Radial ProD8 Owner's Manual

TABLE OF CONTENTS

Introduction .................................................................... Inside Cover
ProD8 Overview ............................................................................... 1
Feature Functions ............................................................................ 2
Rackmounting .................................................................................. 3
Using the ProD8 ............................................................................... 4
Adding Effects .................................................................................. 5
Typical Stage Set-up ........................................................................ 6
Redundant Inputs for Backup Instruments ....................................... 7
Redundant Inputs for Backup Playback ........................................... 8
FAQ .................................................................................................. 9
Warranty Information .........................................................Back Cover
Congratulations on your purchase of the Radial ProD8.
The Radial ProD8 is a simple yet remarkably clever direct box in that it provides all of the standard features
one would find in a typical rackmount DI plus several refinements: First off, it jams eight (8) direct boxes into
a single rack space making it the highest density DI on the market. Secondly, it is equipped with redundant
inputs on each channel that are pre-merged mono to reduce mixer and snake channel requirements or can
be used as redundant inputs for system backup. Thirdly, an effects-loop on each channel lets you share
your effect with two devices saving money and space. And finally, reversible rack rails let you position the
inputs and the outputs on the front or back of the rack to best accommodate your live or studio set-up.
As with all Radial products, we highly recommend that you read this short manual before using the ProD8
so that you become familiar with all of the features and functions to get the most out of this device. Should
you have any questions, please visit the FAQ section on our Radial web site as this is where we post the
latest applications. You can also email us at info@radialeng.com should you have a question that is not
answered.
We are confident that you will enjoy years of trouble free performance with your new Radial ProD8 and we
look forward to hearing back from you about new an innovative ways you have found to use it. Now start
reading and plugging away!
Radial Engineering
1638 Kebet Way, Port Coquitlam BC V3C 5W9
tel: 604-942-1001 • fax: 604-942-1010
email: info@radialeng.com web: www.radialeng.com
Specifications and appearance subject to change without notice.
