- Page 1 VID-TRANS150KN 2.4GHz WIRELESS AUDIO/VIDEO TRANSMISSION SYSTEM MANUAL PATENT ENGLISH www.konigelectronic.info 0336...
-
Page 2: Important Safety Precautions
A. Contents of the packaging: Important Safety Precautions This equipment generates and uses radio frequency energy and if not 1. Transmitter ×1 installed and used properly, that is in strict accordance with the manufacture's instructions, may cause interference to radio and television reception. -
Page 3: Product Description
REAR VIEW TRANSMITTER Introduction: This 2.4GHz system is a wireless audio/video transmission system that uses advanced wireless communication technology to deliver consistently sharp audio and video up to 80 meters in open area and 30 meters trough walls and ceilings (depending on environment circumstances). The PLL circuit controls the strength and quality of the signal by locking it. -
Page 4: Installation Overview
REAR VIEW RECEIVER Installation of the 2.4GHz transmitter and receiver: 1. Plug the transmitter into the SCART output port of VCR, DVD or SAT. 2. Plug the receiver into the SCART input of the LCD screen, PLASMA screen or television. 3. -
Page 5: Troubleshooting, Care And Maintenance
G. Specifications: Transmitter: VCR, DVD, SAT or other Operating Frequency Band 2.400GHz~2.4835GHz Maximum Output Level 10dBm (CE) Modulation FM (video and audio) IR sensor in front of display Channels (4) PLL frequency synthesizer Video Input Level 1V p-p @ 75 ohm Use the IR cable and connect the 3.5mm plug to the input jack on the back Audio Input Level 1V p-p @ 600 ohm... -
Page 6: Declaration Of Confirmity
Internet: www.nedis.com Declare under our responsibility that the product; Brandname: König Model: VID-TRANS150KN Description: 2.4GHz wireless transmission system Is in confirmity with the following standards; Radio: EN 300-220-3 (2000-09); EN 300 440 (1999-04) EMC: EN 301 489 (2002-08) LVD: EN 60065: 1998 Following the provisions of the 1999/5/EC R&TTE Directive.
