 7 Power on Identifying External Components ............
  • Page 4 Introduction To Switch Management ..........10 Management Options 11 SmartConsole Utility 11 Web-based Management Interface Command Line Interface (CLI) SNMP-Based Management Configuration The Switch..............12 SmartConsole Utility 12 Installing SmartConsole Utility.......... 12 Discovered Devices ............13 Monitor List ............... 14 Device Setting..............
  • Page 5 System > SNTP Settings ............ 29 Configuration > 802.1Q VLAN......... 30 Configuration > Trunk ............32 Configuration > IGMP Snooping........33 Configuration > 802.1D Spanning Tree......36 Configuration > Port Mirroring ......... 38 QoS > 802.1p Default Priority ........... 39 Security >...
  • Page 6 VLAN Commands ............. 61 Port Mirroring Commands ..........64 Trap Commands..............67 Spanning Tree Commands ..........72 SNMP Commands ............. 77 IGMP Snooping Commands ..........83 Static MAC Commands ............. 91 Trusted Host Commands............ 95 Trunk Commands............... 97 SNTP Commands............... 99 System Log Commands ...........

  • Page 7: About This Guide

    BOUT UIDE This user’s guide will show you how to install your DES-2108, and how to connect it to your network. Terms For simplicity, this documentation uses the terms “Switch” (first letter upper case) to refer to the DES-2108, and “switch” (first letter lower case) to refer to all Ethernet switches, including the DES-2108.

  • Page 8: Introduction

    NTRODUCTION This section describes the features of the DES-2108, as well as giving some background information about Fast Ethernet and Switching technology. Fast Ethernet Technology The growing importance of LANs and the increasing complexity of desktop computing applications are fueling the need for high performance networks.

  • Page 9: Switch Description

    Switch Description The DES-2108 is equipped with unshielded twisted-pair (UTP) cable ports providing dedicated 10 or 100 Mbps bandwidth. The Switch has 8 UTP ports and Auto MDI-X/MDI-II convertible ports that can be used for up-linking to another switch.

  • Page 10: Features

    Management engine can be configure the Switch's settings for priority queuing, VLANs, and port monitoring, and port speed. Features The DES-2108 was designed for easy installation and high performance in an environment where traffic on the network and the number of users increase continuously.

  • Page 11: Ports

    Supports a packet buffer of up to 256 Kbytes. IGMP Snooping support. SNMP support. Port Mirror support. MIB support for: RFC1213 MIB II. Private MIB. Ports Eight (8) 10/100Mbps 100BASE-TX (Auto MDI-X/MDI-II) ports for connecting to end stations, servers, hubs and other networking devices. All UTP ports can auto-negotiate between 10Mbps and 100Mbps, half-duplex and full duplex, and flow control.

  • Page 12: Unpacking And Setup

    This chapter provides unpacking and setup information for the Switch. Unpacking Open the shipping carton of the Switch and carefully unpack its contents. The carton should contain the following items: One DES-2108 Fast Ethernet Switch Four rubber feet with adhesive backing One AC power adapter Mounting kit CD-ROM (Including this User’s Guide and Utility)

  • Page 13: Mounting The Switch On A Wall

    Mounting the Switch on a Wall The DES-2108 can also be mounted on a wall. Two mounting slots are provided on the bottom of the switch for this purpose. Please make sure that the front panel is exposed in order to view the LEDs. Please refer to the illustration below.

  • Page 14: Power On

    Power on The DES-2108 can be used with AC power sources 100 - 240 VAC, 50 - 60 Hz. The Switch’s power adapter will adjust to the local power source automatically. Plug one end of the DC output into the power jack of the Switch and the other end into the local power source outlet.

  • Page 15: Rear Panel

    DC Power Jack: Power is supplied through an external DC power adapter. Check the technical specification section for information about the DC power input voltage. DES-2108 does not include a power button, plugging its power adapter into a power outlet will immediately power it on. LED Indicators The LED indicators of the Switch include Power, CPU and Port Status LEDs.

  • Page 16: Power And Cpu Leds

    Figure 4. LED indicators Power and CPU LEDs Power : This LED will light green after the Switch is powered on to indicate the ready state of the device. : When the switch powered off or the power adapter has improper connection.

  • Page 17: Management Options

    Web-based Management Interface Command Line Interface (CLI) SNMP-Based Management Managing Management Options This system may be managed in-band using TCP/IP Telnet protocol and web-based management, accessible through a web browser. SmartConsole Utility With the SmartConsole Utility, you can easily discover all the Web Management Switch, assign the IP Address, change the password and upgrade to new firmware.

  • Page 18: Snmp-Based Management

    SNMP-Based Management You can manage the Switch with an SNMP-compatible console program. The Switch supports SNMP version 1.0. The SNMP agent decodes the incoming SNMP messages and responds to requests with MIB objects stored in the database. The SNMP agent updates the MIB objects to generate statistics and counters.

  • Page 19: Discovered Devices

    Figure 5. SmartConsole Utility The SmartConsole Utility was divided into four parts, Discovery List, Monitor List, Device Setting and Toolbar function, for details instruction, follow the below section. Discovered Devices This is the list where you can discover all the Web management devices in the entire network.

  • Page 20: Monitor List

    IP Address: Shows the current IP address of the device. Protocol version: Shows the version of the Utility protocol. Product Name: Shows the device product name. System Name: Shows the appointed device system name. DHCP: Shows whether the switch’s DHCP is Enabled or Disabled.
  • Page 21 Gateway: Shows the Gateway set of the device. Group Interval: Shows the time that the switch will be discovered in the SmartConsole Utility List. View Trap: The Trap function can receive the events that happen from the Web Management Switch in the Monitor List. There is a light indicator behind the “View Trap”...

  • Page 22: Device Setting

    In factory default, the IP address of the DES-2108 will be automatically assigned from DHCP server (DHCP enabled). If your network has no DHCP server, the DES-2108 will fail to get IP address, and the IP address of DES-2108 will be assigned to default IP address of 192.168.0.1 and netmask is 255.255.255.0.
  • Page 23 Figure 8. Change settings Change password: Used to change the password when deemed necessary. Fill in the desired password and press the “Set” button to change the password. Figure 9. Change password Upgrade firmware: When the device has a new function, there will be a new firmware. Use this function to update.

  • Page 24: Toolbar

    Web Access: Double click the device in the Monitor List or select a device in the Monitor List and press this “Web Access” button to access the device in Web browser. Toolbar The toolbar in the Web Management Utility have four main tabs: File, View, Option and Help.

  • Page 25: Configuring The Switch Using Web Browsers

    Web Management Utility. Configuring the Switch using Web Browsers All software functions of the DES-2108 can be managed, configured and monitored via the embedded web-based (HTML) interface. The Switch can be managed from remote stations anywhere on the network through a standard browser such as Netscape Navigator or Microsoft Internet Explorer.

  • Page 26: Login To Web Manager

    Trunk IGMP Snooping 802.1D Spanning Tree Port Mirroring 802.1d Default Priority Trusted Host Storm Control Bandwidth Control 802.1x Settings Static MAC Dynamic Forwarding Table Statistics Login to Web Manager Before you configure this device, note that when the Web Smart Switch is configured through an Ethernet connection, make sure the manager PC must be set on same the IP network.
  • Page 27 Or you may access the above address through the Web Management Utility, this way you do not need to remember the IP Address. Select the device shown in the Monitor List of the Web Management Utility to configure the device on the Web Browser. When the following dialog page appears, enter the default password "admin"...

  • Page 28: Setup Menu

    Setup Menu When the main page appears, find the Setup menu in the left side of the screen (Figure 4). Click on the setup item that you want to configure. There are twenty options: System Settings, Trap Settings, Port Settings, SNMP Settings, Password Access Control, Syslog, 802.1Q Management VLAN, SNTP Settings, 802.1Q VLAN, Trunk,...
  • Page 29 When using static mode, the IP Address, Subnet Mask and Gateway can be manually configured. When using DHCP mode, the Switch will first look for a DHCP server to provide it with an IP address, network mask, and default gateway before using the default or previously entered settings.

  • Page 30: System > Trap Setting

    System > Trap Setting By configuring the Trap Setting, it allows SmartConsole Utility to monitor specified events on this Web-Smart Switch. By default, Trap Setting is Disabled. When the Trap Setting is Enabled, enter the Destination IP address of the managing PC that will receive trap information.

  • Page 31: System > Port Setting

    System > Port Setting In the Port Setting page, the status of all ports can be monitored and adjusted for optimum configuration. By selecting a range of ports (From Port and To Port), the Speed and Flow Control can be set for all such ports, by clicking Apply.

  • Page 32: System > Snmp Setting

    Priority: Displays each port’s 802.1P QoS priority level for received data packet handling. Default setting for all ports is Middle. You can change the priority settings in Qos > 802.1p Default Priority System > SNMP Setting Simple Network Management Protocol (SNMP) is an OSI Layer 7 (Application Layer) designed specifically for managing and monitoring network devices.
  • Page 33 Figure 18. System > SNMP Setting Enabled / Disabled: Default setting is Disabled. Click Enable, then Apply, to set Community Settings. The default community strings for the Switch used for SNMP v.1 management access are: Public: The community with read-only privilege allows authorized management stations to retrieve MIB objects.

  • Page 34: System > Password Access Control

    events to choose from include: System Device Bootup, Twisted Pair Link Up / Link Down, Twisted Pair Abnormal Receive Error, Twisted Pair Abnormal Transmit Error. System > Password Access Control Setting a password is a critical tool for managers to secure the Web- Smart Switch.

  • Page 35: System > Sntp Settings

    Some operating processes have been assigned Facility values. Processes that have not been explicitly assigned a value may use any of the “local” facilities. Figure 20. System > Syslog System > SNTP Settings Enabled / Disabled: Default setting is Disabled. Click Enable, then Apply, to configure the SNTP Settings.

  • Page 36: Configuration > 802.1Q Vlan

    Figure 21. System > SNTP Settings Configuration > 802.1Q VLAN A VLAN is a group of ports that can be anywhere in the network, but communicate as though they were in the same area. VLANs can be easily organized to reflect department groups (such as R&D, Marketing), usage groups (such as e-mail), or multicast groups (multimedia applications such as video conferencing), and therefore help to simplify network management by allowing users to move...
  • Page 37 Add New VID: Click to create a new VID group, assigning ports from 01 to 08 as Untag, Tag, or Not Member. A port can be “Untagged” in only one VID. To save the VID group, press Apply. You may change the name accordingly to the desired groups, such as the aforementioned R&D, Marketing, email, etc.

  • Page 38: Configuration > Trunk

    Figure 24. Configuration > 802.1Q VLAN > VID Configuration Configuration > 802.1Q VLAN Management VLAN This allows to select a VLAN from which a management station will be allowed to manage the Switch using Web or Telnet. Management stations that are on VLANs other than the selected one will not be able to manage the Switch.

  • Page 39: Configuration > Igmp Snooping

    Configuration > IGMP Snooping With Internet Group Management Protocol (IGMP) snooping, the Web-Smart Switch can make intelligent multicast forwarding decisions by examining the contents of each frame’s Layer 3 IP header. IGMP snooping can help reduce cluttered traffic on the LAN. With IGMP snooping enabled globally, the Web-Smart Switch will forward IP multicast traffic only to connections that have group members attached.
  • Page 40 Max Response Time (10-25 sec): The Max Response Time specifies the maximum allowed time before sending a responding report. Adjusting this setting effects the "leave latency", or the time between the moment the last host leaves a group and when the routing protocol is notified that there are no more members.
  • Page 41 'RouterPortPurgeInterval' time, the learnt router port entry will be purged. Default is 125 seconds. Leave Time (0-25 sec): This is the interval after which a Leave message is forwarded on a port. When a leave message from a host for a group is received, a group-specific query is sent to the port on which the leave message is received.

  • Page 42: Configuration > 802.1D Spanning Tree

    Configuration > 802.1D Spanning Tree 802.1D Spanning Tree Protocol (STP) implementation is a backup link(s) between switches, bridges or routers designed to prevent network loops that could cause a broadcast storm. When physical links forming a loop provide redundancy, only a single path will be forwarding frames.
  • Page 43 Bridge Priority: This value between 0 and 65535 specifies the root switch: the lower the value, the higher the priority. The default is 32768. Bridge Max Age: This value may be set to ensure that old information does not endlessly circulate through redundant paths in the network, preventing the effective propagation of the new information.

  • Page 44: Configuration > Port Mirroring

    Path Priority: Select a value between 0 and 255 to specify the priority for a specified port for forwarding packets: the lower the value, the higher the priority. The default is 128. To refresh the information table and view the latest status, press the Refresh button.

  • Page 45: Qos > 802.1P Default Priority

    Press the All button to assign all ports to the respective mode. QoS > 802.1p Default Priority This feature displays the status Quality of Service priority levels of each port, and for packets that are untagged, the switch will assign the priority in the tag depending on your configuration.

  • Page 46: Security > Storm Control

    Figure 33. Security > Trusted Host To define a management station IP setting, click the Add Host button and type in the IP address and subnet mask then click the Apply button. To delete the IP address simply click the Delete Host button, check the unwanted address then click Apply.

  • Page 47: Security > 802.1X Settings

    Enabled / Disabled: Default setting is Disabled. Click Enable, then Apply, to configure Bandwidth Control. The default value for RX Rate is 8000 bytes per second. Figure 35. Security > Bandwidth Control Security > 802.1x Settings Network switches provide easy and open access to resources by simply attaching a client PC.
  • Page 48 on the configuration of the client software and the RADIUS server. Depending on the authenticated results, the port is either made available to the user, or the user is denied access to the network. The RADIUS servers make the network a lot easier to manage for the administrator by gathering and storing the user lists.

  • Page 49: Security > Mac Address Table > Static Mac

    ReAuthEnabled: This Enables Disables periodic ReAuthentication control. When the 802.1X function is Enabled, the ReAuthEnabled function is by default also Enabled. QuietPeriod: Sets the number of seconds that the switch remains in the quiet state following a failed authentication exchange with the client.

  • Page 50: Security > Mac Address Table > Dynamic Forwarding Table

    Figure 37. Security > MAC Address Table > Static MAC Configuration To initiate the removal of auto-learning for any of the uplink ports, press On to enable this feature, and select the port(s) for auto learning to be disabled. The Static MAC Address Setting table displays the static MAC addresses connected, as well as the VID.

  • Page 51: Monitoring > Statistics

    Figure 38. Security > MAC Address Table > Dynamic Forwarding Table Monitoring > Statistics The Statistics screen displays the status of each port packet count. Figure 39. Monitoring > Statistics Refresh: To renew the details collected and displayed. Clear Counter: To reset the details displayed. TxOK: Number of packets transmitted successfully.

  • Page 52: Configuring The Switch Using The Cli

    Figure 40. Monitoring > Port Statistics Configuring the Switch using the CLI The Switch can be managed through the TCP/IP Telnet protocol. The Command Line Interface (CLI) can be used to configure and manage the Switch via TCP/IP Telnet protocol. This section provides a reference for all of the commands contained in the CLI.

  • Page 53: Using The Cli Via Telnet Interface

    Where ip-address is the IP address you have assigned to the Switch. When you telnet to the Switch, it displays its login-in message: Figure 42. The DES-2108 console login At this point you can enter the password you have assigned to your...

  • Page 54: Command Syntax

    The Switch will then display the telnet interface CLI command prompt: Figure 43. DES-2108 CLI command prompt Command Syntax The following symbols are used to describe how command entries are made and values and arguments are specified in this manual. The online help contained in the CLI and available through console interface uses the same syntax.

  • Page 55: Basic Switch Commands

    Syntax show snmp [community | host] In the above syntax sample, you must specify Description either a community or host configuration to be show. Example show snmp community Command | vertical bar Purpose Separates two or more mutually exclusive items in a list, one of which must be entered.
  • Page 56 Command Parameters show switch <config> reset logout save <system_contact 96> config switch system_contact <system_name 20> config switch system_name config switch <system_location 20> system_location config switch < value 0~1000000 sec> system_agingtime <value 3~30 min> config switch system_timeout Each command is listed, in detail, in the following sections. show switch Used to display general information about the Purpose...
  • Page 57 Figure 44. show switch command reset Used to reset the Switch to the factory default Purpose setting Syntax reset <config> The command is used to restore the Switch’s Description configuration to the default setting assigned from the factory. Parameters config - All of the factory default settings are restored on the Switch including the IP address.
  • Page 58 logout Used to log out a user from the Switch’s console. Purpose Syntax logout This command terminates the current session on Description the Switch’s console. None. Parameters Example usage: To terminate the current telnet console session: Figure 46. logout command save Used save...

  • Page 59: Config Switch System_Contact

    Figure 47. save command config switch system_contact Used to enter the name of a contact person who Purpose is responsible for the Switch. Syntax config switch system_contact <system_contact 96> The config snmp system_contact command is Description used to enter the name and/or other information to identify a contact person who is responsible for the Switch.

  • Page 60: System_Location

    The config switch system_name command Description configures the name of the Switch. Parameters <system_name 20> - A maximum of 20 character can be used, space character is not allowed. Example usage: To configure the Switch name for “Sales-SW-1”: Figure 49. config switch system_name command config switch system_location Used to enter a description of location of the Purpose...

  • Page 61: Config Switch System_Agingtime

    config switch system_agingtime Used to set the aging time of the forwarding Purpose database. Syntax config switch system_agingtime <value 0~1000000 sec> The aging time affects the learning process of Description the Switch. Dynamic forwarding table entries, which are made up of the source MAC addresses and their associated port numbers, are deleted from the table if they are not accessed within the aging time.

  • Page 62: Basic Ip Commands

    config switch system_timeout Specifies the maximum amount of time a host Purpose can access the management interface. The default is 5 minutes Syntax config switch system_timeout <value 3~30 min> The command is used to configure the maximum Description amount of time a host can access the management interface.

  • Page 63: Switch Port Commands

    config ipif Used to configure the System IP interface. Purpose Syntax config ipif [ipaddress <network address> | {gw <ipaddress>} | dhcp {vid <vid 1~4094>}] This command is used to configure the System Description IP interface on the Switch. Parameters ipaddress <network address> - IP address and netmask of the IP interface to created.
  • Page 64 IP interface of the Switch. Parameters None. Example usage: To display IP interface settings: Figure 54 show ipif command Switch Port Commands The switch port commands in the Command Line Interface (CLI) are listed (along with the appropriate parameters) in the following table. Command Parameters <portlist | all>...
  • Page 65 config ports Used to configure the Switch’s Ethernet port Purpose settings. Syntax <portlist | all> [speed <disable |auto |10_half | 10_full | 100_half | 100_full> | flow_control <enable | disable> | qos <low | medium | high | highest>] This command allows for the configuration of the Description Switch’s Ethernet ports.
  • Page 66 Figure 55. config ports command show ports Used to display current configuration of a range Purpose of ports. Syntax show ports <portlist> This command is used to display current Description configuration of a range of ports. Specifies a port or range of ports to be Parameters <portlist>...

  • Page 67: Vlan Commands

    Figure 56. show ports command VLAN Commands The VLAN commands in the Command Line Interface (CLI) are listed (along with the appropriate parameters) in the following table. Command Parameters create vlan create vlan tag <vid 1~4094> desc <vlan_name 20> delete vlan tag <vid 1~4094> delete vlan config vlan config vlan vid <vid 1~4094>...
  • Page 68 Parameters <vid 1~4094> VLAN 802.1Q_based VLAN to be created. Allowed values = 1~4094 <vlan_name 20> - The name of VLAN to be created. A maximum of 20 characters can be used. Example usage: To create a VLAN group “sales” with VID 2: Figure 57.
  • Page 69 config vlan Used to add ports to a previously configured Purpose VLAN. Syntax config vlan vid <vid 1~4094> {add [tagged | untagged] | delete} <port_list> This command allows you to add ports to the port Description list of previously configured VLAN. Parameters <vid 1~4094>...

  • Page 70: Port Mirroring Commands

    Figure 60. config vlan command, delete VLAN group members show vlan Used to show VLAN status. Purpose Syntax show vlan {tag <vid 1~4094>} This command allows you to show VLAN status Description on the Switch. Parameters <vid 1~4094> VLAN 802.1Q_based VLAN to be created. Allowed values = 1~4094 Example usage: To show VLAN status:...
  • Page 71 Command Parameters {enable [<port> source ports config mirror port <portlist> [rx | tx |both]] | disable} show mirror Each command is listed, in detail, in the following sections. config mirror port Used to configure a mirror port – source port pair Purpose on the Switch.
  • Page 72 Figure 62. config mirror port command To disable Port Mirror function of the Switch: Figure 63. config mirror port command, disable port mirror function show mirror Used to show the current mirroring configuration Purpose on the Switch. Syntax show mirror This command displays the current mirroring Description configuration on the Switch...

  • Page 73: Trap Commands

    Figure 64. show mirror command Trap Commands The trap mirroring commands in the Command Line Interface (CLI) are listed (along with the appropriate parameters) in the following table. Command Parameters enable discovery disable discovery ipaddress <ip_address> config discovery trap_ip config discovery trap_event [bootup | illegal_login | t_link]...
  • Page 74 Parameters None. Example usage: To enable the discovery trap function: Figure 65. enable discovery command disable discovery Used to the disable the discovery trap function to Purpose SmartConsole Utility. Syntax disable discovery Description The command is used to the disable the discovery trap function to SmartConsole Utility.
  • Page 75 Syntax config discovery trap_ip ipaddress <ip_address> The command is configure an IP address of the Description trap recipient of SmartConsole Utility to the Switch. Parameters <ip_address> - IP address Management Utility. Example usage: To assigned IP address of the Web Configuration Utility to receive trap message: Figure 67.
  • Page 76 Figure 68. config discovery trap_event command delete discovery trap_event Used to delete previously configured events of Purpose trap on the Switch. Syntax trap_event [bootup | illegal_login | t_link] The command is delete previously configured Description events of trap on the Switch. Parameters bootup - Enabled the Switch’s boot up event.
  • Page 77 Figure 69. delete discovery trap_event command show discovery trap Used to show the configuration of the discovery Purpose trap on the Switch. Syntax show discovery trap The command is display the configuration of the Description discovery trap on the Switch.. None.

  • Page 78: Spanning Tree Commands

    Spanning Tree Commands The spanning tree commands in the Command Line Interface (CLI) are listed (along with the appropriate parameters) in the following table. Command Parameters enable stp disable stp [maxage <value 6-40> | hellotime config stp <value 1-10> | forwarddelay <value 4-30>...
  • Page 79 disable stp Used to disable STP on the Switch. Purpose Syntax disable stp This command allows the Spanning Tree Description Protocol to be disabled on the Switch. None. Parameters Example usage: To disable STP on the Switch: Figure 72. disable stp command config stp Used to setup STP on the Switch.
  • Page 80 and a BPDU has still not been received from the Root Bridge, the Switch will sending its own BPDU to all other switches for permission become the Root Bridge. If it turns on that your switch has the lowest Bridge identifier, it will become the Root Bridge.
  • Page 81 config stp ports Used to setup STP on the port level. Purpose Syntax config stp ports [all | <portlist>] {cost <value 1-65535> | priority <value 0-255>} This command is used to create and configure Description STP for a group of ports. Parameters [all | <portlist>] - Specifies all ports or range of ports to be configured.
  • Page 82 This command displays the Switch’s current STP Description configuration. None. Parameters Example usage: To display the status of STP on the Switch: Figure 75. show stp command show stp ports Used to display the Switch’s current STP group Purpose of ports configuration on the Switch. Syntax show stp ports {portlist} This command displays the STP group of...

  • Page 83: Snmp Commands

    Figure 76. show stp ports command SNMP Commands The SNMP commands in the Command Line Interface (CLI) are listed (along with the appropriate parameters) in the following table. Command Parameters enable snmp disable snmp [read_only|read_write] comm_name config snmp <name 20> community show snmp community enable snmp traps...
  • Page 84 enable snmp Used to enable SNMP community string from the Purpose Switch. Syntax enable snmp This command is used to enable SNMP Description community string from the Switch . None Parameters Example usage: To enable the SNMP community string: Figure 77. enable snmp command disable snmp Purpose Used to disable SNMP community string from the...
  • Page 85 Figure 78. enable snmp command config snmp community Used to configure a SNMP community string to Purpose define the relationship between the SNMP manager and an agent. The community string acts like a password to permit access to the agent on the Switch. One or more of the following characteristics can be associated with the community string.
  • Page 86 Example usage: To config the SNMP community read only community name “public”: Figure 79. config snmp community command show snmp community Used to display SNMP community strings Purpose configured on the Switch. Syntax show snmp community This command is used to display SNMP Description community strings that are configured on the Switch.
  • Page 87 enable snmp traps Used to enable the Switch to send traps to the Purpose recipient . Syntax enable snmp traps This command is used to enable the Switch to Description send traps to the recipient . None Parameters Example usage: To enable the SNMP trap generator: Figure 81.
  • Page 88 Figure 82. disable snmp command config snmp trap Used to config a recipient of SNMP traps Purpose generated by the Switch’s SNMP agent. Syntax config snmp trap trap_ip < ipaddress > trap_name <name 20> trap_event <bootup | t_link | t_rx_error | t_tx_error> This command creates a recipient of SNMP traps Description generated by the Switch’s SNMP agent...

  • Page 89: Igmp Snooping Commands

    show snmp trap Used to display the recipient of SNMP traps Purpose generated by the Switch’s SNMP agent. Syntax show snmp trap Description This command is used to display the IP addresses and configuration information of remote SNMP managers that are designated as recipients of SNMP traps that are generated by the Switch’s SNMP agent.
  • Page 90 disable igmp_snooping show router_ports show igmp_snooping group config igmp_snooping {[host_timeout <sec 130-1225> | router_timeout <sec 60-600> query_interval <sec 60-600> response_time <sec 10-25> robustness_variable <sec 1-255> | lmquery_interval <sec 1-25> leave_time <sec 0-25> [enable|disable] vid <vid>} Each command is listed, in detail, in the following sections. config router_ports Used to configure ports as router ports.
  • Page 91 Figure 85. config router_ports command (add static router ports) To delete static router ports: Figure 86. config router_ports command (delete static router ports) enable igmp snooping Purpose Used to enable IGMP snooping on the Switch. Syntax enable igmp_snooping This command allows you to enable IGMP Description snooping on the Switch.

  • Page 92: Disable Igmp_Snooping

    Figure 87. enable igmp snooping command disable igmp snooping Used to disable IGMP snooping on the Switch. Purpose Syntax disable igmp_snooping This command disables IGMP snooping on the Description Switch. None. Parameters Example usage: To disable IGMP snooping on the Switch: Figure 88.

  • Page 93: Show Igmp_Snooping

    Figure 89. show router_ports command show igmp_snooping group Used to display the current IGMP snooping Purpose configuration on the Switch. Syntax show igmp_snooping group This command will display the current IGMP Description setup currently configured on the Switch. None. Parameters Example usage: To view the current IGMP snooping group: Figure 90.

  • Page 94: Config Igmp_Snooping

    config igmp_snooping Used to configure IGMP snooping on the Switch. Purpose Syntax config igmp_snooping {[host_timeout <sec 130-1225> | router_timeout <sec 60-600> | query_interval <sec 60-600> | response_time <sec 10-25> | robustness_variable <sec 1- 255> | lmquery_interval <sec 1-25> | leave_time <sec 0-25>] | [enable|disable] vid <vid>} This command allows you to configure IGMP Description...
  • Page 95 Parameters host_timeout <sec 1-1225> − Specifies the maximum amount of time a host can be a member of a multicast group without the Switch receiving a host membership report. The default is 260 seconds. router_timeout <sec 1-600> − Specifies the maximum amount of time a route can be a member of a multicast group without the Switch receiving a host membership report.

  • Page 96: Leave_Time

    Parameters lmquery_interval <sec 1-25> - The last Member query interval is the max response time inserted into group-specific queries sent in response to leave group messages, and is also the amount of time between group-specific query messages. This value may be adjusted to modify the "leave latency"...

  • Page 97: Static Mac Commands

    Static MAC Commands The layer 2 forwarding database commands in the Command Line Interface (CLI) are listed (along with the appropriate parameters) in the following table. Command Parameters config auto_learning [on ports <port_list | null> | off ] show smac port <port no.>...
  • Page 98 Figure 92. enable auto_learning function show smac Used to display the Static MAC address Purpose forwarding database. Syntax show smac This command allows you to display the Static Description MAC address forwarding database. None. Parameters Example usage: Figure 93. show Static MAC address forwarding database show fdb Used to display the dynamic MAC address Purpose...
  • Page 99 Figure 94. show Dynamic MAC address forwarding database...
  • Page 100 create smac (802.1Q) Purpose Used to create a static entry to the unicast MAC address forwarding table (database). Syntax [mac <macaddress> port <port no.> vid <vid> | idx <mac address index list on smac>] This command allows you to create a static MAC Description entry in the forwarding table for the specified VLAN.

  • Page 101: Trusted Host Commands

    Trusted Host Commands The Trusted Host commands in the Command Line Interface (CLI) are listed (along with the appropriate parameters) in the following table. Command Parameters [ipaddress <ipaddress>/<ipmask>] create host [ipaddress <ipaddress> delete host <trusted host index>] show host Each command is listed, in detail, in the following sections. create host Used to create the trusted host.
  • Page 102 delete host Used to remove the trusted host. Purpose Syntax [ipaddress <ipaddress> | idx <trusted host index>] This command will remove the trusted host that Description has been created. Parameters ipaddress <ipaddress> - Delete a existing trusted host according to the host IP address. idx <trusted host index>...

  • Page 103: Trunk Commands

    show host Purpose Used to display the trusted host that has been created. Syntax show host This command allows you to display the trusted Description remote stations to manage the Switch. None. Parameters Example usage: Figure 99. show host command Trunk Commands The Trunk commands in the Command Line Interface (CLI) are listed (along with the appropriate parameters) in the following table.
  • Page 104 Used to configure trunk groups. Purpose Syntax config link_aggregation group_id <group_id 1-4> ports <port_list | null > desc <trunk name 20> This command is used to configure trunk Description groups. Parameters <group_id 1-4> - Specify which trunk group to configure <port_list>...

  • Page 105: Sntp Commands

    Example usage: To display the status of all trunk group: Figure 101. show link_aggregation command SNTP Commands The SNTP commands in the Command Line Interface (CLI) are listed (along with the appropriate parameters) in the following table. Command Parameters enable sntp disable sntp show sntp ipaddress <ipaddress>...
  • Page 106 <30|60|90|120> time <±HHMM> config sntp_dst from/to day <day> week <week> month <month> time <HHMM> Each command is listed, in detail, in the following sections. enable sntp Used to enable SNTP support. Purpose Syntax enable sntp This command is used to enable SNTP server Description support .
  • Page 107 Figure 103. disable sntp command show sntp Used to display SNTP status. Purpose Syntax show sntp Description This command is used to display SNTP status . None. Parameters Example usage: To display SNTP status of the switch: Figure 104. show sntp command create sntp_server Used to add.SNTP server which the SNTP...
  • Page 108 Parameters <ipaddress> - The IP address of SNTP server <port number 1~65535> - The UDP port number of SNTP server Example usage: To add SNTP server 192.168.0.100 into server list: Figure 105. create sntp_server command delete sntp_server Used to remove SNTP server from server list. Purpose Syntax delete sntp_server idx <index 1-10>...
  • Page 109 Used to display the SNTP server list. Purpose Syntax show sntp_server This command is used to display the SNTP Description server list. Parameters <index 1-10> - The sntp server index in server list Example usage: To display the SNTP server list: Figure 107.
  • Page 110 Figure 108. enable sntp_dst command disable sntp_dst Used to disable time adjustments to allow for the Purpose use of DST. Syntax enable sntp_dst This command used disable time Description adjustments of DST None Parameters Example usage: To disable Daylight Savings Time adjustment: Figure 109.
  • Page 111 summertime. The possible offset times are 30,60,90,120. time <±HHMM> - Indicates time adjustment +/- HH:MM from GMT Example usage: To configure the SNTP Daylight Savings Time offset minutes and timezone: Figure 119. config sntp_dst timezone command config sntp_dst from/to Used to configure the repeating mode of DST Purpose time adjustment.

  • Page 112: System Log Commands

    Example usage: To configure the repeating mode: Figure 110. config sntp_dst command from/to System Log Commands The System Log commands in the Command Line Interface (CLI) are listed (along with the appropriate parameters) in the following table. Command Parameters enable syslog disable syslog Ipaddress <ipaddress>...
  • Page 113 None. Parameters Example Usage: Figure 111. enable syslog command disable syslog Purpose Used to disable the System Log on the switch. Syntax disable syslog This command allows you to disable System Log Description on the switch. None. Parameters Example Usage: Figure 112.
  • Page 114 Parameters Ipaddress <ipaddress> - The IP address of syslog server. port <port> - The port number corresponding to the system log address. facility <local0-7> - Assign a facility value to the system log Example Usage: Figure 113. create syslog_server command delete syslog_server Used to delete a server for the system log.
  • Page 115 show syslog_server Used to display the System Log server status. Purpose Syntax show syslog_server This command allows you to see the System Log Description server status on the switch. None. Parameters Example Usage: Figure 115. show syslog_server command show syslog Used to display the System Log on the switch.

  • Page 116: X Commands

    802.1x Commands The 802.1x commands in the Command Line Interface (CLI) are listed (along with the appropriate parameters) in the following table. Command Parameters enable 802.1x disable 802.1x <IP> port <port> key <key> config radius [auth_configuration [enable_reauth config 802.1x <enable | disable> | quiet_period <secs 0-65535>...
  • Page 117 Figure 117. enable 802.1x command disable 802.1x Used to disable 802.1x on the switch Purpose Syntax Disable 802.1x This command allows you to disable 802.1x Description None. Parameters Example Usage: Figure 118. disable 802.1x command config radius Used to configure the radius of 802.1x on the Purpose switch.
  • Page 118 Example Usage: Figure 119. config radius 802.1x command config 802.1x Used to configure 802.1x on the switch. Purpose [auth_configuration [enable_reauth <enable | Syntax disable> | quiet_period <secs 0-65535> | tx_period <secs 1-65535> | supp_timeout <secs 1-65535> | server_timeout <secs 1-65535> | max_req <secs 1-10>...
  • Page 119 before it times out the authentication session. Default is 5 times. reauth period <reauth_period> This command affects the behavior of the switch only if periodic re-authentication is enabled. Default is 3600 port <port_list> - the port number set for direct monitoring Example Usage: Figure 120.
  • Page 120 show 802.1x Used to display the current status of 802.1x on Purpose the switch. Syntax [auth_configuration | auth_state | port <port_list>] This command allows you to see the current Description status of 802.1x on the switch. Parameters port <port_list> the list of ports and the port number set for direct monitoring Example Usage: Figure 121.
  • Page 121 Management VLAN Commands The Management VLAN commands in the Command Line Interface (CLI) are listed (along with the appropriate parameters) in the following table. Command Parameters [enable <vid>|disable] config mgt_vlan Each command is listed, in detail, in the following sections. config mgt_vlan Used to configure the management VLAN Purpose...
  • Page 122 Figure 123. config mgt_VLAN disable command...
  • Page 123 ECHNICAL PECIFICATIONS General IEEE 802.3 10BASE-T Ethernet IEEE 802.3u 100BASE-TX Fast Ethernet Standards: ANSI/IEEE 802.3 Auto-negotiation IEEE 802.3x Full duplex Flow Control Protocol: CSMA/CD Data Ethernet: 10Mbps (half-duplex), 20Mbps (full-duplex) Transfer Fast Ethernet: 100Mbps (half-duplex), 200Mbps (full-duplex) Rate: Star Topology Ethernet: 2-pair UTP Cat.
  • Page 124 Physical and Environmental DC inputs: DC 5V/2A 9 watts maximum Power Consumption: Operating 0 ~ 40 degrees Celsius Temperature: -10 ~ 70 degree Celsius Storage Temperature: Humidity: 10% ~ 90% RH, non-condensing Dimensions: 192.5 x 118.5 x 32 mm (W x H x D) CE Class B EMI: Performance...
